DVG-2102S
VoIP Telephone Adapter
User's Manual
Version 1.0
(Dec. 2008)

Advertisement

Table of Contents
loading

Related Manuals for D-Link DVG-2102S

Summary of Contents for D-Link DVG-2102S

  • Page 1 DVG-2102S VoIP Telephone Adapter User’s Manual Version 1.0 (Dec. 2008)
  • Page 2 Reproduction in any manner whatsoever without the written permission of D-Link Corporation is strictly forbidden. Trademarks used in this text: D-Link and the D-Link logo are trademarks of D-Link Corporation/D-Link Systems Inc.; Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.

  • Page 3: Table Of Contents

    Contents 1. Introduction ................................ 4 1-1 Product Overview ............................4 1-2 Hardware Description ..........................5 2. Getting Started ..............................7 3. VoIP Telephone Adapter Web Configuration (continued) ................14 3-1 SETUP..............................17 3-1-1 Internet Setup..........................17 3-1-2 VoIP Setup ............................. 23 3-1-3 Time and Date..........................

  • Page 4: Introduction

    1-1 Product Overview The DVG-2102S is designed to carry both voice and facsimile over the IP network. It uses the industry standard SIP call control protocol so as to be compatible with free registration services or VoIP service providers’ systems.

  • Page 5: Hardware Description

    DVG-2102S User’s Manual Telephone Interface Description 1-2 Hardware Description Front Panel Power LED: Green light indicates a normal power supply. A fast blinking light indicates the SIP TA is not registered. A slow blinking light indicates the SIP TA is communicating with the Auto Provision Server.

  • Page 6: Rear Panel

    DVG-2102S User’s Manual Telephone Interface Description Rear Panel Power Receptor: Receptor for the provided power adapter. WAN: Connect to your broadband modem using an Ethernet cable or connect to your Ethernet enabled computers using Ethernet cabling. Phone Port (1-2): Connect to your phones using standard phone cabling (RJ-11).

  • Page 7: Getting Started

    SETUP 2. Getting Started To access the web-based configuration utility, open a web browser such as Internet Explorer and enter the IP address of the DVG-2102S from WAN port. Open your Web browser and type http://192.168.8.254 into the URL address box.
  • Page 8 DVG-2102S User’s Manual SETUP Click Setup Wizard. Click Next. D-Link Systems, Inc.
  • Page 9 DVG-2102S User’s Manual SETUP The username of ADMIN and USER have been defined and locked by default. It is highly recommended to create a login password to keep your Telephone Adapter secure. Click Next. D-Link Systems, Inc.
  • Page 10 DVG-2102S User’s Manual SETUP Enter a NTP server or use the default server. Select your time zone from the drop-down menu. Enable Daylight Saving for your local time if required. Click Next. D-Link Systems, Inc.
  • Page 11 DVG-2102S User’s Manual SETUP Select your Internet connection type: DHCP – Most Cable ISPs or if you are connecting the DVG-2102S behind a router. Static IP – Select if your ISP supplied you with your IP settings. PPPoE – Most DSL ISPs.
  • Page 12 DVG-2102S User’s Manual SETUP Register to the SIP Proxy Server by clicking Enable support of SIP Proxy Server. Enter Proxy Server IP/Domain and Port. Outbound Proxy Support is optional. To register, please click on the Outbound Proxy Support box and enter Outbound Proxy IP/Domain and Port in it.
  • Page 13 DVG-2102S User’s Manual SETUP Setup is finished. Check the summary of your settings. To make new settings effective, you must click on the Restart button to reboot the DVG-2102S. Click Restart D-Link Systems, Inc.

