RIDGID TP-4000 User Manual

Transfer Pump
*
Motor Housing
Identifcation
1
10*
TP-5500
TP-4000
Ref. Catalog Catalog
No. No. No.
1 88492 88497
2 88502 88507
3 88512 88517
4 88522 88527
5 88532 88537
6 88542 88542
7 88547 88552
8 16743 16748
9 16753 16758
10* 16763 16768
11 16773 16778
* Refer to Motor Housing Identification (TX2 or WKT2) For
Proper Seal Plate. Seal Plates Are Not Interchangable.
Ridge Tool Company/Elyria, Ohio, U.S.A.
2
7
8
9
Description
Engine
Shaft Seal Kit
Suction Flange
Flapper Check Valve
Discharge Flange Kit
Drain/Fill Plug
Impeller
Wear Plate
Volute Seal
Seal Plate (TX2)
Seal Plate (WKT2)
TP-4000
TP-5000
6
5
4
3
6
127
