3
• Tilt the unit slightly to one side to access the
Step
• Install a U-Clip into the front and rear holes
Install
CAUTION: See illustration. Be sure the tangs
on the clips are on the outside and the
Leveling
straight portion is inserted into the holes.
Legs
• Screw the leveling legs into the U-clips all
• Follow the same procedure for the opposite
4
• Move the beverage center/wine chiller close
• Connect the power cord plug to the properly
S tep
• Slide the unit into the opening.
Slide the
Unit into
the Cutout
bottom corner holes.
on the bottom as shown.
the way until snug. Then, adjust the leveling
legs to installation height.
side.
to the opening.
grounded receptacle.
Installation
Beverage Center & Wine Chiller
A.
B.
C.
D.
7
