SerialPort configuration
xConfiguration SerialPort Mode
Enable/disable the serial port (COM port).
Requires user role: ADMIN
Value space: <Off/On>
Off: Disable the serial port.
On: Enable the serial port.
Example: xConfiguration SerialPort Mode: On
xConfiguration SerialPort BaudRate
Specify the baud rate (data transmission rate, bits per second) for the serial port. The default value
is 38400.
Other connection parameters for the serial port are: Data bits: 8; Parity: None; Stop bits: 1; Flow
control: None.
Requires user role: ADMIN
Value space: <9600/19200/38400/57600/115200>
Range: Select a baud rate from the baud rates listed (bps).
Example: xConfiguration SerialPort BaudRate: 38400
xConfiguration SerialPort LoginRequired
Determine if login shall be required when connecting to the serial port.
Requires user role: ADMIN
Value space: <Off/On>
Off: The user can access the codec via the serial port without any login.
On: Login is required when connecting to the codec via the serial port.
Example: xConfiguration SerialPort LoginRequired: On
Codec C90 API Reference Guide TC7.0, JANUARY 2014.
D14641.15
About the API xConfiguration xConfiguration

SIP configuration

xConfiguration SIP ANAT
xConfiguration SIP AuthenticateTransferror
xConfiguration SIP ListenPort
xConfiguration SIP PreferredIPMedia
60
xCommand
ANAT (Alternative Network Address Types) enables media negotiation for multiple addresses and
address types, as specified in RFC 4091.
Requires user role: ADMIN
Value space: <Off/On>
Off: Disable ANAT.
On: Enable ANAT.
Example: xConfiguration SIP ANAT: Off
Not applicable in this version.
Turn on or off the listening for incoming connections on the SIP TCP/UDP ports. If turned off, the
endpoint will only be reachable through the SIP registrar (CUCM or VCS). It is recommended to
leave this setting at its default value.
Requires user role: ADMIN
Value space: <On/Off>
On: Listening for incoming connections on the SIP TCP/UDP ports is turned on.
Off: Listening for incoming connections on the SIP TCP/UDP ports is turned off.
Example: xConfiguration SIP ListenPort: On
Define the preferred IP version for sending and receiving media (audio, video, data). Only applicable
when both Network IPStack and Conference CallProtocolIPStack are set to Dual, and the network
does not have a mechanism for choosing the preferred IP version.
Requires user role: ADMIN
Value space: <IPv4/IPv6>
IPv4: The preferred IP version for media is IPv4.
IPv6: The preferred IP version for media is IPv6.
Example: xConfiguration SIP PreferredIPMedia: IPv4
