Owner's Manual
Multi-Function Optical
Fiber Cable Tester
Model: T020-001-PSF
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2015 Tripp Lite. All rights reserved.
1
15-11-089-9334DC-EN.indd 1
11/20/2015 2:11:04 PM

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite T020-001-PSF

Summary of Contents for Tripp Lite T020-001-PSF

  • Page 1 Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a $100 value! www.tripplite.com/warranty 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support Copyright © 2015 Tripp Lite. All rights reserved. 15-11-089-9334DC-EN.indd 1 11/20/2015 2:11:04 PM...

  • Page 2: Package Includes

    Package Includes • T020-001-PSF Tester Unit • Owner’s Manual Product Features • All-in-One Optical Fiber cable tester with Power Meter, Light Source, and Visual Fault Locator • Easy-to-use LCD interface • Determine optical power loss • Visual fault locator finds visual faults in the cable, featuring multiple frequency settings for continuous and flashing modes •...

  • Page 3: Cable Tester Unit

    Cable Tester Unit Power Button – When off, press this button to turn the unit on. When on, press this button to toggle the Auto-Off feature on/off, or hold it down to turn off the unit. Power Meter / Light Source Button ( ) –...
  • Page 4 Cable Tester Unit (continued) Wavelength / VFL Button ( ) – Press this button to change the wavelength setting in the power meter and light source screens. Hold it down to activate the Visual Fault Locator. Frequency / OSL Button ( ) –...

  • Page 5: Lcd Screen

    LCD Screen Power loss measurement data, with the unit of measurement shown to its right. Selected wavelength. A saved power loss reference value or the selected frequency value. Battery icon showing the remaining battery capacity. Power cord icon will display if you are using rechargeable batteries and charging them via the USB Micro-B connector on the side of the unit.
  • Page 6 Power Meter Screen When turning on the unit, the power meter screen is the first to be displayed. When in a screen other than the power meter screen, press the Power Meter / Light Source ( ) button on the unit to access it. The power meter screen consists of the power data in the center of the screen, with the selected unit of measurement displayed to the right of it.

  • Page 7: Visual Fault Locator

    Light Source Screen To access the light source screen, press the Power Meter / Light Source ( ) button on the unit, toggling from the power meter screen to the light source screen. The light source screen consists of the wavelength in the center of the screen and the frequency in the upper-right corner.

  • Page 8: Warranty And Product Registration

    1-YEAR LIMITED WARRANTY TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
