Owner's Manual
Multi-Function Cable
Tester with Wire Tracker
(RJ45, RJ11, BNC, USB)
Model: T010-001-K
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
surge protector in our monthly drawing!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
1
19-04-414-9334DF-EN.indd 1
6/21/2019 8:26:41 AM

Advertisement

loading

Related Manuals for Tripp Lite T010-001-K

Summary of Contents for Tripp Lite T010-001-K

  • Page 1 Register your product today and be automatically entered to win an ISOBAR surge protector in our monthly drawing! www.tripplite.com/warranty 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support Copyright © 2019 Tripp Lite. All rights reserved. 19-04-414-9334DF-EN.indd 1 6/21/2019 8:26:41 AM...

  • Page 2: Package Includes

    Package Includes • Main Tester Unit • Remote Tester Unit • Remote Probe Unit • RJ11 Jumper Cable – 6 in. • RJ45 Jumper Cable – 6 in. • RJ11 to Alligator Clips Adapter • Headphones for Cable Tracing • Owner’s Manual Product Features •...
  • Page 3 Main Tester Unit RJ11 Port USB-B Port BNC Port RJ45 SCAN Port – Used for cable tracing test. RJ45 MAIN Port – Used in cable wiring, length and fault test. UP Button – Press to move up through the menu in the LCD interface. DOWN Button –...
  • Page 4 Remote Probe Unit Probe – Part of the unit that is pointed towards the cable when performing cable tracing. Power LED – Illuminates red when the test button is pressed during cable tracing. Volume Slider – Move it up and down to adjust the volume of the tone generated during cable tracing.
  • Page 5 Remote Tester Unit RJ45 Port USB-A Port RJ11 Port BNC Port 19-04-414-9334DF-EN.indd 5 6/21/2019 8:26:41 AM...
  • Page 6 LCD Interface Menu The following options are available in the LCD Interface Menu. • Language – Select the language in which to display the LCD Interface Menu. • Type – Choose the type of cable you are connecting to. • Wire Mapping – Used to perform Wire Map testing. •...
  • Page 7 Wire Mapping Test Note: The Remote Tester unit beeps on and off when a “correct connection” is detected in Wire Mapping. A long beep occurs when an “open circuit on near end” is detected in Wire Mapping. 1. To perform a Wire Mapping test, connect a patch cable (Cat5, Cat6, RJ11, USB, BNC) from the appropriate connector on the Main Tester unit to the Remote Tester unit.
  • Page 8 Wire Mapping Test b. Cable Open / Too Short – When the results to the right appear, it means that either the cable under test does not have any pins directly connected from one end to the other, you do not have a cable connected at all (or one end is not connected), you do not have the appropriate cable type selected in the LCD Interface, or the cable is too short to be...
  • Page 9 Wire Mapping Test g. Crosstalk – If crosstalk is found, results like those to the right will appear. The pins where crosstalk is detected will be flashing. h. Correct Connection (Installed Cable) – When testing installed cable that connects from the Main Tester unit to a wallplate, switch or other device, a correctly connected cable is indicated by results like those to the right.
  • Page 10 Cable Length Test If performing a Cable Length test for the first time, it is recommended you perform Calibration for the most accurate results. To perform Calibration, follow the steps below. Calibration 1. Connect a cable to the appropriate port on the Main Tester unit, using the RJ45 port marked Main for Cat5 / Cat6 cables.
  • Page 11 Cable Length Test Performing a Cable Length Test 1. Connect a cable to the appropriate port on the Main Tester unit, using the RJ45 port marked Main for Cat5 / Cat6 cables. You can choose to connect the other end to the Remote Tester unit or not. 2.
  • Page 12 Wire Tracker Test Notes: • The included headphones can be used when in a noisy environment to ensure you are hearing the tone from the Remote Probe Unit. • Press the flashlight button on the side of the Remote Probe Unit to turn on the light for use in dark areas.
  • Page 13 Recalibration Note: Prior to performing recalibration: • The unit needs to be turned OFF. • An RJ45 cable must connected to the Main Tester unit and the Remote Tester Unit. Not doing so will prompt the error message “Invalid remote”. 1.
  • Page 14 Recalibration 7. The progress bar with the word “Identify” will appear again. 8. Press the DOWN button twice to exit recalibration settings. 9. Scroll down and press the ENTER button once “Save-Off” appears on the screen. When Sys Adj End! completed, “Sys Adj End!”...

  • Page 15: Warranty And Product Registration

    1-YEAR LIMITED WARRANTY TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
  • Page 16 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support 19-04-414 93-34DF_RevB 19-04-414-9334DF-EN.indd 16 6/21/2019 8:26:42 AM...
