Page 1: User Manual
Version 1.0 | 05/29/2013 User Manual Full HD Outdoor Fixed Dome Network Camera DCS-6314... -
Page 2: Manual Revisions
Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Information in this document may become obsolete as our services and websites develop and change. -
Page 3: Table Of Contents
Connection Using Power over Ethernet ....24 Status ..................67 Software Installation ............25 Device Info ................67 D-ViewCam Setup Wizard ..........28 Logs ..................68 Configuration ................30 Help..................69 Using the Configuration Interface ........30 DI/DO Specifications ..............70 Live Video ................31 Technical Specifications ............71 D-Link DCS-6314 User Manual... -
Page 4: Product Overview
Section 1: Product Overview Product Overview Package Contents CAT5 Ethernet cable DCS-6314 Full HD Outdoor Fixed Dome Network Camera CD-ROM with User Manual and software Screws and wall socket Quick Installation Guide Weather Shield Power adapter 4Pin Terminal Block Security Wrench If any of the above items are missing, please contact your reseller. -
Page 5: Introduction
The DCS-6314 has an IP68 certified weatherproof housing designed for both indoor and outdoor applications. The built-in removable IR-cut filter and IR LEDs give the DCS-6314 the capability to view up to 15 meters at night. The ability to use Power over Ethernet (PoE) also allows it to be easily installed in a variety of locations without the need for supplemental power cabling. -
Page 6: Features
The built-in infrared LEDs enables night time viewing of up to 15 meters (49 feet). IP68 Weatherproof Housing The DCS-6314 uses an IP68 weatherproof housing, allowing you to rest assured that in the toughest of conditions, it will continue to provide round- the-clock surveillance. -
Page 7: Hardware Overview
The light sensor measures the lighting conditions and switches between color Light Sensor and infrared accordingly Camera Lens Vari-focal lens to record video of the surrounding area IR LEDs Infrared LEDs illuminate the camera's field of view at night Power/Status LED Indicates the camera's current status D-Link DCS-6314 User Manual... -
Page 8: Top
IR LEDs. For details on how to adjust the camera angle, please see "Orienting the Camera" on page 22. For details on how to turn the IR LEDs on/off, please see "ICR and IR" on page 61. D-Link DCS-6314 User Manual... -
Page 9: Cable Harness
Power connector for the provided 12V DC power adapter. Connects to an RJ45 Ethernet port. Can be used with PoE to provide power to Ethernet Jack the camera. Reset Button Press and hold the recessed button for 10 seconds to reset the camera. D-Link DCS-6314 User Manual... -
Page 10: Internal
Insert a Micro SD card for Local storage for storing recorded image and video Note: For step-by-step instruction on how to insert a Micro SD card please skip to "Installing a Micro SD Card" on page 11. D-Link DCS-6314 User Manual... -
Page 11: Assembly And Installation
Remove the adjustable top part of the camera housing by removing the three retaining screws. Step 3 Remove the base of the camera by holding the camera firmly and rotating the base in a counter clockwise direction. D-Link DCS-6314 User Manual... - Page 12 Replace the base of the camera by holding the camera firmly and rotating the base in a clockwise direction ensuring a tight fit. Note: Users are advised to ensure that the weatherproof seals are secured firmly in place. D-Link DCS-6314 User Manual...
-
Page 13: Deploying The Camera
Step 2 Use a 6mm drill bit to make required holes approximately 30mm deep. Step 3 Remove the Alignment Sticker. Step 4 Insert wall anchors and affix the mounting plate using the screws provided. D-Link DCS-6314 User Manual... - Page 14 Section 2: Assembly and Installation Step 5 Fasten the camera firmly to the mounting plate using the screw provided ensuring clear passage for the cables through the cable channel or via the mounting plate cut-out. D-Link DCS-6314 User Manual...
-
Page 15: Mounting The Camera
Section 2: Assembly and Installation Mounting the Camera The DCS-6314 is suitable for mounting to a wall using the camera shoe and wire-in bracket provided. Step 1 Remove the top part of the camera housing by using the included tool to unscrew the three retaining screws. - Page 16 Slide the lower half of the camera housing onto the mounting plate and resecure it. Make sure that the cable sheath extends out of the base in such a way that the cable is not kinked or twisted. D-Link DCS-6314 User Manual...
- Page 17 Section 2: Assembly and Installation Step 5 Reattach the top part of the camera housing, and secure it by tightening the three retaining screws. Step 6 If necessary, the included weather shield can now be attached to the camera. D-Link DCS-6314 User Manual...
