Tripp Lite APS 1024 INT Owner's Manual

200208166 93-2079 APS-PV Remote II-DR Owner's Manual.qxd
Owner's Manual
Remote Control Module
for use with select
PowerVerter Inverters (PV series) or
®
PowerVerter
®
(APS, RV or EMS series)
The Remote Control Module allows you to remotely monitor and control many of the functions of
select* Tripp Lite PowerVerter PV Inverters and PowerVerter APS, RV or EMS Inverter/Chargers.
* Only those models featuring an RJ45 Remote Port.
Installation
Labeling: Affix the appropriate label to the front panel of the Remote Control Module so that the
holes in the label align with the Module's LEDs and switch.** If your Remote Control Module will
be used with a PowerVerter . . .
• INVERTER (PV series) ....................................................choose the label marked "PV"
• INVERTER/CHARGER (APS or RV** series) ............choose the label marked "APS"
** EMS series Inverter/Chargers will already have the appropriate labeling and will not require a separate label.
Connection (Remote Control/Monitoring): Connect one end of the included RJ-type cable into
the RJ45 Remote Port on the front of your PowerVerter Inverter or Inverter/Charger. Connect the
other end into either of the two RJ45 Remote Ports on the bottom of the Remote Control Module.
Daisychain capability: You can control a single PowerVerter Inverter or Inverter/Charger
with two separate Remote Control Modules. Connect one Remote Control Module directly
to the PowerVerter as described above. Connect either of the two RJ45 Remote Ports on the
bottom of the second Remote Control Module directly to the remaining RJ45 Remote Port
on the bottom of the first Remote Control Module using an RJ-type cable, included.
Optional Connection (Ignition Lockout—Select Models Only): Ignition Lockout automatically
switches off your PowerVerter when a vehicle's ignition is turned off. This connection is optional;
the Remote Control Module will function without this connection. Connect one end of the Ignition
Lockout Cable (included with select models) into the Ignition Lockout Port and wire the other end
to the vehicle's ignition: red to positive, black to ground.
THE IGNITION LOCKOUT FUNCTION IS ONLY FOR USE
Wiring the Ignition Lockout Cable to your vehicle's ignition requires a qualified technician,
Mounting: Using two to four user-supplied screws appropriate to your mounting surface, attach the
Remote Control Module securely so that the LEDs can be clearly seen.
Copyright © 2002 Tripp Lite. All rights reserved. PowerVerter
Inverter/Chargers
WARNING!
WITH 12V NEGATIVE GROUND SYSTEMS.
who must determine the proper wiring procedure.
9/9/2002
1111 W. 35th Street Chicago, IL 60609 USA
Customer Support: (773) 869-1234 • www.tripplite.com
® is a registered trademark of Tripp Lite.
4:07 PM Page 1
