Chapter 3
Installing the Clean Access Manager and Clean Access Server
Specify VLAN passthrough behavior for traffic passing from the untrusted to the trusted network. At the
Step 15
prompt, type
to enable VLAN ID passthrough for traffic from the untrusted network.
[Vlan Id Passthrough] for packets from eth1 to eth0 is disabled.
Would you like to enable it? (y/n)? [n]
Figure 3-9
Specify Management VLAN Tagging for the untrusted interface at the next prompt. Type
Step 16
Enter (or just press Enter) to keep Management VLAN tagging disabled (default). Or, type
Enter to enable Management VLAN tagging and specify the Management VLAN ID to use for the CAS
untrusted interface.
[Management Vlan Tagging] for egress packets of eth1 is disabled.
Would you like to enable it? (y/n)? [n]
Note
OL-20326-01
and press Enter (or just press Enter) to accept the default behavior (disabled) or enter
n
VLAN ID Passthrough
Untrusted network
VLAN
ID
You can change the Management VLAN ID later from the CAS Network > IP web console
page; however, changing settings on the CAS IP page requires a reboot of the CAS.
Trusted network
Clean Access
Server
Cisco NAC Appliance Hardware Installation Guide
Installing the Clean Access Server
VLAN
ID
and press
N
and press
Y
3-29
y
