- Page 1 X-Treme Electric Scooters Model: X-400 Product Handbook (photos may vary) Page1...
-
Page 2: Important Nformation
Failure to follow these INSTRUCTIONS will VOID YOUR WARRANTY! This PRODUCT IS NOT INTENDED FOR EXTREME or OFF-ROAD Use! Please take care of your X-400! DO NOT JUMP or ABUSE THIS PRODUCT! DO NOT RIDE IN WET/ICY CONDITIONS! Failure to follow these instructions will... - Page 3 IMPORTANT PLEASE READ THIS BEFORE USING THIS PRODUCT READ THIS FIRST! WARNING This product does not conform to Federal Motor Vehicle Standards and is not intended for operation on public streets, roads or highways. Serious injury can result from the unsafe operations of this product. Operator can minimize these risks by using certain safety equipment such as: safety helmet, goggles, gloves, elbow and kneepads and appropriate footwear.
-
Page 4: Quick Reference
Avoid unintentional starts by turning the scooter off while not in use. To avoid the risk of a short circuit in the electrical parts, do not use your X-Treme Electric scooter in the rain and never spray or wash off your scooter with water. ... -
Page 5: Table Of Contents
TABLE OF CONTENTS IMPORTANT NFORMATION…………………………………….………………2-3 QUICK REFERENCE……………………………………………………………….4 TABLE OF CONTENTS……………………………….…………….………………5 GETTING TO KNOW YOUR X-TREME X-400…………………………………..6 PACKAGE CONTENTS…………………………………………………………….7 GETTING STARTED/ASSEMBLY..……………………………..………………..7 CHARGING…………….…………………………………………………………….8 RIDING…………………….……….………………………..……………………….9 STOPPING AND BRAKING. …………………………………….…………………9 FOLDING & STORAGE………………………………………………………..……9 BRAKING SYSTEM…………..…………………………………….…………….…9 ADJUSTING THE BRAKES……….…………….………………………..……9-10 TIRES……………………………………………………….………………………11 BATTERIES…………………..……………………………………...……………..11 MAINTENANCE…….….…………………………………………………………..11 ADJUSTING THE CHAIN………………………...……………………………….11 MAINTENANCE SCHEDULE…………………………………………………….12... -
Page 6: Getting To Know Your X-Treme X-400
GETTING TO KNOW YOUR X-TREME X-400 (Photo’s may vary) Page6... -
Page 7: Package Contents
PACKAGE CONTENTS Your X-Treme X-400 comes with the following items in the box. Please locate all of the following: The X-Treme X-400 Scooter 36V Battery Charger Tool Kit Product Handbook Seat & Seat Post GETTING STARTED Please read and understand these instructions and the OPERATING... -
Page 8: Charging
Fig. 4 Fig. 5 Fig. 6 Fig. 7 Charging Your scooter comes charged out of the carton. We still recommend charging the unit for 8-10 hours prior to it’s first use. We also recommend charging your scooter after each use and prior to storage. WARNING: Do not allow your scooter to go into deep discharge, as this will damage the batteries. -
Page 9: Riding
BRAKING SYSTEM The X-400 uses a pinch braking system for the front, and a hub system for the rear. They are both activated by a hand brake lever on the left and right side of the handlebar. Squeezing the hand brake lever with your left hand activates the rear brake. Squeezing the hand brake lever with your right hand activates the front brake. - Page 10 To adjust the Rear Brakes: For brakes that are adjusted too tight: 1. Loosen the tension screw on the left right hand brake lever by rotating it counter-clockwise until the wheel spins freely. (Fig. 11) Fig. 11 For brakes that are adjusted too loose: 2.
-
Page 11: Tires
Batteries The X-400 is a 36V system. The batteries are located under the footplate of the scooter. Should you need to service the batteries, simply unscrew the two bolts that hold the footplate down and raise the plate. -
Page 12: Maintenance Schedule
For additional questions, service instructions, further information and important phone numbers, please go to the X-Treme website at www.x-tremescooters.com Thank you for purchasing an X-Treme X-400 and please tell your friends how much fun you’re having on the X-Treme X-400... -
Page 13: General Information/Tech Support
For General Information or Parts Visit www.x-tremescooters.com For Technical Support or Assistance Visit www.x-tremescooters.com/support/ Page13...
