Table 2 lists supported single stream configurations on the Cisco Video Surveillance 2630V IP Dome.
Table 2.
Single
Streaming
H.264
MPEG-4
MJPEG
Table 3 lists the supported primary and secondary video stream combinations on the Cisco Video Surveillance
2630V IP Dome.
Table 3.
Primary
H.264
H.264
MPEG4
MPEG4
Table 4 lists the supported primary and secondary video streams on the Cisco Video Surveillance 2630V IP Dome.
Table 4.
NTSC Primary Channel
Resolutions
4 CIF, CIF
PAL Primary Channel
Resolutions
4 CIF, CIF
* If a secondary frame rate is selected in Cisco Video Surveillance Manager that is not listed in the table, the camera will
automatically use the closest frame rate.
Connectors
Table 5 describes the connectors on the Cisco Video Surveillance 2630V IP Dome.
Table 5.
Item
Network Connectivity
Video
Audio*
Alarm Input
Alarm Output*
Power Input
* Not supported or applicable when the camera is used with Cisco Video Surveillance Manager.
© 2011 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information.
Supported Single Stream Configurations
Maximum Resolution and
Frames Per Second (FPS)
D1 @ 30 fps
D1 @ 30 fps
D1 @ 30 fps
Supported Primary and Secondary Video Stream Combinations
Secondary
H.264
MJPEG
MPEG4
MJPEG
Cisco Video Surveillance 2630V IP Dome Video Stream Support
NTSC Primary Frame Rate
30, 25, 20, 15, 10, 8, 6, 5
PAL Primary Frame Rate
25, 20, 15, 10, 8, 6, 5
Cisco Video Surveillance 2630V IP Dome Connectors
Specification
10/100 BASE-TX Ethernet with RJ-45 connector
3.5-mm service connector, provides analog video (use with optional mini cable with BNC adapter during installation)
● 3.5-mm audio jack: audio input for optional external microphone and audio output for optional external speaker
supported through Y-cable adapter
● Two-way (full- or half-duplex), one-way, or audio off
Two logic-level programmable inputs
Two logic-level programmable outputs
3-pin terminal
Resolutions Supported (NTSC
NTSC FPS Supported
& PAL)
D1
30, 25, 20, 15, 10, 8, 6, 5
4CIF
CIF
D1
30, 25, 20, 15, 10, 8, 6, 5
4CIF
CIF
D1
30, 25, 20, 15, 10, 8, 6, 5
4CIF
CIF
NTSC Secondary Channel
Resolutions
CIF
PAL Secondary Channel
Resolutions
CIF
Data Sheet
PAL FPS Supported
25, 20, 15, 10, 8, 6, 5
25, 20, 15, 10, 8, 6, 5
25, 20, 15, 10, 8, 6, 5
NTSC Secondary Frame Rate*
15, 10, 8, 6, 5
PAL Secondary Frame Rate*
15, 10, 8, 6, 5
Page 3 of 6
