3.3.8
Serial Console Redirection
COM1~COM6
Console Redirection
Allows you enable or disable the console redirection feature.
[Enabled] [Disabled]
Console Redirection Settings
The settings specify how the host computer and the remote computer (which
the user is using) will exchange data. Both computers should have the same or
compatible settings.
Terminal Type
Configuration options: [VT100] [VT100Plus] [VT-UTF8] [ANSI]
[VT100]
[VT100Plus]
[VT-UTF8]
[ANSI]
Bits per second
Allows you to select serial port transmission speed. The speed must be
matched on the other side. Long or noisy lines may require lower speeds.
Configuration options: [9600] [19200] [38400] [57600] [115200]
Data Bits
Configuration options: [7] [8]
Parity
A parity bit can be sent with the data bits to detect some transmission errors.
Configuration options: [None] [Even] [Odd] [Mark] [Space]
[None]
[Even]
[Odd]
[Mark]
[Space]
Mark and Space Parity do not allow for error detection.
Stop Bits
Stop bits indicate the end of a serial data packet. The standard setting is 1
stop bit. Communication with slow devices may require more than 1 stop bit.
Configuration options: [1] [2]
Flow Control
Flow control can prevent data loss from buffer overflow. When sending
Chapter 3: BIOS setup
ASCII char set.
Extends VT100 to support color, function keys, etc.
Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.
Extended ASCII char set.
Disables parity check.
Parity bit is 0 if the num of 1's in the data bits is even.
Parity bit is 0 if the num of 1's in the data bits is odd.
Parity bit is always 1.
Parity bit is always 0.
Configuration options:
3-9
