Ethernet Port Connector - Cisco Wide Area Virtualization Engine 274 Hardware Installation Manual

Chapter 1 Introducing the Cisco Wide Area Virtualization Engine
Table 1-2 Back Panel LEDs
LED
Ethernet link
Ethernet activity

Ethernet Port Connector

OL-17739-01
Color State
Green On
Green On
Connect a Category 3, 4, or 5 unshielded twisted-pair cable to the Ethernet
connector. 100BASE-TX and 1000BASE-T Fast Ethernet standards require
Category 5 or higher cabling. The WAVE appliance has one Ethernet connector
(see Figure 1-3).
The Ethernet controller is integrated on the system board. It provides an interface
for connecting to a 10-Mbps, 100-Mbps, or 1-Gbps network and provides
full-duplex (FDX) capability, which enables simultaneous transmission and
reception of data on the network. If the Ethernet port in the server supports auto
negotiation, the controllers detect the data-transfer rate (10BASE-T,
100BASE-TX, or 1000BASE-T) and duplex mode (full duplex or half duplex) of
the network and automatically operate at that rate and mode. You do not have to
set any jumpers or configure the controller.
Figure 1-3 Ethernet Port Connector
Cisco Wide Area Virtualization Engine 274 and 474 Hardware Installation Guide
Description
Active link connection on the 10BASE-T,
100BASE-TX, or 1000BASE-TX interface for
the Ethernet port.
System is transmitting to or receiving signals
from the Ethernet LAN that is connected to the
Ethernet port.
Hardware Features
1-5
