Linksys SPA9000 Product Data

IP Telephony System
Full Featured IP PBX System
for the Small Business and
Home Office
The SPA9000 marries the rich feature set of
high-end PBX telephone systems with the
convenience and cost advantages of Voice
over IP. It has common voice system
features such as an auto-attendant, shared
line appearances, three way call
conferencing, intercom, music on hold,
call-forwarding and much more. The
SPA9000 opens up access to the benefits of
VoIP, including low cost long distance
service, telephone number portability, and
one network for both voice and data.
The SPA9000 is so easy to configure that a
fully working system can be set up in
minutes. New telephones are
automatically detected and registered
when they are connected to the SPA9000.
The SPA9000 has an integrated web server
that allow features to be configured using a
web browser. The web server has multiple
levels of password protected access to user and service level features. Service level settings
may be locked by the Internet Telephone Service Provider to ensure they are not
inadvertently corrupted. The Internet Telephone Service Provider also can remotely update
the software and settings through a secure encrypted connection.
With its integrated router, the SPA9000 can be either connected directly to the internet
connection or to another router on your network. The SPA9000 has separate WAN and LAN
Ethernet ports. The WAN connection can be connect through DHCP or a fixed IP address. The
LAN port can assign IP addresses to IP telephones and computers using NAT and DHCP.
While the SPA9000 will work with any SIP compatible IP telephone, it is the ideal host for
Linksys business telephones, such as the SPA901, SPA921, SPA922, SPA941, and SPA942.
Powerful configuration capabilities enable the SPA9000 to support a greater set of advanced
features with these telephones, such as shared line appearances, hunt groups, call transfer,
call parking lot, and group paging. With its two FXS ports, the SPA9000 can support traditional
analog devices such as telephones, answering machines, FAX machines, and media adapters.
The SPA9000 initially supports four (4) SIP compatible IP Phones and is upgradeable to sixteen
(16) IP Phones total per SPA9000 with an easy to install license key upgrade.
PRODUCT DATA
IP PBX system with high-end
features comparable to
traditional large business voice
services
Initial support of 4 SIP
compatible IP Phones per
SPA9000 is upgradeable to 16
with an easy to install license
key
Powerful self-configuration
capabilities enabled with
Linksys IP telephones
Works with most Internet
Telephone Service Providers
SPA9000
Model No.
