- Page 1 INSTRUCTION MANUAL Cordless Impact Driver DTD152 Read before use.
-
Page 2: Specifications
EC Declaration of Conformity Intended use For European countries only Makita declares that the following Machine(s): The tool is intended for screw driving in wood, metal Designation of Machine: Cordless Impact Driver and plastic. Model No./ Type: DTD152 Noise... -
Page 3: General Power Tool Safety Warnings
your finger on the switch or energising power tools General power tool safety warnings that have the switch on invites accidents. Remove any adjusting key or wrench before WARNING: Read all safety warnings and all turning the power tool on. A wrench or a key left instructions. Failure to follow the warnings and attached to a rotating part of the power tool may instructions may result in electric shock, fire and/or result in personal injury. -
Page 4: Functional Description
terminals together may cause burns or a fire. conductive material. Under abusive conditions, liquid may be Avoid storing battery cartridge in a con- ejected from the battery; avoid contact. If con- tainer with other metal objects such as tact accidentally occurs, flush with water. If nails, coins, etc. liquid contacts eyes, additionally seek medical Do not expose battery cartridge to water help. Liquid ejected from the battery may cause... -
Page 5: Battery Protection System
Low battery voltage: The remaining battery capacity is too low and the tool will not operate. In this situation, remove and recharge the battery. Indicating the remaining battery capacity Only for battery cartridges with "B" at the end of the model number 1. Red indicator 2. Button 3. Battery cartridge To remove the battery cartridge, slide it from the tool while sliding the button on the front of the cartridge. To install the battery cartridge, align the tongue on the battery cartridge with the groove in the housing and slip it into place. - Page 6 Switch action Reversing switch action 1. Switch trigger 1. Reversing switch lever CAUTION: Before inserting the battery car- CAUTION: Always check the direction of rota- tridge into the tool, always check to see that the tion before operation. switch trigger actuates properly and returns to CAUTION: Use the reversing switch only after the "OFF"...
-
Page 7: Installing Hook
For tool with shallow driver bit hole NOTE: If the driver bit is not inserted deep enough into the sleeve, the sleeve will not return to its original A=12mm Use only these type of driver position and the driver bit will not be secured. In this B=9mm bit. -
Page 8: Maintenance
Proper fastening torque for standard bolt completely, voltage will drop and the fastening torque will be reduced. Driver bit or socket bit N•m (kgf•cm) Failure to use the correct size driver bit or socket bit will cause a reduction in the fastening torque. (1428) Bolt • Even though the torque coefficient and the (1224) class of bolt are the same, the proper fasten- (1020) ing torque will differ according to the diame- ter of bolt. -
Page 9: Optional Accessories
Centers, always using Makita replacement parts. OPTIONAL 1. Carbon brush cap ACCESSORIES CAUTION: These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 10 Center. • Driver bits • Hook • Plastic carrying case • Makita genuine battery and charger • Battery protector NOTE: Some items in the list may be included in the tool package as standard accessories. They may differ from country to country. 10 ENGLISH...
- Page 12 Makita Jan-Baptist Vinkstraat 2, 3070, Belgium Makita Corporation Anjo, Aichi, Japan 885432-226 www.makita.com 20150522...
