Owner's Manual
HDMI/Mini HDMI
Cable Tester
Model: T040-001-HDMI
Este manual esta disponible en español en la página de Tripp Lite:
www.tripplite.com/support
Ce manuel est disponible en français sur le site Web de Tripp Lite :
www.tripplite.com/support
Русскоязычная версия настоящего руководства
представлена на веб-сайте компании Tripp Lite по адресу:
www.tripplite.com/support
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2018 Tripp Lite. All rights reserved.
1
04-380-933794-EN.indd 1
5/7/2018 4:47:25 P
Advertisement
Table of Contents
Related Manuals for Tripp Lite T040-001-HDMI
Summary of Contents for Tripp Lite T040-001-HDMI
- Page 1 Model: T040-001-HDMI Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com/support Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com/support Русскоязычная версия настоящего руководства представлена на веб-сайте компании Tripp Lite по адресу: www.tripplite.com/support...
-
Page 2: Package Contents
Package Contents • Master Unit • Carrying Case • Remote Unit • Owner’s Manual Product Features • All-in-one unit combines a Main Tester with a removable Remote Identifier • Compatible with HDMI versions 1.0 through 2.1 • Fast and accurate verification of HDMI cables with Type A-A, A-C or C-C connectors •... -
Page 3: Operation
Operation Notes: • Before testing, insert a 9V battery (not included) and ensure the cable being tested is not yet connected to the tester. • Do not test live cables or any cable connected to an active device. Cables should be directly connected to the Master Unit and then to the Remote Unit. - Page 4 Detecting Connections Note: This product is designed to test cable lengths up to 164 ft. (50 m). When a cable connection from both ends is detected, the LEDs will illuminate. Listed below are detected connection examples with diagrams showing which pins should illuminate for each connection type. Note: When no connection is detected between the connectors of the cable being tested, the LEDs will not illuminate Straight (Proper) Connection...
- Page 5 Detecting Connections Crossed Connection If the wires inside the cable are out of order or crossed, the LEDs on the Remote Identifier will illuminate to show in what order they are wired. For example, in the diagram below, when the Master unit shows pin 14 illuminated, pin 19 on the Remote unit will illuminate, indicating those connections are crossed.
-
Page 6: Open Circuit
Detecting Connections Open Circuit If the same LEDs on both the Master and Remote units remain off, the corresponding wire is an open circuit. Remote Continuity Sweep Power Master 04-380-933794-EN.indd 6 5/7/2018 4:47:26 P... -
Page 7: Short Circuit
Detecting Connections Short Circuit If a short circuit is detected, the Remote unit’s LEDs will not illuminate, but the Master units LEDs will illuminate brighter. Remote Continuity Sweep Power Master 04-380-933794-EN.indd 7 5/7/2018 4:47:26 P... -
Page 8: Warranty And Product Registration
1-YEAR LIMITED WARRANTY TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center.
