Operating Guide
Read this document when using the AK-HRP1005G Remote Operation Panel in
conjunction with AW-UE100 4K Integrated Camera.
For details of operating Remote Operation Panel AK-HRP1005G, please
visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.
html), and refer to the Operating Instructions (HTML or PDF).
W0321AM0 -PS
Remote Operation Panel
AK-HRP1005G
Model No.
ENGLISH
DVQP2496ZA
Advertisement
Table of Contents
Related Manuals for Panasonic AK-HRP1005G
Summary of Contents for Panasonic AK-HRP1005G
- Page 1 Operating Guide Remote Operation Panel AK-HRP1005G Model No. Read this document when using the AK-HRP1005G Remote Operation Panel in conjunction with AW-UE100 4K Integrated Camera. For details of operating Remote Operation Panel AK-HRP1005G, please visit the Panasonic website (https://pro-av.panasonic.net/manual/en/index.
-
Page 2: Table Of Contents
Table of Contents Connecting the Unit to AW-UE100 Cameras Connection Example Connections Compatible Functions List ROP Menu (during AW-UE100 connection) ROP Menu List 01 SCENE 02 SHUTTER SPEED 03 FILTER 04 PEDESTAL 05 CHROMA 06 GAIN 07 WHITE BALANCE 08 GAMMA 09 BLACK GAMMA 10 KNEE 11 WHITE CLIP... -
Page 3: Connecting The Unit To Aw-Ue100 Cameras
* Prepare a cable that is in accordance with the following serial connection cable specifications. Switching hub PoE injector with PoE support LAN cable (straight cable) Serial connection cable specifications AK-HRP1005G <CCU> connector side AW-UE100 <RS-422> connector side (RJ-45) - 3 -... -
Page 4: Connections
Connecting the Unit to AW-UE100 Cameras Connections Set the connection setting to “Serial(AW5)” or “LAN(AW5)” in the [CONNECT SETTING] menu. When connecting, observe the following points. Serial connection Use a dedicated cable to connect the <CCU> connector of this unit to the <RS-422> connector of the AW-UE100. Use a PoE injector for the power supply. -
Page 5: Compatible Functions List
Connecting the Unit to AW-UE100 Cameras Compatible Functions List When the unit is used in conjunction with an AW-UE100 4K Integrated Camera, there will be functions that are limited or disabled for some of the unit's buttons, dials, and other controls. Be sure to refer to the following table. Front panel 1 Front panel 2 Front panel 3... - Page 6 Connecting the Unit to AW-UE100 Cameras ✓ : Enabled Number Part name Remarks ×: Disabled ✓ [GAIN] button When this button is pressed, the gain menu appears on the LCD panel. The button is lit dur- ing menu display. ✓ [SHT] button When this button is pressed, the shutter menu appears on the LCD panel.
- Page 7 Connecting the Unit to AW-UE100 Cameras ✓ : Enabled Number Part name Remarks ×: Disabled ✓ [ALM] indicator [OPT] indicator × [EXT] indicator × ✓ [D.EXT] indicator ✓ Adjustment value display The adjustment value of the CC filter is not dis- played.
-
Page 8: Rop Menu (During Aw-Ue100 Connection)
ROP Menu (during AW-UE100 connection) ROP Menu (during AW-UE100 connection) ROP Menu List When an AW-UE100 4K Integrated Camera is connected, the ROP menu will be as follows. NOTE To perform menu operations, upgrade the system version of the unit to V5.00-00-0.00 or later. For details on menu operations, refer to the following sections in the Operating Instructions. - Page 9 ROP Menu (during AW-UE100 connection) “DRS” (see page 25) 12 DRS MASTER DTL “MASTER DTL” (see page 26) CORING “CORING” (see page 26) V DTL LEVEL “V DTL LEVEL” (see page 26) “FREQ” (see page 26) FREQ “LEVEL DEPEND.” (see page 26) LEVEL DEPEND.
- Page 10 ROP Menu (during AW-UE100 connection) “TYPE” (see page 29) TYPE ADAPTIVE MATRIX “ADAPTIVE MATRIX” (see page 29) COLOR CORRECT “COLOR CORRECT” (see page 29) “SAT” (see page 29) “PHASE” (see page 29) PHASE “SAT B_Mg” (see page 29) SAT B_Mg “PHASE B_Mg”...
- Page 11 ROP Menu (during AW-UE100 connection) “FOCUS MODE” (see page 33) FOCUS MODE FOCUS SPEED “FOCUS SPEED” (see page 33) FOCUS “FOCUS” (see page 33) ZOOM WIDE “ZOOM WIDE” (see page 33) “ZOOM SPEED” (see page 33) 18 LENS CONTROL ZOOM SPEED “ZOOM TELE”...