  • Page 14: Voip Telephone Adapter Web Configuration (Continued)

    DVG-2102S User’s Manual SETUP 3. VoIP Telephone Adapter Web Configuration (continued) During configuration, please follow the Setup Hint for some specific procedure in case the VoIP Telephone Adapter fails to make the changes active. Situation 1: (example: Internet Setup) Setup Hint: Select DHCP WAN Setup.
  • Page 15 DVG-2102S User’s Manual SETUP Situation 2: (example: VoIP Proxy Server) Setup Hint: Click “Edit” to start configuration. Click “Apply” after settings. Go to “MAINTAINACE”-> “Backup and Restore” save settings and reboot the system. D-Link Systems, Inc.
  • Page 16 DVG-2102S User’s Manual SETUP Situation 3: (example: Enable IP Filtering) Setup Hint: Click “Enable IP Filtering” check box to open the main screen. Click “Add” to enter an entry. After Adding an entry, you have to click “Apply”. Don’t forget to click “Apply” which in the filed of “Enable IP Filtering”.

  • Page 17: Setup

    DVG-2102S User’s Manual SETUP 3-1 SETUP 3-1-1 Internet Setup WAN (Wide Area Network) Settings are used to connect to your ISP (Internet Service Provider). The WAN settings are provided to you by your ISP and oftentimes referred to as "public settings". Please select the appropriate option for your specific ISP.
  • Page 18 DVG-2102S User’s Manual SETUP SETUP → Internet Setup SETUP → Internet Setup DHCP: Select this option if your ISP (Internet Service Provider) provides you an IP address automatically. Cable modem providers typically use dynamic assignment of IP Address. The Host Name field is optional but may be required by some Internet Service Providers.
  • Page 19 DVG-2102S User’s Manual SETUP SETUP → Internet Setup PPPoE: Select this option if your ISP requires you to use a PPPoE (Point-to-Point Protocol over Ethernet) connection. Enter the PPPoE Account, PPPoE Password and re-enter Password to confirm. SETUP → Internet Setup PPTP: Point-to-Point Tunneling Protocol (PPTP) is a WAN connection.
  • Page 20 DVG-2102S User’s Manual SETUP SETUP → Internet Setup L2TP: Layer 2 Tunneling Protocol is a WAN connection. Enter the IP Address, Subnet mask, L2TP Server, L2TP ID and Password. D-Link Systems, Inc.
  • Page 21 DVG-2102S User’s Manual SETUP SETUP → Internet Setup Before the VoIP Gateway obtains an IP address, you can use the IP address of WAN ALIAS to browse the Web UI for configuration. IP Address: The default IP is 192.168.8.254. Subnet Mask: Leave the Subnet Mask as default: 255.255.255.0.
  • Page 22 DVG-2102S User’s Manual SETUP SETUP → Internet Setup Factory Default MAC Address: The original MAC address of the VoIP Telephone Adapter. Your MAC Address: It is left blank as you log-in via the WAN port. Current MAC Address: It shows the current MAC Address if you ever used the different MAC address from Factory Default MAC Address.

  • Page 23: Voip Setup

    DVG-2102S User’s Manual SETUP 3-1-2 VoIP Setup In this section, it supports registration to multiple Proxy Servers which is allowed to choose ITSP by user manually. If any registration problem occurs, please consult your VoIP Service Provider. SETUP → VoIP Setup Clink Edit icon to modify the settings.
  • Page 24 DVG-2102S User’s Manual SETUP SETUP → VoIP Setup Enable Support of SIP Proxy Server / Soft Switch: Check the box to register the VoIP Telephone Adapter with SIP proxy server or soft switch. ITSP Name: Enter the name of ITSP.
  • Page 25 DVG-2102S User’s Manual SETUP SETUP → VoIP Setup Each line registers to Proxy independently: Number: Enter the number, text or number and text in this field. It is the Caller ID for the called party when you make a VoIP call. If you register the VoIP Telephone Adapter to a SIP proxy server, then it should be the number that provided by SIP proxy server.
  • Page 26 DVG-2102S User’s Manual SETUP SETUP → VoIP Setup Proxy Server IP/Domain: Enter the IP address or URL (Uniform Resource Locator) of SIP proxy server or soft switch. Proxy Server Port: Enter the SIP proxy server’s listening port for the SIP in this field. Leave this field to the default if your VoIP Service Provider did not give you a server port number for SIP.
  • Page 27 DVG-2102S User’s Manual SETUP SETUP → VoIP Setup Outbound Proxy Support: Check the box to send all SIP packets to the destined outbound proxy server. An outbound proxy server handles SIP call signaling as a standard SIP proxy server would do. Further, it receives and transmits phone conversation traffic (media) between two communication parties.
  • Page 28 DVG-2102S User’s Manual SETUP SETUP → VoIP Setup The rule of dialing of inviting to VoIP Service Providers may vary. That is, you have to configure different Digit Map for different ITSP. In this filed, you can configure individual Digit Map for each Proxy Server. The following examples introduce some cases.
  • Page 29 DVG-2102S User’s Manual SETUP For example (Example in Taiwan), If Server 1 is local ITSP, you can refer to Digit Map page for general settings. If Server 2 is global ITSP (VoIP STUN, free to dial to some cities free charge) you can set individual Digit Map in Number Translation field.