-
Page 18: Attaching The Camera To The Pendant Mount
"Deploying the Camera" Rubber Seal on page 13. Pendant Bracket Step 3 Attach the bracket cap, by screwing it onto the pendant bracket. Bracket Cap D-Link DCS-6314 User Manual... - Page 19 If necessary, the included weather shield can now be attached to the camera. Please see step 6 of "Mounting the Camera" on page 15 for more details on how to do this. D-Link DCS-6314 User Manual...
-
Page 20: Attaching The Camera To The Bent Mount
Securely mount the rubber seal and pendant bracket to the ceiling, if you need more details please see "Deploying the Camera" on page 13. Step 3 Bent Attach the bracket cap, by screwing it onto the pendant bracket. Bracket Bracket D-Link DCS-6314 User Manual... - Page 21 If necessary, the included weather shield can now be attached to the camera. Please see step 6 of "Mounting the Camera" on page 15 for more details on how to do this. D-Link DCS-6314 User Manual...
-
Page 22: Orienting The Camera
Section 2: Assembly and Installation Orienting the Camera The DCS-6314 can be adjusted to ensure an optimal viewing position when mounted to a wall by following the steps outlined. Step 1 Turn the lens module left and right until the desired position is achieved. -
Page 23: Camera Installation Wizard
Camera Installation Wizard General Connection Using 12 V DC Power Adapter Step 1 Connect the network camera to a hub via an Ethernet cable. Step 2 Connect the supplied power cable from the camera to a power outlet. D-Link DCS-6314 User Manual... -
Page 24: Connection Using Power Over Ethernet
Connection Using Power over Ethernet Step 1 If you are using a PoE hub, connect the IP camera to the hub via an Ethernet cable, which will provide transmission of both power and data over a single cable. D-Link DCS-6314 User Manual... -
Page 25: Software Installation
Camera Installation Wizard. Step 3 Select your camera from the list, then click Wizard. If you have multiple cameras, you can identify them by the MAC ID printed on the label on the back of your camera. D-Link DCS-6314 User Manual... - Page 26 Enter the correct configuration information and click Next to continue. Note: Select DHCP if you are unsure of which settings to choose. Click Next to continue. D-Link DCS-6314 User Manual...
- Page 27 Step 6 Confirm your camera login details and IP address details and click Restart. The LED on the front of the DCS-6314 will blink, then turn solid green once it successfully connects to your network.. Step 7 Your DCS-6314 camera is now set up, Click Exit to exit the wizard and can skip to "Configuration"...
-
Page 28: D-Viewcam Setup Wizard
Section 2: Assembly and Installation D-ViewCam Setup Wizard D-ViewCam software is included for the administrator to manage multiple D-Link IP cameras remotely. You may use the software to configure all the advanced settings for your cameras. D-ViewCam is a comprehensive management tool for IP surveillance. - Page 29 Section 2: Assembly and Installation Step 3 Click Finish to complete the installation. Step 5 For more detail operation of using the D-ViewCam software, please refer to D-ViewCam Manual. D-Link DCS-6314 User Manual...
-
Page 30: Configuration
The camera’s built-in Web configuration utility is designed to allow you to easily access and configure your DCS-6314. At the end of the wizard, click Link, or enter the IP address of your camera into a web browser, such as Mozilla Firefox. -
Page 31: Live Video
"Audio and Video" on page 45. Language: You may select the interface language using this menu. Go To: If any presets have been defined, selecting a preset (Preset List) from this list will display it. D-Link DCS-6314 User Manual... - Page 32 Enable or disable the ability to listen through the built in Listening microphone. Talk/Stop Talking Enable or disable the ability to speak through the built in speaker. Start/Stop Digital Enable or disable the ability to use the built in digital in/out port. Output D-Link DCS-6314 User Manual...
-
Page 33: Setup
To quickly configure your Network Camera’s motion detection settings, click Motion Detection Setup Wizard. If you want to enter your settings without running the wizard, click Manual Motion Detection Setup and skip to"Motion Detection" on page 49. D-Link DCS-6314 User Manual... -
Page 34: Internet Connection Setup Wizard
Internet Connection Setup Wizard This wizard will guide you through a step-by-step process to configure your new D-Link Camera and connect the camera to the internet. Click Next to continue. Note: Select DHCP if you are unsure of which settings to choose. - Page 35 If you have a Dynamic DNS account and would like the camera to update your IP address automatically, Select Enable DDNS and enter your host information. Click Next to continue. Enter a name for your camera and click Next to continue. D-Link DCS-6314 User Manual...
- Page 36 Configure the correct time to ensure that all events will be triggered as scheduled. Click Next to continue. Confirm the settings are correct and click Apply to save them. The settings will be saved to the DCS-6314 and the camera will restart. D-Link DCS-6314 User Manual...
