INSTALLATION AND MAINTENANCE INSTRUCTIONS
Velociti Series
®
AOM-2SF Supervised Control Module
SPECIFICATIONS
Normal Operating Voltage:
Maximum Current Draw:
Average Operating Current:
Maximum NAC Line Loss:
External Supply Voltage (between Terminals T10 and T11)
Maximum (NAC):
Maximum (Speakers):
Drain on External Supply:
Max NAC Current Ratings:
Temperature Range:
Humidity:
Dimensions:
Accessories:
RELAY CONTACT RATINGS
CURRENT RATING
2 A
3 A
2 A
0.46 A
0.7 A
0.9 A
0.5 A
0.3 A
BEFORE INSTALLING
This information is included as a quick reference installation guide. Refer to
the control panel installation manual for detailed system information. If the
modules will be installed in an existing operational system, inform the opera-
tor and local authority that the system will be temporarily out of service. Dis-
connect power to the control panel before installing the modules.
NOTICE: This manual should be left with the owner/user of this equipment.
GENERAL DESCRIPTION
AOM-2SF Supervised Control Modules are intended for use in intelligent, two-
wire systems, where the individual address of each module is selected us-
ing the built-in rotary switches. This module is used to switch an external
power supply, which can be a DC power supply or an audio amplifier (up
to 80 VRMS), to notification appliances. It also supervises the wiring to the
connected loads and reports their status to the panel as NORMAL, OPEN, or
SHORT CIRCUIT. The AOM-2SF has two pairs of output termination points
available for fault-tolerant wiring and a panel-controlled LED indicator.
COMPATIBILITY REQUIREMENTS
To ensure proper operation, this module shall be connected to a compatible
Gamewell-FCI system control panels only (list available from Gamewell-FCI).
MOUNTING
The AOM-2SF mounts directly to 4-inch square electrical boxes. (See
Figure 2A.) The box must have a minimum depth of 2
mounted electrical boxes (SMB500 Series) are available. The module can also
mount to the DNR(W) housing.
15 to 32 VDC
6.5 mA (LED on)
375µA (LED flashing - in Velociti® Mode); 350µA (LED flashing - in CLIP mode); 485µA Max. (LED flashing, NAC shorted)
4 VDC
Regulated 24 VDC
70.7 V RMs, 50W
1.7 mA Maximum using 24 VDC supply; 2.2 mA Maximum using 80 VRMS supply
For class B wiring system, the current rating is 3A; For class A wiring system, the current rating is 2A
32°F to 120°F (0°C to 49°C)
10% to 93% Non-condensing
4.675˝ H x 4.275˝ W x 1.4˝ D (Mounts to a 4˝ square by 2
SMB500 Series Electrical Box; CB500 Barrier
MAXIMUM VOLTAGE
25 VAC
30 VDC
30 VDC
30 VDC
70.7 VAC
125 VDC
125 VAC
125 VAC
1 / inches. Surface
8
1 / ˝ deep box.)
8
LOAD DESCRIPTION
PF = 0.35
Resistive
Resistive, NAC, and Door Holder
(L/R = 20ms)
PF = 0.35
Resistive
PF = 0.75
PF = 0.35
WIRING
NOTE: All wiring must conform to applicable local codes, ordinances, and
regulations. When using control modules in nonpower limited applications,
the CB500 Module Barrier must be used to meet UL requirements for the sepa-
ration of power-limited and nonpower-limited terminals and wiring. The bar-
rier must be inserted into a 4˝ × 4˝ × 2
module must be placed into the barrier and attached to the junction box. (See
Figure 2A.)The power-limited wiring must be placed into the isolated quad-
rant of the module barrier. (See Figure 2B.)
1. Install module wiring in accordance with the job drawings and appropri-
ate wiring diagrams.
2. Set the address on the module per job drawings.
3. Secure module to electrical box (supplied by installer). (See Figure 2A.)
Wire should be stripped to the appropriate length (recommended strip length
is 1 / ˝ to 3 / ˝). Exposed conductor should be secured under the clamping plate
4 8
and should not protrude beyond the terminal block area. Caution: Do not loop
wire under terminals. Break wire run to provide supervision of connections.
IMPORTANT: When using the AOM-2SF for audio applications, remove
Jumper (J1) and discard. The Jumper is located on the back as shown in
Figure 1B. J1 must be removed whenever power supply monitoring feature is
not required.
NOTE: All references to power limited represent "Power Limited (Class 2)".
All references to Class A also include Class X.
1
12 Clintonville Road
Northford, CT 06472-1653
Phone: 203.484.7161; Fax: 203.484.7118
www.gamewell-fci.com
APPLICATION
Non-coded
Non-coded
Coded
Non-coded
Non-coded
Non-coded
Non-coded
Non-coded
1
/ ˝ junction box, and the control
8
I56-3550-009
8/16/2021