  • Page 30: Time And Date

    DVG-2102S User’s Manual SETUP 3-1-3 Time and Date SETUP → Time and Date Automatically synchronize with Internet time servers: The VoIP Telephone Adapter should automatically sync up with time servers. First NTP time server: Select the desired domain name of a NTP server as first priority.

  • Page 31: Advanced

    DVG-2102S User’s Manual ADVANCED 3-2 ADVANCED 3-2-1 VoIP 3-2-1-1 Caller Filter This function allows you to accept or reject any incoming call from the IP address listed in the filter rule. The call from the IP address of SIP proxy server is always accepted, despite Deny is selected or the IP address of SIP proxy server is not in the filter rule of Allow.
  • Page 32 DVG-2102S User’s Manual ADVANCED 3-2-1-2 Caller ID ADVANCED → VoIP → Caller ID FXS Caller ID Generation: Select DTMF, FSK or FSK+Type II Caller ID to enable the caller ID display function on FXS port. When enabled, the caller’s phone number will be displayed on your phone set when the call comes through.

  • Page 33: Calling Features

    DVG-2102S User’s Manual ADVANCED 3-2-1-3 Calling Features ADVANCED → VoIP → Calling Features Do Not Disturb: Check the box to reject (busy tone played) incoming calls. Unconditional Forward: Check the box to forward incoming calls to the assigned “Forwarding Number”...
  • Page 34 DVG-2102S User’s Manual ADVANCED Proxy Server that supports Three-Way Calling service. Local Mixer: It is used to setup the conference call when your Proxy Server did not support Three-Way Calling service. Calling Feature Instructions: Call Hold: The call will be held after the FLASH button is pressed on the phone set. The VoIP Telephone Adapter will play a hold music (provided by your ITSP or VSP) to the remote end.
  • Page 35 DVG-2102S User’s Manual ADVANCED ADVANCED → VoIP → Calling Features Enable Call Feature Code: Check the box to enable/disable some call feature codes through a phone set. Call pickup: Allow one to pick up someone else’s telephone call. Call Back on Busy: Your phone will ring back the last number that called you.
  • Page 36 DVG-2102S User’s Manual ADVANCED 3-2-1-4 Codec ADVANCED → VoIP → Codec Preferred Codec Type: Select a preferred codec type for all calls. Since different voice codecs have different compression ratios, the sound quality and occupied bandwidths are also different. The factual codec may determine by the called party.
  • Page 37 DVG-2102S User’s Manual ADVANCED 3-2-1-5 CPT/Cadence ADVANCED → VoIP → CPT / Cadence CPT # 1 Enable Setting 1: The CPT has a set of parameter table. Please adjust the CPT based on the local PSTN or PBX settings and requirements.

