Table 2-19 Power Requirements and Heat Dissipation—Miscellaneous Modules
Model Number/
Module Type
WS-X6066-SLB-APC
Content Switching Module
Table 2-20
configuration:
•
•
•
Table 2-20
Model Number/
Module Type
Cisco 7603 Router chassis
(with fans)
WS-X6K-S2U-MSFC2
OSM-4OC12-POS-MM
OC-12 module 4-port
Total

Power Requirements

Read the installation instructions before connecting the system to the power source.
Warning
Follow these requirements when preparing your site for the router installation:
•
•
•
Cisco 7600 Series Router Installation Guide
2-20
Module Module
Current (A) Power
@ 42 VDC (Watts)
3.0 126.0
provides a sample calculation of power and heat dissipation for the following router
Cisco 7603 Router chassis (including AC-input power supplies)
One WS-X6K-S2U-MSFC2 supervisor engine
Two 4-port OC-12 POS modules
Sample Calculation of Router Configuration
AC-Input
Power
(Watts)
88
182
502
751
The redundant power option provides a second, identical power supply to ensure that power to the
chassis continues uninterrupted if one power supply fails or input power on one line fails.
In systems configured with the redundant power option, connect each of the two power supplies to
a separate input power source. If you fail to do this, your system might be susceptible to total power
failure due to a fault in the external wiring or a tripped circuit breaker.
To prevent a loss of input power, be sure that the total maximum load on each circuit supplying the
power supplies is within the current ratings of the wiring and breakers.
AC DC
AC-Input Heat Diss. DC-Input
Power (BTU/HR) Power
(Watts) (Watts)
157.5 537.9 169.35
Input Current
DC-Output
Power Heat Diss. 90 VAC
(Watts) (BTU/HR) (Amps)
34 302 0.98
145 620 2.02
402 1714 5.58
565 2565 8.35
Chapter 2 Preparing for Installation
Heat Diss.
(BTU/HR)
578.35
120 VAC 180 VAC 240 VAC
(Amps) (Amps) (Amps)
0.74 0.49 0.37
1.57 1.01 0.76
4.18 2.78 2.10
6.26 4.16 3.14