- Page 12 ROP Menu (during AW-UE100 connection) IRIS LEV MODE Refer to the following section in the Operating Instructions. “37 ROP SETTING” M.PED CONT LOCK SELECT AUTO BUTTON G/M PED VOL FREE+LOCK CAM SEL DTL BUTTON SKIN VOL LCD BRIGHT PANEL BRIGHT B.GAMMA VOL BUZZER PERIOD...
- Page 13 ROP Menu (during AW-UE100 connection) IP ADDRESS 1 Refer to the following section in the Operating Instructions. “39 ROP IP SETTING” IP ADDRESS 2 IP ADDRESS 3 IP ADDRESS 4 IP ADDRESS PORT IP ADDRESS UPLOAD SUBNET MASK 1 24 ROP IP SETTING SUBNET MASK 2 SUBNET MASK 3 SUBNET MASK 4...
-
Page 14: Scene
ROP Menu (during AW-UE100 connection) 01 SCENE Item Setting details SCENE1(push) Switches the scene file. Switches to the scene set to ON. SCENE2(push) SCENE3(push) SCENE4(push) - 14 -... -
Page 15: Shutter Speed
ROP Menu (during AW-UE100 connection) 02 SHUTTER SPEED Item Setting details MODE Selects the operation mode of the shutter. SPEED Sets the shutter speed. Sets the maximum shutter value for ELC operation. - 15 -... -
Page 16: Filter
ROP Menu (during AW-UE100 connection) 03 FILTER Item Setting details Sets the transmittance of the lens’ built-in ND (neutral density) filter. - 16 -... -
Page 17: Pedestal
ROP Menu (during AW-UE100 connection) 04 PEDESTAL Item Setting details M.PED Adjusts the black level of the master pedestal. OFFSET Sets the [PED R], [PED G], and [PED B] pedestal levels when the auto black balance is adjusted. PED R Sets the correction level of red to the master pedestal. -
Page 18: Chroma
ROP Menu (during AW-UE100 connection) 05 CHROMA Item Setting details LEVEL Sets the color intensity of images. PHASE Finely adjusts the color phase of images. - 18 -... -
Page 19: Gain
ROP Menu (during AW-UE100 connection) 06 GAIN Item Setting details SUPER GAIN Sets the super gain (increased sensitivity) to ON/OFF. GAIN Adjusts the gain of images. AGC MAX GAIN When “AUTO” is selected as the [GAIN] setting, the maximum gain-up amount can be set. - 19 -... -
Page 20: White Balance
ROP Menu (during AW-UE100 connection) 07 WHITE BALANCE Item Setting details MODE Sets the white balance mode. COLOR TEMP Sets color temperature settings. GAIN OFFSET Sets the [GAIN R] and [GAIN B] values when the [MODE] is set to “AWB A” or “AWB B”. GAIN R Adjusts the R gain. -
Page 21: Gamma
ROP Menu (during AW-UE100 connection) 08 GAMMA Item Setting details MODE Selects the type of gamma curve. GAMMA Sets the gamma. - 21 -... -
Page 22: Black Gamma
ROP Menu (during AW-UE100 connection) 09 BLACK GAMMA Item Setting details BLACK GAMMA Sets the gamma curve for dark areas. RANGE Sets the maximum level for compression/expansion. - 22 -... -
Page 23: Knee
ROP Menu (during AW-UE100 connection) 10 KNEE Item Setting details MODE Sets the operating mode for gradation compression (knee). When [DRS] is enabled, the knee settings are disabled. A.KNEE RESPONSE Sets the auto knee response speed. POINT Sets the compression level (knee point) position for high-brightness video signals. SLOPE Sets the knee slope. -
Page 24: White Clip
ROP Menu (during AW-UE100 connection) 11 WHITE CLIP Item Setting details WHITE CLIP Sets the white clip function to ON/OFF. WHITE CLP LV Sets the white clip level. - 24 -... -
Page 25: Drs
ROP Menu (during AW-UE100 connection) 12 DRS Item Setting details Sets the DRS function, which performs correction when video with high light/dark contrast is displayed, to ON/OFF. - 25 -... -
Page 26: Detail
ROP Menu (during AW-UE100 connection) 13 DETAIL Item Setting details MASTER DTL Adjusts the contour correction level (master). CORING Sets the level of signal (including noise) that does not activate the detail effect. V DTL LEVEL Adjusts the vertical contour correction level. FREQ Sets the boost frequency for detail. -
Page 27: Matrix
ROP Menu (during AW-UE100 connection) 14 MATRIX Item Setting details TYPE Selects the type of color matrix. ADAPTIVE MATRIX Turns ON/OFF the function to suppress the linear matrix according to the shooting conditions. Adjusts the linear matrix between red and green. Adjusts the linear matrix between red and blue. -
Page 28: Color Correction
ROP Menu (during AW-UE100 connection) 15 COLOR CORRECTION - 28 -... - Page 29 ROP Menu (during AW-UE100 connection) Item Setting details TYPE Selects the type of color matrix. ADAPTIVE MATRIX Turns ON/OFF the function to suppress the linear matrix according to the shooting conditions. COLOR CORRECT Selects the color component in 12-axis matrix memory to adjust. Adjusts the saturation of the color component selected in [COLOR CORRECT].