  • Page 38: Digit Map

    DVG-2102S User’s Manual ADVANCED 3-2-1-6 Digit Map Digit Map supports multiple dial plans which help users to arrange least cost route. Each Proxy Server has individual dial plan which combines the original feature of Digit Map and Speed Dial. You can use “?” or “%”...
  • Page 39 DVG-2102S User’s Manual ADVANCED ADVANCED → VoIP → Digit Map → VoIP Route Profile Example of VoIP Route Profile: Assume that VoIP TA is registered to three servers. Server 1 is local VoIP Service Provider. Server 2 is VoIP STUN (free to dial to some cities without charge).
  • Page 40 DVG-2102S User’s Manual ADVANCED Example 1 – Single VoIP route, The number translation of each server is blank. The VoIP route profile appears like: Digit Map Table appears like: As you dial the phone numbers starting with 09, like 0912345678, the call will only go through Server 1 (local VSP).
  • Page 41 DVG-2102S User’s Manual ADVANCED Example 2 – Multiple Route, The number translation of Server 1 is blank, and the number translation of Server 2 appears like: The VoIP route profile appears like: Digit Map Table appears like: As you dial the phone numbers staring with 03, like 0312345678, the number will be changed to 0045312345678, followed the number translation of Server 2, and the call will go through Server 2 (free VSP) at first.
  • Page 42 DVG-2102S User’s Manual ADVANCED Example 3 – Multiple Route, The number translation of Server 1 is blank, and the number translation of Server 2 appears like: The number translation of Server 3 appears like: The VoIP Route Profile appears like:...
  • Page 43 DVG-2102S User’s Manual ADVANCED Digit Map Table appears like: As you dial the phone numbers staring with 00244, like 00244123456789, the number will be changed to 0123456789 followed the number translation of Server3, and the call will go through Server 3 (UK VSP) at the first.
  • Page 44 DVG-2102S User’s Manual ADVANCED Method 1- Single mapping: Fill a short code into the Scan Code column, and enter the desired phone number into the VoIP Dial-out column. For example, Scan Code: 091 VoIP Dial-out: 0912345678 User Dial Length: 3...
  • Page 45 DVG-2102S User’s Manual ADVANCED 4. Translate the global number to the private number followed the number translation of Server 2. 00244323456789 is translated to 0044323456789. 5. If Server 2 is failed, the system will use the global number to go through Server 1.
  • Page 46 DVG-2102S User’s Manual ADVANCED 3-2-1-7 DTMF & PULSE ADVANCED → VoIP → DTMF & PULSE Dial Wait Timeout: Enter the timeout duration after the user picks up the phone set. Inter Digits Timeout: Enter the timeout duration between the intervals of each key pressed. When exceeding the set timeout duration without entering further digits, the numbers entered will be dialed out.
  • Page 47 DVG-2102S User’s Manual ADVANCED 3-2-1-8 Fax ADVANCED → VoIP → FAX FAX / Modem: Select the mode to detect if there is a fax tone and transfer the call to a fax line. Function Fax Detection Content of SDP of re-INVITE re-INVITE with T.38...
  • Page 48 DVG-2102S User’s Manual ADVANCED ADVANCED → VoIP → FAX Enable High Quality: Check the box to increase approximately two times the bandwidth in order to compensate possible loss of packet during transmission and offers a better and reliable fax quality.

  • Page 49: Hot Line

    DVG-2102S User’s Manual ADVANCED 3-2-1-9 Hot Line ADVANCED → VoIP → Hot Line Hot Line: Check to direct the call automatically to a pre-configured destination without any action when the FXS is off-hook. (ie. as the user picks up the phone). When the FXS is under Hot Line mode, no other phone numbers can be dialed.
  • Page 50 DVG-2102S User’s Manual ADVANCED 3-2-1-10 Line ADVANCED → VoIP → Line Enable: Tick the check box to enable a line. If some lines are not used, disable them (Pause Function) to avoid unnecessary waiting when an incoming call is diverting to the line.
  • Page 51 DVG-2102S User’s Manual ADVANCED ADVANCED → VoIP → Line Ring (Early Media) Time Limit[10 - 600secs]: Enter the timeout to cancel a call if no one answers the phone. Enable End of Digit Tone: Check the box to activate the function of playing a “Beep-Beep” tone to notify the user that the call is in progress.
  • Page 52 DVG-2102S User’s Manual ADVANCED ADVANCED → VoIP → Line Termination Impedance: Select different impedance from the drop-down menu. ADVANCED → VoIP → Line This feature is a call drop standard for a VoIP Telephone Adapter to determine whether or not to hang up the phone.
  • Page 53 DVG-2102S User’s Manual ADVANCED ADVANCED → VoIP → Line Hunting/Ring: It is used to set FXS group hunting mode. There are Hunting, Simultaneous Ring and Sequential Ring. Hunting: When someone calls in by dialing FXS representative number, the system will always assign the call to the first line.

