3-5-4 Installation of LOGIQ™ 100 PRO with Global or Modular Trolley
Note:
1.) Unpack the global trolley packed in a wooden box by opening the top cover, refer Figure 3-8
Figure 3-8 Global Trolley Unpacking
Ap p r o v e d Do c u m e n t - 5 3 0 5 8 8 0 - 1 0 0 T PH_ r 3 . p d f Pa g e 5 6 o f 1 9 7
3
EVISION
LOGIQ™ 100 PRO has two types of Trolleys, the Global Trolley and the Modular Trolley.
The Global Trolley comes in the assembled form and the Modular Trolley comes in a modular
form which needs assembly at field
(trolley which is inside the box is seen in the diagram).
