NOTE:
IEEE 802.1w standard-based RSTP implementation runs on one STG (i.e. same as one spanning tree
instance) only. As a result, if 'rstp' mode is selected under the /cfg/mrst/mode command, then only a
single RSTP instance (default for STG 1) is supported for all VLANs, including the Default VLAN 1.
If multiple spanning tree instances are required, then select 'mstp' mode so that multiple VLANs are
handled by multiple spanning tree instances, as specified by IEEE 802.1s standard-based MSTP
implementation.
IEEE 802.1s MSTP supports rapid convergence using IEEE 802.1w RSTP.
PVST+ does not support rapid convergence in current versions.
NOTE:
The following configurations are unsupported:
HP PVST+ (default Spanning Tree setting) is NOT interoperable with Cisco Rapid PVST+.
HP MSTP/RSTP (with mode set to either 'mstp' or 'rstp') is NOT interoperable with Cisco Rapid PVST+.
The following configurations are supported:
HP PVST+ (default Spanning Tree setting) is interoperable with Cisco PVST+.
HP MSTP/RSTP (with mode set to 'mstp') is interoperable with Cisco MST/RSTP.

Common Internal Spanning Tree configuration

Command: /cfg/l2/mrst/cist
[Common Internal Spanning Tree Menu]
brg
port
add
default - Default Common Internal Spanning Tree and Member parameters
cur
The Common Internal Spanning Tree (CIST) provides compatibility with different MSTP regions and with devices
running different Spanning Tree instances. It is equivalent to Spanning Tree Group 0.
The following table describes the commands used to configure Common Internal Spanning Tree Configuration Menu
options.
Table 107 Common Internal Spanning Tree Configuration Menu options
Command
brg
port <port number>
add <1-4095>
default
cur
- CIST Bridge parameter menu
- CIST Port parameter menu
- Add VLAN(s) to CIST
- Display current CIST parameters
Description
Displays the CIST Bridge Menu.
Displays the CIST Port Menu.
Adds VLANs to the CIST. Enter one VLAN per line, and press Enter to add the VLANs.
Resets all CIST parameters to their default values.
Displays the current CIST configuration.
Configuration Menu 113