  • Page 54: Phone Book

    DVG-2102S User’s Manual ADVANCED 3-2-1-11 Phone Book Phone Book: It is used for peer-to-peer communication. Some peer information needs to be added to this section prior to making peer-to-peer calls. You need to enter the phone number and the IP address of the remote peer.
  • Page 55 DVG-2102S User’s Manual ADVANCED 3-2-1-12 SIP Advanced ADVANCED → VoIP → SIP Advanced Listen Port UDP: Enter the VoIP Telephone Adapter’s listening port in this field. Leave it as default settings, unless it conflicts with ports used by other device in your network.
  • Page 56 DVG-2102S User’s Manual ADVANCED ADVANCED → VoIP → SIP Advanced Session Expiration: This field will set the time that the VoIP Telephone Adapter will allow a SIP session to remain die (without traffic) before dropping it. Session Refresh Request: Select UPDATE or re-INVITE to send refresh requests to the Server.
  • Page 57 DVG-2102S User’s Manual ADVANCED ADVANCED → VoIP → SIP Advanced Anonymous Caller ID (CLIR): Check the box to lock the delivery of the Caller ID to the called party. VoIP Call Out Notification: Check the box to enable the function of playing a tone to notify user that the call is through VoIP.
  • Page 58 DVG-2102S User’s Manual ADVANCED Put Caller ID In URI: This feature is to put Caller ID in URL. The Caller ID is located in SIP → Message Header → After [From:], Before [<sip:] by default settings. It will be located in SIP → Message Header →...

  • Page 59: Dos Prevention

    DVG-2102S User’s Manual ADVANCED 3-2-2 DoS Prevention ADVANCED → DoS Prevention D-Link Systems, Inc.
  • Page 60 DVG-2102S User’s Manual ADVANCED ADVANCED → DoS Prevention Enable DoS Prevention: Check the box to prevent DoS attacks from WAN. There are various types of DoS attacking. Leave settings in this field to the default if you are not familiar with it.

  • Page 61: Advanced Network

    DVG-2102S User’s Manual ADVANCED 3-2-3 Advanced Network 3-2-3-1 QOS ADVANCED → Advanced Network → QoS QoS Enable: Check the box to guaranty the voice quality. Voice packets have the highest priority in IP networks, and the data transmission is distributed to less bandwidth.

  • Page 62: Nat Traversal

    DVG-2102S User’s Manual ADVANCED 3-2-3-2 NAT Traversal If your VoIP Telephone Adapter is set up behind an Internet sharing device, you can select either the NAT or STUN protocol. ADVANCED → Advanced Network → NAT Traversal Enable NAT Public IP: Check the box to use the IP address of the Internet sharing device if the VoIP Telephone Adapter is set up behind an Internet sharing device.
  • Page 63 DVG-2102S User’s Manual ADVANCED 3-2-3-3 STUN Inquiry Use “STUN Inquiry” to detect your IP sharing device’s NAT type and communication between a STUN server and client. ADVANCED → Advanced Network → STUN Inquiry NAT Type: It shows the NAT type of your router.
  • Page 64 DVG-2102S User’s Manual ADVANCED 3-2-3-4 Static Route Build static routes within an internal network. These routes will not apply to the Internet. ADVANCED → Advanced Network → Static Route Route: Destination network of the route. Route Mask: Subnet mask to apply on destination network.

  • Page 65: Maintenance

    DVG-2102S User’s Manual MAINTENANCE 3-3 MAINTENANCE 3-3-1 Device Management MAINTENANCE → Device Management Note: There are two operating levels when entering the Web UI. Logging-in as the ADMIN allows you to change all settings. A Web UI USER only has access to some settings.

