Page 1
Difficulty: Easy Tools/supplies: Flat head screwdriver. #0 Phillips screwdriver Parts: n/a Additional Resources at baratza.com/troubleshooting: How to Troubleshoot a Grind Quality Issue (video/PDF). Case Removal (Video/PDF). Adjustment Ring Replacement (Video/PDF). *** Unplug the grinder from power supply *** -A BRIEF NOTE BEFORE BEGINNING- Calibration on these models is a way to make small adjustments to burr spacing.
Page 2
We opened up this grinder to find it in the middle window. #0 Phillips screw Windows Remove the screw. Note that there are two holes that the screw can be threaded into. Holes www.baratza.com support@baratza.com rev. 4/2/2019...
Page 3
ROTATE To adjust your calibration, hold the white ring with one hand, keeping it from rotating. Using the other hand, turn the black STATIONARY ring to reposition the screw hole to the desired location. www.baratza.com support@baratza.com rev. 4/2/2019...
Page 4
** Rotate the adjustment system fully counter- clockwise. Install the case and return the unit to operation. If you have any questions, or encounter issues with this guide, contact support@baratza.com www.baratza.com support@baratza.com rev. 4/2/2019...
