Grizzly T32730 Instructions

For questions or help with this product contact Tech Support at (570) 546-9663 or techsupport@grizzly.com
Introduction
The Model T32730 Outboard Turning Attachment
is designed to fit on the Model G0733/G0766
lathes. The 22 ⁄ " bed extension can be installed
3
4
to support a tool rest and replace a floor-mounted
tool post for outboard turning operations.
Inventory
Description (Figure 1)
A. Bed Extension ............................................ 1
B. Tool Rest Base 1" ....................................... 1
C. Tool Rest Arm 1" ........................................ 1
D. Outboard Extension Shaft .......................... 1
E. Hex Wrench 8mm ....................................... 1
F.
Adjustable Handles M10-1.5 x 18, 70L ....... 3
G. Cap Screws M10-1.5 x 25 .......................... 3
A
D
C
F
Figure 1. Inventory.
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
B
E
G
COPYRIGHT © MAY, 2022 BY GRIZZLY INDUSTRIAL, INC.
NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
(FOR MODELS MFD. SINCE 01/22) #CS22255 PRINTED IN CHINA
***Keep for Future Reference***
OUTBOARD TURNING
ATTACHMENT FOR G0733/G0766
Installation
Refer to Outboard Turning in the Model G0733/
G0766 Owner's Manual to remove the tailstock
Qty
and position the headstock for outboard turning
operations.
To install outboard turning attachment:
1.
Attach bed extension to lathe with (3) M10-
1.5 x 25 cap screws (see Figure 2).
Figure 2. Bed extension attached to lathe.
MODEL T32730
INSTRUCTIONS
Wear safety glasses during
the entire setup process!
x 3
Bed Extension
V1.05.22