  • Page 66: Backup And Restore

    DVG-2102S User’s Manual MAINTENANCE 3-3-2 Backup and Restore Save and Reboot MAINTENANCE → Backup and Restore Save All Settings: Click the Save All Settings check box and reboot the system after completing changes. The new settings will take effect after the VoIP Telephone Adapter is restarted.

  • Page 67: Restore Default Settings

    DVG-2102S User’s Manual MAINTENANCE Update Settings MAINTENANCE → Backup and Restore To restore a system settings file, click on Browse to search the local hard drive for the file to be used. Once you locate the file, click Upload Settings to overwrite the current settings with the settings saved to the file.

  • Page 68: Firmware Update

    DVG-2102S User’s Manual MAINTENANCE 3-3-3 Firmware Update The VoIP Telephone Adapter supports a software upgrade function from a remote server. Please consult your VoIP Service Provider for information about the following details. MAINTENANCE → Firmware Update Upgrade Server: Select the upgrade type: TFTP, FTP, or HTTP.

  • Page 69: Dynamic Dns

    DVG-2102S User’s Manual MAINTENANCE 3-3-4 Dynamic DNS ADVANCED → Dynamic DNS Enable Dynamic DNS: Check the box to enable DDNS function. It is only necessary when the VoIP Telephone Adapter is set up behind an Internet sharing device that uses a dynamic IP address and does not support DDNS.

  • Page 70: Log Settings

    DVG-2102S User’s Manual MAINTENANCE 3-3-5 Log Settings MAINTENANCE → Log Settings Enable: Check the box to send event notification messages across IP networks to the Server. Server Address: Enter the System Log Server’s IP address. Port: Enter the System Log Server’s listening port. Leave this field to the default if your VoIP Service Provider did not provide you a server port number for System Log Server.

  • Page 71: Diagnostics

    DVG-2102S User’s Manual MAINTENANCE 3-3-6 Diagnostics Use “Ping” to verify if a remote peer is reachable. Enter a remote IP address and click “Test” to ping the remote host. The result would be shown on Result Table MAINTENANCE → Diagnostics...

  • Page 72: Provision

    DVG-2102S User’s Manual MAINTENANCE 3-3-7 Provision Provisioning is a function that automatically updates your VoIP Telephone Adapter’s configuration by using a TFTP, FTP, or HTTP server located on the Internet. If you have access to such service, you will need to know the URL or IP address of the Provisioning Server.
  • Page 73 DVG-2102S User’s Manual MAINTENANCE Connect Provision Server Periodically: Check the box to connect to Provisioning Server periodically. Auto Provision Interval: Enter the time for auto provisioning. Random Offset: Enter the offset of the time for auto provisioning. Provision Retry Times: Enter the retry time if a provisioning attempt fails.

  • Page 74: Cdr

    DVG-2102S User’s Manual MAINTENANCE 3-3-8 CDR The user can set up a CDR Server to record call details for every phone call with TCP protocol. The present CDR provides the call event such as HOOK ON, HOOK OFF, DIALED NUMBER, DATE…recording in a text file and which can be imported to prepare an analysis report.

  • Page 75: Status

    DVG-2102S User’s Manual STATUS 3-4 STATUS 3-4-1 Device Info STATUS → Device Info For System Info, it shows Model Name, Time and Date and Firmware version. For Network Information, it shows factory default MAC address, IP address, subnet mask, default gateway and DNS server.

  • Page 76: Voip Status

    DVG-2102S User’s Manual STATUS 3-4-2 VoIP Status STATUS → VoIP Status For Port Status, it includes if each port registers to Proxy successfully, the last dialed number, how many calls each port has made since the VoIP Telephone Adapter is start, etc.

  • Page 77: Statistics

    DVG-2102S User’s Manual STATUS 3-4-3 Statistics STATUS → Statistics Display the information of the last call made. Press Refresh button to get the latest RTP Packet Summary. 3-4-4 Routing Table STATUS → Routing Table The Routing Table stores the information for particular network destination around the VoIP Telephone Adapter.

