Page 1: User Guide
L-Series B/W Camera CCIR HCM574L HCM584LX HCM384L HCM585LX HCM404LX HCM405LX User Guide Document G-113078-001 – 02/07 – Rev 5... - Page 2 Revisions Issue Date Revisions 1.00 09/06 New document 1.01 09/06 Updated Mains 230V in Figure 2 Figure 1.02 10/06 Changed 2nd ‘clockwise’ to ‘counterclockwise’ on page 8. 10/06 Updated Figure Figure 4, and Figure 5 to show HCM model. 11/06 Updated Figure 1 for better quality.
-
Page 3: Explanation Of Graphical Symbols
Warnings Installation and servicing should be performed only by qualified and experienced personnel to conform to all local codes and to maintain your warranty. WARNING! 12 VDC/24 VAC models require the use of CSA Certified/UL Listed Class 2 power adapters to ensure compliance with electrical safety standards. -
Page 4: Fcc Compliance Statement
FCC Compliance Statement Information to the User: This equipment has been tested and found to comply with the limits for a Class A digital device. Pursuant to Part 15 of the FCC Rules, these limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 5: Table Of Contents
Contents Introduction ....... 1 Features ....... . . 1 Before You Begin . -
Page 6: Introduction
Introduction The Honeywell L-Series monochrome cameras are ideally suited for use in day-to-day surveillance applications. The L-Series monochrome cameras are designed for exceptional value and performance for everyday use. Their off-the-shelf feature set is designed for high picture quality in standard applications and they require little to no adjustment after installation. -
Page 7: Before You Begin
• One L-Series monochrome camera • One Auto Iris lens plug If any parts are missing or damaged, contact the dealer you purchased the camera from or call Honeywell Customer Service (see Contact Information on the back of this manual). -
Page 8: Camera Settings
Camera Settings Camera Functions Figure 2 Camera Rear View Low Voltage Mains 230V—Line Voltage (HCM574L, HCM384L, (HCM585LX, HCM405LX) HCM584LX, HCM404LX) VIDEO CLASS 2 ONLY VIDEO IRIS V -PH LEVEL IRIS V-PH LEVEL = ON LEGEND Shaded box indicates default switch setting. -
Page 9: Setting Up Your Camera
Setting Up Your Camera Figure 3 shows the factory set DIP switch settings. Automatic Gain Control (AGC) is set ON. Figure 3 Factory Set DIP Switch Settings IRIS Low Voltage version shown LEVEL VIDEO CLASS 2 ONLY IRIS V-PH LEVEL = ON LEGEND = OFF... -
Page 10: Video Drive (Vsd) Lens
Video Drive (VSD) Lens Set the VSD/DC switch on the rear of the camera (see Figure 3) to VSD. Backlight Compensation (BLC) If there is excessive light (for example, a window exists in a scene), the camera tries to compensate by reducing the overall exposure, resulting in the areas surrounding the window becoming too dark. -
Page 11: Line Lock Phase Adjustment Potentiometer
V-PH Low Voltage version shown VID EO CLASS 2 ONLY IR IS V-PH LEVEL IN T = ON L EG E ND = OFF Line Lock Phase Adjustment Potentiometer When the camera is in Line lock mode, it is possible to adjust the point on the AC cycle at which the camera triggers. -
Page 12: Lens Installation
Lens Installation Adjusting the Back Focus The back focus adjustment is accessible at the front end of the camera housing to adjust the back focal length or picture focus. The range of adjustment allows both C- and CS-mount lenses to be used without the need for a spacer ring. Figure 4 C/CS Mount Setscrew... - Page 13 Figure 5 DC and VSD Lens Pin Definition 4-pin Auto Iris lens connector DC (Direct Drive) lens Video (VSD) lens CTRL - Power (+12V) CTRL + DRV + Video Signal DRV - Set the select switch to DC. Set the select switch to VSD. Rev 5 G-113078-001 02/07...
-
Page 14: Completing The Installation
Completing the Installation Mounting the Camera Mounting points are provided on the top of the camera for mounting the camera on a bracket or tripod. They are designed to accept standard sized 1/4 x 20 mounting screws. This bracket can be unscrewed and mounted onto the opposite side of the camera, depending on your application. -
Page 15: Connecting The Camera
Connect the camera to a power supply appropriate for your installation. HCM574L, HCM384L, HCM584LX, HCM404LX: 12 VDC or 24 VAC power supply HCM585LX, HCM405LX: 230V power supply Plug in the power supply. The power (PWR) LED illuminates to show that the camera is receiving power. -
Page 16: Warranty And Service
Warranty and Service Subject to the terms and conditions listed on the Product warranty, during the warranty period Honeywell will repair or replace, at its sole option, free of charge, any defective product returned prepaid. In the event you have a problem with any Honeywell product, please call Customer Service at 1.800.796.CCTV (North America... - Page 17 HCM574L HCM584LX HCM585LX Sync System: Internal/Line lock S/N Ratio: > 50 dB Auto Gain On/Off Control (AGC): ALC: EE/VSD/DC Automatic 1/60 - 1/50 - 1/100,000 sec Electronic 1/100,000 sec Shutter (AES): Lens Mount: C/CS mount (adjustable) BLC: On/Off Gamma: 0.45...
- Page 18 HCM384L HCM404LX HCM405LX Scanning 525 lines, 2:1 625 lines, 2:1 interlace System: interlace Number of 510 x 492 500 x 582 Pixels (H x V): Minimum < 0.05 lux @ F1.2 (50 IRE, AGC ON) Illumination: Horizontal 380 TVL 400 TVL Resolution: Video Output: 1 Vp-p @ 75 Ohms...
- Page 20 Document G-113078-001 02/07 © 2007 Honeywell International Inc. All rights reserved. No part of this publication may be reproduced by any means without written permission from Honeywell Video Systems. The information in this publication is believed to be accurate in all respects.