-
Page 37: Motion Detection Setup Wizard
This UI element should be inside like the other steps Step 2 This step allows you to enable motion detection based on a customized schedule. Specify the day and hours. You may also choose to always record whenever motion is detected. D-Link DCS-6314 User Manual... - Page 38 Click Next to continue. Step 4 You have completed the Motion Detection Wizard. Please verify your settings and click Apply to save them. Please wait a few moments while the camera saves your settings and restarts. D-Link DCS-6314 User Manual...
-
Page 39: Network Setup
Enabling this setting allows your camera to be Presentation: configured as a UPnP device on your network. Enable Enabling this setting allows the camera to add port UPnP Port forwarding entries into the router automatically on Forwarding: a UPnP capable network. D-Link DCS-6314 User Manual... - Page 40 Enabling QoS allows you to specify a traffic priority policy to ensure a consistent Quality of Service during busy periods. If the Network Camera is connected to a router that itself implements QoS, the router's settings will override the QoS settings of the camera. D-Link DCS-6314 User Manual...
- Page 41 Enabling the option allows you to manually set up the address, specify an optional IP address, specify an optional router and an optional primary DNS. Enable The DCS-6314 allows you to multicast each of the Multicast for available streams via group address and specify the stream: TTL value for each stream.
-
Page 42: Dynamic Dns
DDNS account. Password: Enter the password used to connect to your DDNS server account. Timeout: Enter the DNS timeout values you wish to use. Status: Indicates the connection status, which is automatically determined by the system. D-Link DCS-6314 User Manual... -
Page 43: Image Setup
White Balance: Use the drop-down box to change white balance settings to help balance colors for different environments. You can choose from Auto, Outdoor, Indoor, Fluorescent, and Push Hold. Changes the exposure mode. Use the drop-down D-Link DCS-6314 User Manual... - Page 44 WDR Level: Specify a value from 0 to 10 to specify how much WDR to apply to the image, or select None. Reset Default: Click this button to reset the image to factory default settings. D-Link DCS-6314 User Manual...
-
Page 45: Audio And Video
Mode: Set the video codec to be used to JPEG, MPEG-4, or H.264. Frame size / The field of view for the DCS-6314 is fixed based on View window its mounted orientation. The ePTZ function requires area: that the frame size is larger than the view window area in order to allow the user to pan, tilt, and zoom within the image. - Page 46 Audio out off: Selecting this checkbox will mute outgoing audio. Audio out This setting controls the amount of gain applied volume level: to outgoing audio to increase its volume. D-Link DCS-6314 User Manual...
-
Page 47: Preset
Click this drop-down box to see a list of all the presets that have been created. You can select one, then click the GoTo button to change the displayed camera view to the preset. Clicking the Remove button will delete the currently selected preset. D-Link DCS-6314 User Manual... - Page 48 Clicking the trash can button will remove the currently selected preset from the sequence. If you want to change the dwell time for a preset, select it from the list, enter a new dwell time, then click the Update button. D-Link DCS-6314 User Manual...
-
Page 49: Motion Detection
Right clicking on the camera image brings up the following menu options: Select All: Draws a motion detection area over the entire screen. Clear All: Clears any motion detection areas that have been drawn. Restore: Restores the previously specified motion detection areas. D-Link DCS-6314 User Manual... -
Page 50: Time And Date
Enable this feature to obtain time automatically from an NTP server. Synchronize Network Time Protocol (NTP) synchronizes the with NTP DCS-6314 with an Internet time server. Server: NTP Server: Choose the one that is closest to your location. Set the Date... -
Page 51: Event Setup
Event Setup In a typical application, when motion is detected, the DCS-6314 sends images to a FTP server or via e-mail as notifications. As shown in the illustration below, an event can be triggered by many sources, such as motion detection. When an event is triggered, a specified action will be performed. - Page 52 2. To delete the selected item from the pull-down menu of event, server or media, click Delete. 3. Click on the item name to pop up a window for modifying. D-Link DCS-6314 User Manual...
-
Page 53: Add Server
Enter the configuration for the target e-mail server account. FTP: Enter the configuration for the target FTP server account. Network Specify a network storage device. Only one Storage: network storage device is supported. SD Card: Use the camera's onboard SD card storage. D-Link DCS-6314 User Manual... -
Page 54: Add Media
You can set up to 7 post-event images to be taken. File name The prefix name will be added on the file name. prefix: SNAPSHOTS20080104_100341 Date and time suffix File name prefix The format is: YYYYMMDD_HHMMSS D-Link DCS-6314 User Manual... - Page 55 Set the maximum file size to record for your video clips. size: System log: Select this option to set the media type to system logs. This will save the event to the camera system log, but will not record any snapshots or video. D-Link DCS-6314 User Manual...