  • Page 78: Logout

    DVG-2102S User’s Manual STATUS 3-4-5 Logout If setting or parameter has been changed, remember to save the changes before you logout the configuration menu. Logout D-Link Systems, Inc.

  • Page 79: Configuring The Voip Telephone Adapter Through Ivr

    DVG-2102S User’s Manual VoIP Telephone Adapter Configuration-IVR 4. Configuring the VoIP Telephone Adapter through VoIP transmits voice data (packets) via the Internet, hence the condition and status of the network environment is relatively important to the telecommunications quality. If any one of the parties involved in VoIP communications has insufficient bandwidth or frequent packet loss, the telecommunication quality will be poor.
  • Page 80 DVG-2102S User’s Manual VoIP Telephone Adapter Configuration-IVR Functions Table for available functions and codes. Once the setting or query has been completed, you can hear a dial tone. Use the same procedure to make a second query or setting. To exit IVR mode, simply hang up the phone.

  • Page 81: Ivr Functions Table

    DVG-2102S User’s Manual VoIP Telephone Adapter Configuration-IVR 4-1-1 IVR Functions Table: Function Description Example / Notes Code 111/101 WAN Port IP address Set/Query Dial function code 114 and then dial 1 for a Static IP connection then 112/102 WAN Port Subnet Mask Set/Query setup the IP address.

  • Page 82: Ip Configuration Settings-Set The Ip Configuration Of The Wan Port

    DVG-2102S User’s Manual VoIP Telephone Adapter Configuration-IVR 4-2 IP Configuration Settings—Set the IP Configuration of the WAN Port Static IP Settings Note: Complete static IP settings should include a static IP (option 1 under 114), IP address (111), Subnet Mask (112), and Default Gateway (113). Please contact your Internet Service Provider (ISP) if you have any question.
  • Page 83 DVG-2102S User’s Manual VoIP Telephone Adapter Configuration-IVR Select a PPPoE After entering IVR mode, dial 114. When voice prompt plays “Enter value,” dial 3 (to select PPPoE). PPPoE Account Settings After entering IVR mode, dial 121. When voice prompt plays “Enter value”, enter the account number followed by”#”.

  • Page 84: Pppoe Character Conversion Table

    (high-lighted) of each pair of the column (“Input Key”) represents the codes to be entered for the corresponding numbers, alphabets or symbols. For example, to enter “D-Link” according to the table below, enter: 148322495451 Numbers...

  • Page 85: Dialing Principles

    DVG-2102S User’s Manual Dialing Principles 5. Dialing Principles 5-1 Dialing Options Dial the phone number which you want to call and press # to call out immediately. Note that if the “# (pound)” not dialed, the number will be called out after 4 seconds by default. The period between number dialed and call out is named “Inter Digits Timeout”.

  • Page 86: Routing

    DVG-2102S User’s Manual Dialing Principles 5-3 Routing To achieve maximum flexibility, the number dialed will be looked up in several tables defined by the VoIP Telephone Adapter. If no match is found from Digit Map Table, it will then look up the number from another table and to the registered VoIP Service Provdier.
  • Page 87 DVG-2102S User’s Manual Dialing Principles Start Enter a phone number (D#) Is (D#) defined Change the number to in Digit Map Global Number. table? Is (D#) or Global Number defined in Phone Book table? Is (D#) or Global Number defined in Server 1?

  • Page 88: Appendix

    DVG-2102S User’s Manual Appendix Appendix Product Features • One 10/100Mbps auto-negotiation, auto-crossover RJ-45 Ethernet port • Support static IP, PPPoE, and DHCP address assignment and dynamic DNS (DDNS) • QoS: IP TOS (Type of Services) and DiffServ (Differentiated Services) for both SIP signaling and RTP •...
  • Page 89 DVG-2102S User’s Manual Appendix Configuration & Maintenance • Configuration methods: Telnet • Status reports: Port status Registration status Ping tests STUN/UPnP status Hardware / software information • Firmware Upgrade through TFTP, FTP and proprietary image server • Configuration Backup/Restore •...
