IP Trunk Hash configuration

Command: /cfg/l2/thash
[IP Trunk Hash Menu]
set
cur
The following table describes the IP Trunk Hash Configuration Menu options.
Table 116 IP Trunk Hash Configuration Menu options
Command
set
cur

Layer 2 IP Trunk Hash configuration

Command: /cfg/l2/thash/set
[set IP Trunk Hash Settings Menu]
smac
dmac
sip
dip
cur
Trunk hash parameters are set globally for the GbE2c. You can enable one or two parameters, to configure any of
the following valid combinations:
SMAC (source MAC only)
DMAC (destination MAC only)
SIP (source IP only)
DIP (destination IP only)
SIP + DIP (source IP and destination IP)
SMAC + DMAC (source MAC and destination MAC)
The following table describes the IP Trunk Hash Configuration Menu options.
Table 117 IP Trunk Hash Set Menu options
Command
smac enable|disable
dmac enable|disable
sip enable|disable
dip enable|disable
cur

Link Aggregation Control Protocol configuration

Command: /cfg/l2/lacp
[LACP Menu]
sysprio
timeout
port
cur
- IP Trunk Hash Settings Menu
- Display current IP trunk hash configuration
Description
Displays the Trunk Hash Settings menu.
Display current trunk hash configuration.
- Enable/disable smac hash
- Enable/disable dmac hash
- Enable/disable sip hash
- Enable/disable dip hash
- Display current trunk hash setting
Description
Enable or disable trunk hashing on the source MAC.
Enable or disable trunk hashing on the destination MAC.
Enable or disable trunk hashing on the source IP.
Enable or disable trunk hashing on the destination IP.
Display current trunk hash configuration.
- Set LACP system priority
- Set LACP system timeout scale for timing out partner info
- LACP port Menu
- Display current LACP configuration
Configuration Menu 120
