Table of Contents Important ����������������� 6 What's in the box ������������� 11 Overview ������������������ 12 Disassembling and cleaning before first use ������������������� 14 Assembling ���������������� 16 Using the Pasta and noodle maker �� 19 Cleaning ������������������ 27 Storage ������������������ 30 Troubleshooting �������������...
Safety Important Read this user manual carefully before you use the appliance, and save it for future reference. Warning • Before you connect the appliance to the power, make sure that the voltage indicated on the bottom of the appliance corresponds to the local power voltage.
Page 7
• If the power cord is damaged, you must have it replaced by Philips, a service center authorized by Philips or similarly qualified persons to avoid a hazard. • Do not replace parts of the appliance by yourself.
Page 8
• This appliance is intended for household use only. • Never use any accessories or parts from other manufacturers or that Philips does not specifically reommend. If you use such accessories or parts, your guarantee becomes invalid.
Page 9
Caution • Pull out the power plug immediately after you detect smoke. • When unplugging the power cord, do not pull the cable but grab the plug part. • Keep the power plug clean. • Do not put heavy objects on the appliance. •...
Page 10
60°C (140°F). • Use only on properly grounded outlet. Electromagnetic fields (EMF) This Philips appliance complies with all applicable standards and regulations regarding exposure to electromagnetic fields. 10 English...
Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. Read this user manual carefully before you install and use the appliance. Save it for future reference. What's in the box...
Overview Mixing paddle Squeezing bar Extra-extrusion Auto operation Control knob Start/pause button Main English...
Page 13
Squeezing tube Shaping disc Shaping disc holder Mixing chamber lid Mixing chamber Power cord Storage box Main unit Cord storage wrap English 13...
Disassembling and cleaning before first use Important • Before using the appliance for the first time, remove and safely discard any packing material and /or promotional labels. • Take out all detachable parts and accessories, wash and thoroughly dry all parts and accessories (refer to the chapter "Cleaning").
Page 15
Turn the shaping disc holder counterclockwise to remove it from the mixing chamber outlet. Put your finger in the mixing chamber and push the squeezing tube outwards to slide it out of the mixing chamber outlet. Detach the shaping disc, and then pull the squeezing bar out of the squeezing tube. Take the mixing paddle out of the mixing chamber.
Follow below assembling steps to install Assembling the Pasta and noodle maker. Important • Make sure the appliance is not plugged in during assembly. Slide the mixing chamber onto the main unit. Note: • Make sure the fixing levers on the main unit are fitted with the openings on the bottom of the mixing chamber.
Page 17
Insert the squeezing tube into the mixing chamber. Note: • Make sure the big opening on the squeezing tube faces up when you insert the tube into the chamber. Insert the squeezing bar into the mixing chamber. Make sure the squeezing bar slides all the way through both the squeezing tube and the mixing paddle and into the shaft in the main unit.
Page 18
Press the shaping disc through the opening of the shaping disc holder, and then assemble the holder on the mixing chamber outlet. Turn the holder clockwise to firmly lock it in place. Always attach the shaping disc on the mixing chamber outlet before you assemble the shaping disc holder.
Using the Pasta and noodle maker Important • Place the product on a flat surface and prevent table shaking or vibration. • Make sure all the parts are well assembled before plugging in. • Do not put less than 200g (1 flour cup) or more than 400g (2 flour cups) of flour in the chamber.
Page 20
Preparing and measuring the flour Scoop one full cup of flour using the flour cup. Scrape off any excessive flour from the cup edge with the supplied flat cleaning tool. 1 full cup of flour weighs around 200g, and 2 full cups of flour weigh around 400g.
Page 21
Pour the flour into the chamber. If you want to make 2-3 servings, add a second cup of flour as you will need 2 cups (~400g) of flour in total. Note: • Do not pour liquid into the mixing chamber at this point. Only pour liquid after the Pasta and noodle maker starts running.
Page 22
Preparing and measuring the liquid Measure the liquid volume at eye level on a flat surface. Note: • Do not pour liquid into the mixing chamber before the Pasta and noodle maker starts running. There are 2 sets of water markings on the supplied water cup. When using all-purpose flour and egg mixture to make plain egg pasta, refer to side A with two liquid levels.
Page 23
Check the following tables for detailed water and flour ratio. Note: • These tables show the flour-liquid ratio base on 200g of flour. When using 400g of flour to make pasta, double the liquid volume (including egg) to get the right flour-liquid ratio. When using egg mixture to make pasta, crack 1 egg into the water cup.
Page 24
Important • The pasta recipes provided in the recipe book have been tested for success. If you experiment with or use other pasta recipes, the flour and water/egg ratios will need to be adjusted to the flour and water cup ratios included with the Pasta and noodle maker.
Page 25
Put the plug of the appliance into the power outlet. The Pasta and noodle maker will sound once. Note: • Make sure all the parts are well assembled before plugging in. Attach the lid onto the mixing chamber. Note: • The appliance will not start working if the chamber lid is not properly closed.
Page 26
After the Pasta and noodle maker finishes kneading, it will beep a few times and the pasta extrusion will start after a few seconds. Place a container right under the outlet. Cut the pasta into the desired length with the cleaning tool. Note: •...
Cleaning Important • Turn the control knob to "OFF", disconnect the power and remove the power cord before cleaning or disassembling this appliance. • Do not immerse the main unit in water. • Do not use a scouring pad, caustic cleaners, or abrasive cleaners (for examples, gasoline, alcohol, and propanol) to clean the appliance.
Page 28
Slide the mixing chamber off the main unit. Turn the shaping disc holder counterclockwise to remove it from the mixing chamber outlet. Put your finger in the mixing chamber and push the squeezing tube outwards to slide it out of the mixing chamber outlet. Detach the shaping disc, and then pull the squeezing bar out of the squeezing tube.
Page 29
Clean the shaping disc with the supplied cleaning tool to remove the dough residues. After that, you can clean it with water. Clean all detachable parts with dishwashing liquid and warm water or clean in the dishwasher. After that, wipe all parts dry. Use a dry cloth to clean the main unit, control knob, and the exterior of the Pasta and noodle maker.
Storage Wind the power cord around the cord storage wrap. Dry the shaping discs and store them in the storage box. The small groove in the storage box is designed for the cleaning tool of the angel hair shaping disc, which is not included in this Pasta and noodle maker.
This chapter summarizes the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, visit www.philips.com/support or refer to page 32 for the consumer care number to call for assistance.
Page 32
During the pasta making process, the appliance stops working, and there is no alarm sound. • The Pasta and noodle maker has overheated due to long and continuous working time. Disconnect from the power source, and allow the Pasta and noodle maker to cool down. Do not exceed the maximum operation cycle of 2 cycles continuously at all applications.
Page 33
The pasta sticks together. • The ratio of the flour and water is incorrect, too much water is poured in the mixing chamber. Measure flour and water with the provided flour and water cup and according to the "flour/ water ratio table". Use a kitchen scale to measure the flour weight more accurately. Too much leftover dough inside the chamber.
Product information Model HR2332 Motor power 150W Rated voltage AC220-240V (50Hz) Dimensions (L x W x H) 350 mm x 135 mm x 287 mm Net weight 4.7 kg • For rated voltage and frequency information, refer to the type plate on the product. Product information is subject to change without prior notice.
Guarantee and service If you have a problem, need service or need information, see www.philips.com/support or contact the Philips Consumer Care Center in your country. English...
