Summary of Contents for Draytek VigorSwitch G2121
- Page 2 VigorSwitch P2121/G2121 L2 Managed Gigabit Switch Quick Start Guide Version: 1.1 Firmware Version: V2.5.1 (For future update, please visit DrayTek web site) Date: December 25, 2019...
- Page 3 Intellectual Property Rights (IPR) Information © All rights reserved. This publication contains information that is protected Copyrights by copyright. No part may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language without written permission from the copyright holders. The following trademarks are used in this document: Trademarks ...
-
Page 4: Eu Declaration Of Conformity
EU Declaration of Conformity We DrayTek Corp. , office at No.26, Fu Shing Road, HuKou County, Hsin-Chu Industry Park, Hsinchu 300, Taiwan , R.O.C., declare under our sole responsibility that the product Product name: 8 + 4 Combo GbE Ports PoE Switch ... - Page 5 EU Declaration of Conformity We DrayTek Corp., office at No.26, Fu Shing Road, HuKou County, Hsin-Chu Industry Park, Hsinchu 300, Taiwan , R.O.C., declare under our sole responsibility that the product Product name: 8 + 4 Combo GbE Ports Switch ...
-
Page 6: Regulatory Information
ZIP Code 75234 E-mail rmesser@abptech.com Representative Contact Person Mr. Robert Tel. 19728311600 Messer Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. More update, please visit www.draytek.com. - Page 7 Web registration is preferred. You can register your Vigor switch via http://www.draytek.com. Firmware & Tools Updates Due to the continuous evolution of DrayTek technology, all switches will be regularly upgraded. Please consult the DrayTek web site for more information on newest firmware, tools and...
- Page 8 The 8 ports + 4 Combo UTP/SFP ports, L2 Managed Gigabit Ports Switch is a standard switch that meets both IEEE 802.3u/ab Fast Ethernet and Gigabit Ethernet specifications. The network administrator can logon the switch to monitor, configure and control each port’s activity. In addition, the switch implements the QoS (Quality of Service) and VLAN.
- Page 9 PoE for Port 1 to Port 8 RJ45 LNK/ACT Combo Port 1 to Port 8 Port LNK/ACT Status Explanation PoE/Alert On (Green) Devices connected over the PoE maximum power budget. (for P2121) Blinking More than 80% of maximum power budget is (Green) supplied for PoE device(s).
- Page 10 Combo for Port On (Green) The device is connected with 1000Mbps. 9 ~ 12 The device is connected with 10/100Mbps. (RJ 45 (Amber) LNK/ACT) Blinking The system is sending or receiving data through the port. The port is disconnected or the link is failed. On (Green) The device is connected with 1000Mbps.
- Page 11 This section will guide you to install the switch through hardware connection and configure the switch’s settings through web browser. Before starting to configure the switch, you have to connect your devices correctly. Note Power the device to this switch and get 54V power source through Cat.
- Page 12 The switch can be installed easily by using rack mount kit. Attach the brackets to the chassis of a 19- or a 23-inch rack. The second bracket attaches the other side of the chassis as above procedure. After the bracket installation, the VigorSwitch’s chassis can be installed in a rack by using four screws for each side of the rack.
- Page 13 In this section, we take VigorSwitch G2121 as an example: Before using the switch, perform the following steps: 1. Set up a physical path between the configured the switch and a PC by a qualified UTP Cat. 5e cable with RJ-45 connector.
- Page 14 The home page of VigorSwitch will be shown as below:...
- Page 15 This DrayTek product uses software partially or completely licensed under the terms of the GNU GENERAL PUBLIC LICENSE. The author of the software does not provide any warranty. A Limited Warranty is offered on DrayTek products. This Limited Warranty does not cover any software applications or programs.
