ROUTER TABLE

MODEL H3114
INSTRUCTION MANUAL
COPYRIGHT © DECEMBER 2002 BY GRIZZLY INDUSTRIAL, INC
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
PRINTED IN CHINA
ONLINE MANUAL DISCLAIMER
THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE
MACHINE CONFIGURATION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED. IF YOU OWN AN EARLIER VERSION OF
THE MACHINE, THIS MANUAL MAY NOT EXACTLY DEPICT YOUR MACHINE . CONTACT CUSTOMER SERVICE IF YOU HAVE ANY QUESTIONS
ABOUT DIFFERENCES. PREVIOUS VERSIONS ARE NOT AVAILABLE ONLINE.

Advertisement

Table of Contents
loading

Related Manuals for Grizzly H3114

Summary of Contents for Grizzly H3114

  • Page 1: Router Table

    INSTRUCTION MANUAL COPYRIGHT © DECEMBER 2002 BY GRIZZLY INDUSTRIAL, INC WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC. PRINTED IN CHINA ONLINE MANUAL DISCLAIMER THE INFORMATION IN THIS MANUAL REPRESENTS THE CONFIGURATION OF THE MACHINE AS IT IS CURRENTLY BEING SHIPPED. THE MACHINE CONFIGURATION CAN CHANGE AS PRODUCT IMPROVEMENTS ARE INCORPORATED.
  • Page 2 Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemi- cals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead-based paints. •...

  • Page 3: Table Of Contents

    SAFETY ...2 SAFETY INSTRUCTIONS FOR POWER TOOLS...2-3 ADDITIONAL SAFETY INSTRUCTIONS FOR ROUTER TABLES ...4 INTRODUCTION ...5 COMMENTARY...5 CIRCUIT REQUIREMENTS ...6 GENERAL ...6 ELECTRICAL ...6 SET UP...7 MAIN FEATURES ...7 ASSEMBLY ...8-13 OPERATION ...14-16 REFERENCE INFO ...17 PARTS BREAKDOWNS AND LIST ...18-19 WARRANTY AND RETURNS ...22-24...

  • Page 4: Safety

    H3114 Router Table VISITORS...

  • Page 5: Safety Instructions For Power Tools

    13. NEVER OVERREACH. Keep proper foot- ing and balance at all times. H3114 Router Table 14. MAINTAIN TOOLS WITH CARE. Keep 15. DISCONNECT TOOLS before servicing 16. REDUCE THE RISK OF UNINTENTIONAL...

  • Page 6: Additional Safety Instructions For Router Tables

    12. NEVER REACH BEHIND THE SPINNING CUTTER. 13. READ UNDERSTAND INSTRUCTION MANUAL WITH THE ROUTER INSTALLED IN THIS TABLE 14. DO NOT REACH UNDER THE ROUTER TABLE WHILE PLUGGED IN OR RUNNING. H3114 Router Table SUPPLIED ROUTER...

  • Page 7: Introduction

    SECTION 2: INTRODUCTION Commentary We are proud to offer the Grizzly Model H3114 Router Table. The Model H3114 is part of a grow- ing Grizzly family of fine woodworking machinery. When used according to the guidelines set forth in this manual, you can expect years of trouble- free, enjoyable operation and proof of Grizzly’s...

  • Page 8: Circuit Requirements

    The power switch (Page 7, Figure 2) on the Model H3114 is designed to work with most routers and other electrical accessories. The power switch provides the convenience of switch-...

  • Page 9: Set Up

    Figure 2. Retractable Dust Port Guard Pocket Table Insert Jointing Main Fence Fence Extension Table Miter Gauge Main Table Power Switch Note–Only 1 of the 5 table inserts are shown. Figure 2. Machine features. H3114 Router Table...

  • Page 10: Assembly

    (Figure 3). Note—DO NOT secure the extension tables with screws at this time. Extension Table Main Table Figure 3. Aligning an extension table with the main table. H3114 Router Table...
  • Page 11 Figure 5. Securing a leg to the main table. Repeat Steps 3 & 4 for the remaining three legs. H3114 Router Table To check the flushness of the table: Place a straightedge across both extension tables and the main table. The straightedge should sit flush on all three surfaces as shown in Figure 6.
  • Page 12 Begin threading the M5-0.8 keps nuts onto the ends of the M5-0.8 x 45 carriage bolts. Rotate the clamps out of the circular recess and position the router base against the cir- cular recessed area. H3114 Router Table...
  • Page 13 Hold the router and rotate the clamps over the router base as shown in Figure 9 . Clamp Position Figure 9. Rotating a clamp over the router base. Tighten the M5-0.8 keps nuts enough to pre- vent the router from moving, but DO NOT fully tighten them at this time.
  • Page 14 Figure 15. Note—The power switch mounting bracket should be on the inside of the main table edge. Figure 15. Securing the power switch to the main table. Flip the table assembly top-side up . H3114 Router Table ⁄ " truss head...
  • Page 15 To secure the router table to a workbench: The bottom of each leg has two holes ( Figure 16 ) used for mounting the router table to the work- bench. Secure the router table to the workbench with wood screws and washers.

  • Page 16: Operation

    Wear safety glasses during assembly. Routing operations on your Model H3114 are grouped into three main techniques: • Jointing an edge (Page 14) • Groove cutting (Page 15) • Profile cutting with pilot bits (Page 16)
  • Page 17 Edge Of Board To Center Of V-Groove Figure 22. Groove cutting setup. (Side View) Tighten the main fence threaded knobs. Double check that the router is secured to the table. If it is, the router table is ready for use. -15-...
  • Page 18 Router Bit Figure 24. Proper setup for profile cutting. (Side View) Tighten the main fence threaded knobs. Double check that the router is secured to the table. If it is, the router table is ready for use. H3114 Router Table...

  • Page 19: Reference Info

    Grizzly Service Department. Trained ser- vice technicians will be glad to help you. If you have any comments regarding this manual, please write to Grizzly at the address below: Grizzly Industrial, Inc. Technical Documentation P.O. Box 2069...

  • Page 20: Parts Breakdowns And List

    PARTS BREAKDOWN AND LIST -18- H3114 Router Table...
  • Page 21 12 PH3114012 POCKET JOINTING FENCE 13 PH3114013 MAIN FENCE M8-1.25 15 PH3114015 THREADED KNOB 16 PH3114016 DUST COLLECTION INSERT H3114 Router Table PART # DESCRIPTION 17 PH3114017 SAFETY GUARD 18 PHTEK5M M4 X 12 (TYPE B) TAP SCREW 19 PH3114019 TABLE INSERT (5)
  • Page 22 NOTES -20- H3114 Router Table...
  • Page 23 NOTES H3114 Router Table -21-...

  • Page 24: Warranty And Returns

    WARRANTY AND RETURNS Grizzly Industrial, Inc. warrants every product it sells for a period of 1 year to the original purchaser from the date of purchase. This warranty does not apply to defects due directly or indirectly to misuse, abuse, negligence, accidents, repairs or alterations or lack of maintenance.
  • Page 25 Do you think your purchase represents good value? ___Yes Would you recommend Grizzly Industrial to a friend? ___Yes Would you allow us to use your name as a reference for Grizzly customers in your area? Note: We never use names more than three times. ___Yes Comments:_________________________________________________...
