■ WKP-5 ■
PULL-OUT KITCHEN FAUCET
• SINGLE CONTROL
• SOAP DISPENSER
DESMONTABLE MANIJAS PARA LA COCINA
• GRIFO MONOMANDO
• DISPENSADOR DE JABÓN
BRANCHEMENT ROBINET DE CUISINE
• COMMANDE SIMPLE
• DISTRIBUTEUR DE SAVON
