5-12 System Unit Repair
4. Remove the two screws securing the power button to the front of the system unit
(see Figure 5-13).
5. Remove the four screws holding the power supply to the system unit (see
Figure 5-14).
6. Slide the power supply toward the system board to release the two tabs at the
front, then lift it out of the system unit.
Figure 5-13 Power Button Screws
Figure 5-14 Power Supply Screws
Power Button
Screws
Power Supply
Screws
