This product works with the following operating
Windows XP, Windows
system software:
2000, Windows Me, Windows 98SE
Before You Begin
You must have at least the following:
•
A desktop computer with an available PCI 2.2, 32-bit, 5 volt PCI slot
•
At least a 500MHz processor and 128MB of memory
•
An 802.11a, 802.11b or 802.11g Access Point (for Infrastructure Mode) or
another 802.11a, 802.11b, or 802.11g wireless adapter (for Ad-Hoc;
Peer-to-Peer networking mode.)
Check Your Package Contents
These are the items included with your DWL-AG530 purchase:
If any of the above items are missing, please contact your reseller.
Insert the D-Link CD Into Your Desktop PC
Turn on the computer
Insert
the
D- Link AirPremier DWL-AG530
Driver CD in the CD-ROM drive.
The step-by-step instructions that follow are shown in
Windows XP. The steps and screens are similar for the
other Windows operating systems
©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and
DWL-AG530 Dualband Wireless PCI Adapter
CD-ROM (containing Drivers, Manual and Warranty)
and
specifications subject to change without notice. DWL-AG530 11132003
DWL-AG530
Wireless PCI Adapter
into your computer
before installing the
driver software from the
D-Link CD!
1
TM
Air Premier Dualband
Wireless PCI Adapter
Do
NOT
install
the DWL-AG530
Advertisement
Table of Contents
Related Manuals for D-Link DWL-AG530
Summary of Contents for D-Link DWL-AG530
-
Page 1: Before You Begin
Windows XP. The steps and screens are similar for the other Windows operating systems ©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DWL-AG530 11132003... - Page 2 Continued... The Install Screen will appear. Click Install Drivers If the CD Autorun function does not automatically start on your computer , go to Start > Run and type “D:\Drivers\Setup.exe.” If it does start, proceed to the next screen. Type “D:\Drivers\Setup.exe.”...
-
Page 3: Your Computer
Click Next Click Next Click Finish Shut down your computer... - Page 4 Remove the back or side cover of the com- puter. Install the DWL-AG530 carefully, and firmly set it into the available PCI slot (which is typically white or cream-colored). Secure the DWL-AG530’s back panel bracket with its mounting screw.
-
Page 5: Product Overview
(Recommended) Click Next Antenna to wirelessly connect to 802.11a and 802.11b networks Antenna Cable DWL-AG530 PCI board to the screen Link/Activity LEDs Indicates that the card is properly installed when the computer is on and blinks when data is being transmitted. - Page 6 For Windows 2000, this Digital Signature Not Found screen may appear after your computer restarts. Click to finalize the installation. Hardware The D-Link driver software for this device is undergoing Windows Logo testing. Microsoft certification is pending.
- Page 7 Your Installation is Complete! After you’ve continued in Windows 2000, Me, or 98SE, the D-Link AirPremier DWL-AG530 Configuration Utility will automatically start and the utility icon will appear in the bottom right hand corner of the desktop screen (systray). If this...
- Page 8 Appendix For Windows XP, if you wish to use the AirPremier utility, please do the following steps. Click the XP Networking icon to use the Zero Configuration Wireless Settings. Click Advanced Uncheck “Use Windows to configure my wireless net- work settings.”...
-
Page 9: Using The Configuration Utility
Signal Quality : Displays the Link Quality for the DWL- AG530 wireless connection to the access point. The Signal Strength represents the wireless signal be- tween the access point and the DWL-AG530. The percentage coincides with the graphical bar. Frequency Displays the... - Page 10 SSID: The Service Set Identifier is the name as- signed to the wireless network. The factory SSID setting is set to default. Make changes here to match the SSID on existing Wireless Router or Access Point. Authentication: You can specify the authentication mode for the wireless network.
- Page 11 Notes...
- Page 12 You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link technical support through our website, or by phone.