-
Page 56: Add Event
Triggers an event when the system boots up. Network Lost: Triggers an event when the network connection is lost. Time: Select Always or enter the time interval. Trigger D/O: Specify the amount of time in seconds if an event is triggered D-Link DCS-6314 User Manual... -
Page 57: Add Recording
Select this to enable the recording function. recording: Priority: Set the priority for this entry. The entry with a higher priority value will be executed first. Source: The source of the stream. Recording Scheduling the recording entry. schedule: D-Link DCS-6314 User Manual... - Page 58 If this is selected, files will be separated based on each file for the maximum length you specify. recording: File Name The prefix name will be added on the file name of Prefix: the recording file(s). D-Link DCS-6314 User Manual...
-
Page 59: Sd Card
If video files are stored on the SD card, click on the Recorded video folder and choose the video file you would Video: like to view. Refresh: Reloads the file and folder information from the SD card. D-Link DCS-6314 User Manual... -
Page 60: Advanced
Therefore events are triggered when the device status changes to "Closed." LED: You may specify whether or not to illuminate the status LED on the camera. Video Output: Enable/ disable the BNC terminal TV output signal. D-Link DCS-6314 User Manual... -
Page 61: Icr And Ir
The IR light will always be on. Sync: The IR light will turn on when the ICR sensor is on. Schedule: The IR light will turn on or off according to the schedule that you specify below. D-Link DCS-6314 User Manual... -
Page 62: Https
Create a certificate request and install Status: Displays the status of the certificate. Note: The certificate cannot be removed while the HTTPS is still enabled. To remove the certificate, you must first uncheck Enable HTTPS secure connection. D-Link DCS-6314 User Manual... -
Page 63: Access List
When the range of the Allowed List is set from 1.1.1.0 to 192.255.255.255 and the range of the Denied List is set from 1.1.1.0 to 170.255.255.255. Only users with IPs located between 171.0.0.0 and 192.255.255.255 can access the Network Camera. D-Link DCS-6314 User Manual... -
Page 64: Maintenance
Enter a label for the camera, which will be shown on the OSD when it is enabled. Show Time: Select this option to enable the time-stamp display on the video screen. LED: Select whether to turn the camera LED on or off. D-Link DCS-6314 User Manual... -
Page 65: System
Browse and then restore the pre-defined settings Drive: to your camera by clicking Load Configuration. Restore You may reset your camera and restore the factory to Factory settings by clicking Restore Factory Defaults. Default: Reboot Device: This will restart your camera. D-Link DCS-6314 User Manual... -
Page 66: Firmware Upgrade
Section 3: Configuration Firmware Upgrade The camera's current firmware version will be displayed on this screen. You may visit the D-Link Support Website to check for the latest available firmware version. To upgrade the firmware on your DCS-6314, please download and save the latest firmware version from the D-Link Support Page to your local hard drive. -
Page 67: Status
Section 3: Configuration Status Device Info This page displays detailed information about your device and network connection. D-Link DCS-6314 User Manual... -
Page 68: Logs
Section 3: Configuration Logs This page displays the log information of your camera. You may download the information by clicking Download. You may also click Clear to delete the saved log information. D-Link DCS-6314 User Manual... -
Page 69: Help
Section 3: Configuration Help This page provides helpful information regarding camera operation. D-Link DCS-6314 User Manual... -
Page 70: Di/Do Specifications
Appendix A: DI/DO Specifications DI/DO Specifications D-Link DCS-6314 User Manual... -
Page 71: Technical Specifications
• DNS client • CoS • Multicast • DDNS client (D-Link) • SMTP client • ONVIF compliant • FTP client Security • Administrator and user group protection • HTTP and RTSP digest encryption • Password authentication D-Link DCS-6314 User Manual... - Page 72 • Operating: -30 to 50 °C (-22 to 122 °F) • Storage: -20° to 70° C (-4° to 158° F) • Operating: 20% to 80% non-condensing • Storage: 5% to 95% non-condensing Humidity • CE • FCC Certifications • CE LVD • C-Tick D-Link DCS-6314 User Manual...
- Page 73 Full HD Outdoor Fixed Dome Network Camera Pendant Mount DCS-34-2 201 x 150 mm (7.9 x 5.9 inches), 665 grams (1.45 lbs) Optional Accessories Bent Arm Mount DCS-34-3 253 x 150 mm (9.96 x 5.9 inches), 770 grams (1.7 lbs) D-Link DCS-6314 User Manual...
