grandMA3 User Manual – Single User and Multi User Systems
Version 1.5 – 2022-12-27
English
User Settings
There are a lot of settings connected to the User and the User Profile.
User Settings
There are eight different user settings.
Name:
This is the name of the user. This is the login name used with the Login keyword.
Scribble:
A user can have a scribble assigned. The scribble is only used in the User pool.
Appearance:
A user can have an appearance. The appearance is used in the user pool and when the station is locked.
Password:
This is an optional password that can be set to the user. It needs to be provided when the user is logging in.
Profile:
Each user has a User Profile assigned. Read more below.
ScreenConfig:
Different screen configurations can be created. This is the configuration called when the user logs in.
Rights:
There are six different levels of rights. Read more below.
Language:
The user can have a language setting. This is used to select one of the available languages. Nothing is currently
translated, so changing the language does not change anything.
Keyboard:
The on-screen keyboard can have different layouts. This setting can be used to select one of the available layouts.
There are two places in the GUI where the settings can be viewed and edited. The settings are the same.
The first place is the Users pool. Editing a pool object opens an editor where the settings can be changed. Learn more
about the Users pool in the Create User topic.
The second place is the User Configuration. Navigate to it using these steps:
1. Press the
Menu
2. Tap the
Settings
3. Tap the
User Configuration
This opens the list of users in the show. Edit any field to change the setting.
© 2022 MA Lighting Technology GmbH - Dachdeckerstr. 16 - 97297 Waldbüttelbrunn - Germany
Phone +49 5251 688865-30 - support@malighting.com - www.malighting.com
key.
button.
button.
1 of 8

Advertisement

loading

Related Manuals for MA grandMA3

Summary of Contents for MA grandMA3

  • Page 1 This opens the list of users in the show. Edit any field to change the setting. © 2022 MA Lighting Technology GmbH - Dachdeckerstr. 16 - 97297 Waldbüttelbrunn - Germany 1 of 8 Phone +49 5251 688865-30 - support@malighting.com - www.malighting.com...

  • Page 2: User Profile Settings

    This setting is also in the Encoder Bar. It is used when working with Phasers. It turns off the looping function of the phaser to make it easier to edit a single step in the phaser. © 2022 MA Lighting Technology GmbH - Dachdeckerstr. 16 - 97297 Waldbüttelbrunn - Germany 2 of 8...
  • Page 3 Mirror SpecialExecutor Pages: This setting is for the custom section of the grandMA3 extension. If the setting is "Yes" then the extension has the same assignment as the custom section of the station the extension is connected to. If the setting is "No", then each extension can have its own assignments in the custom section.

  • Page 4: Wheel Mode

    The encoder resolution defines how big the change of an attribute value will be when turning a dual encoder by 1 click. This setting can also be changed by pressing MA and tapping the channel function area in the encoder toolbar. Learn how in the Encoder Resolution topic.
  • Page 5 When using the level wheel to turn up the dimmer values, the difference in the dimmer values will increase. Turning down the values will make all channels reach 0% at the same time. © 2022 MA Lighting Technology GmbH - Dachdeckerstr. 16 - 97297 Waldbüttelbrunn - Germany 5 of 8...

  • Page 6: User Rights

    Time and Frame Readout The applied values are used most places the time is displayed. © 2022 MA Lighting Technology GmbH - Dachdeckerstr. 16 - 97297 Waldbüttelbrunn - Germany 6 of 8 Phone +49 5251 688865-30 - support@malighting.com - www.malighting.com...
  • Page 7 24 if time is more than a day. The frame options are: Seconds 24 fps 25 fps 30 fps 60 fps © 2022 MA Lighting Technology GmbH - Dachdeckerstr. 16 - 97297 Waldbüttelbrunn - Germany 7 of 8 Phone +49 5251 688865-30 - support@malighting.com - www.malighting.com...
  • Page 8 If frame readouts (24, 25, 30, 60 fps) are used, fractions are separated by a colon, fractions of seconds are divided by dots. Fps means frames per second. © 2022 MA Lighting Technology GmbH - Dachdeckerstr. 16 - 97297 Waldbüttelbrunn - Germany 8 of 8 Phone +49 5251 688865-30 - support@malighting.com - www.malighting.com...
