- Page 1 INSTRUCTION MANUAL Cordless Driver Drill FD02 IMPORTANT: Read Before Using.
-
Page 2: Specifications
(Original instructions) SPECIFICATIONS Model FD02 Steel 10 mm (3/8") Wood 21 mm (13/16") Capacities Wood screw 5.1 mm x 63 mm (7/32" X 2-1/2") Machine screw M6 (1/4") High (2) 0 - 1,300/min. No load speed (RPM) Low (1) 0 - 350/min. Chuck capacity 0.8 mm (1/32") - 10 mm (3/8") Overall length... - Page 3 that have the switch on invites accidents. Battery tool use and care 24. Recharge only with the charger specified by 13. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left the manufacturer. A charger that is suitable for attached to a rotating part of the power tool may one type of battery pack may create a risk of fire result in personal injury.
-
Page 4: Functional Description
Do not leave the tool running. Operate the tool Do not expose battery cartridge to water only when hand-held. or rain. Do not touch the drill bit or the workpiece A battery short can cause a large current immediately after operation; they may be flow, overheating, possible burns and extremely hot and could burn your skin. -
Page 5: Switch Action
Speed change This tool is equipped with an electric brake. If the tool consistently fails to quickly stop after switch trigger 1. Speed change release, have tool serviced at a Makita service center. lever Turning on the front lamp 1. Lamp... -
Page 6: Adjusting The Fastening Torque
Hold the tool firmly with one hand on the grip and the Adjusting the fastening torque other hand on the bottom of the battery cartridge to control the twisting action. 1. Pointer 2. Adjusting ring Screwdriving operation 3. Graduation 009333 The fastening torque can be adjusted in 18 steps by turning the adjusting ring so that its graduations are aligned with the pointer on the tool body. -
Page 7: Using Holster
To maintain product SAFETY and RELIABILITY, repairs, screws. any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Using holster Centers, always using Makita replacement parts. CAUTION: Do not use for tools such as a drill with a bit •... - Page 8 Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. Drill bits • Screw bits • Socket bits •...
- Page 9 WARNING Some dust created by power sanding, sawing, grinding, drilling, and other construction activities contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • lead from lead-based paints, •...
