SV Photo Capture

SV Photo Capture
SV Photo Capture can be used to control the VIEWCAM
connected to the computer from the computer and capture images
being displayed on the LCD screen in the Camera mode, or
images recorded on tapes in the Tape Playback mode into the
computer as still pictures.

Preparations

1
Connect the VIEWCAM to the computer.
• For details on connections, refer to the operation manual
of your VIEWCAM.
2
Turn on the VIEWCAM's power and set it to the Camera
or VCR mode.

Launching SV Photo Capture

3
Select the "Program" menu from "Start" on the task
bar, then click on "SV Photo Capture" in the "PixLab
Lite" folder, or double click the short-cut icon on the
desktop.
• SV Photo Capture is launched.
COM Port Settings
G This software automatically searches for and selects the COM port assigned
for serial connection and there is no need to specify the port.
G If the connection cannot be set automatically, click the
the assigned serial port and transfer speed in the connection settings dialog
box and then try again. For details on the serial port and transfer speed
settings, refer to the operation manual of your computer.
Edge Smoothing
OFF button
Use this to capture
images without
correction.
Capture button
Use this button to start
capturing images from
the VIEWCAM.
Display window
The image is
displayed here as it is
being captured.
Cancel button
Click this to cancel
the image capture.
Control buttons (VCR mode)
icon, change
Note
3
CONTENTS
CONTENTS PREVIOUS PAGE
PREVIOUS PAGE
Edge smoothing AUTO button
Use this to capture images
with correction.
Use this to play in the reverse direction.
Use this to play in the forward direction.
Use this to stop.
Use this to pause playback and display a still image.
Use these for slow playback.
Use these during still image playback for frame-by-frame
playback.
Use these to fast-forward and rewind the tape. During
playback, use them for forward and reverse search.
G If your VIEWCAM is not equipped for the operations described
above, these operations cannot be performed with SV Photo
Capture.
G SV Photo Capture cannot be launched while SV Card Link is running.
NEXT PAGE
NEXT PAGE
Connection
settings button
Use this to set the
serial port and transfer
speed.
Exit button
Use this to close the
SV Photo Capture
dialog.
Mode select
buttons
Camera mode:
Mode for capturing
images currently
being displayed on
the VIEWCAM's LCD
screen.
Video mode:
Mode for capturing
images from the tape
currently playing on
the VIEWCAM.
Zoom buttons
(Camera mode)
Use these to zoom in
and out.