- Page 30 ROP Menu (during AW-UE100 connection) Item Setting details PHASE Mg_R_R Adjusts the hue with a 1:3 magenta to red ratio. SAT R Adjusts red color saturation. PHASE R Adjusts red hue. SAT R_R_Yl Adjusts the color saturation with a 3:1 red to yellow ratio. PHASE R_R_Yl Adjusts the hue with a 3:1 red to yellow ratio.
-
Page 31: Dnr
ROP Menu (during AW-UE100 connection) 16 DNR Item Setting details Sets the level for the noise reduction. - 31 -... -
Page 32: Brightness
ROP Menu (during AW-UE100 connection) 17 BRIGHTNESS Item Setting details PICTURE LEVEL Sets the target picture level for auto exposure correction. FRAME MIX Selects for frame addition (gain-up using sensor storage) amount. DAY/NIGHT Switches between standard shooting (day mode) and night-vision shooting (night mode: shooting with infrared light). -
Page 33: Lens Control
ROP Menu (during AW-UE100 connection) 18 LENS CONTROL Item Setting details FOCUS MODE Selects auto or manual mode for the focus adjustment function. FOCUS SPEED Adjusts the focus operation speed. FOCUS Adjusts the lens focus manually. ZOOM WIDE Adjusts the lens zoom to wide angle (Wide). ZOOM SPEED Adjusts the zoom operation speed. -
Page 34: Iris Relative
ROP Menu (during AW-UE100 connection) 19 IRIS RELATIVE Item Setting details SENSE Adjusts the iris variable range for when the iris lever is moved from the center to the top and bottom ends. COARSE Use this dial to adjust the iris value when the IRIS lever is moved to the center. RELATIVE When this is set to “ON”, the iris lever's variable range is not dependent on the [SENSE] and [COARSE] set- tings and will include the entire range between OPEN and CLOSE. -
Page 35: System Cam
ROP Menu (during AW-UE100 connection) 20 SYSTEM CAM Item Setting details FORMAT Displays the system format. FREQUENCY Indicates the frame frequency. 12G 3G SDI Selects the format to output 3G SDI signals when the video format of 12G SDI/OPTICAL is “1080/59.94p” or “1080/50p”. - Page 36 ROP Menu (during AW-UE100 connection) Item Setting details OSD HDMI Selects ON/OFF for the display of the camera menu, status, and other information that is output from the <HDMI> connector. OSD IP Selects ON/OFF for the display of the camera menu, status, and other information that is output from the <LAN LINK/ACT>...
-
Page 37: Camera Menu Control
ROP Menu (during AW-UE100 connection) 21 CAMERA MENU CONTROL Item Setting details MENU ON/OFF Turns the menu ON/OFF. CURSOR/PARAMETER Moves the menu cursor or changes setting values. EXECUTE Executes the selected process. - 37 -... -
Page 38: Rop Setting
ROP Menu (during AW-UE100 connection) 22 ROP SETTING For details on operations and settings, refer to the following sections in the Operating Instructions. “37 ROP SETTING” - 38 -... -
Page 39: Connect Setting
ROP Menu (during AW-UE100 connection) 23 CONNECT SETTING Item Setting details CONNECT MODE(push) CAM1 Sets the connection method for camera 1. Changes to settings are applied by pressing the menu operation dial. Select “LAN(AW5)” and “Serial(AW5)” when connecting with the AW-UE100. “Serial(AW5)”... -
Page 40: Rop Ip Setting
ROP Menu (during AW-UE100 connection) 24 ROP IP SETTING For details on operations and settings, refer to the following sections in the Operating Instructions. “39 ROP IP SETTING” 25 CAMERA IP SETTING For details on operations and settings, refer to the following sections in the Operating Instructions. “40 CAMERA IP SETTING”... -
Page 41: Auto Iris Setting
ROP Menu (during AW-UE100 connection) 26 AUTO IRIS SETTING Item Setting details IRIS SPEED Sets the control speed of the auto iris function. IRIS WINDOW Selects the auto iris detection window. - 41 -... -
Page 42: Switcher Link
ROP Menu (during AW-UE100 connection) 27 SWITCHER LINK For details on operations and settings, refer to the following sections in “Functions Added by Version Updates”. “Functions linking with AV-HS6000” 28 AW CONTROLLER LINK For details on operations and settings, refer to the following sections in “Functions Added by Version Updates”. “Function linking with AW-RP150”...
