Tripp Lite Classic DMCS3770L Owner's Manual

Mobile flat-panel
Hide thumbs Also See for Classic DMCS3770L:

Advertisement

Quick Links

Download this manual
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
CAUTION: DO NOT EXCEED MAXIMUM LISTED WEIGHT CAPACITY. SERIOUS INJURY OR
PROPERTY DAMAGE MAY OCCUR!
200 x 200 / 300 x 300 /
400 x 200 / 400 x 400 /
600 x 400
Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com
Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com
Русскоязычная версия настоящего руководства представлена на веб-сайте компании
Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
17-11-297-9337CE-EN.indd 1
Owner's Manual
Mobile Flat-Panel
Classic
Model: DMCS3770L
PROTECT YOUR INVESTMENT!
www.tripplite.com/warranty
70"
MAX
Tripp Lite по адресу: www.tripplite.com
Copyright © 2017 Tripp Lite. All rights reserved.
TV
88 lb.
(40 kg)
MAX
1
DVD
22 lb.
(10 kg)
MAX
12/21/2017 10:10:12 AM

Advertisement

loading

Related Manuals for Tripp Lite Classic DMCS3770L

Summary of Contents for Tripp Lite Classic DMCS3770L

  • Page 1 600 x 400 Este manual esta disponible en español en la página de Tripp Lite: www.tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : www.tripplite.com Русскоязычная версия настоящего руководства представлена на веб-сайте компании Tripp Lite по адресу: www.tripplite.com Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: www.tripplite.com...
  • Page 2 NOTE: Read the entire instruction manual before you start assembly and installation. WARNING • Do not begin the installation until you have read and understood the instructions and warnings contained in this manual. If you have any questions regarding any of the instructions or warnings, please visit www.tripplite.com/support •...

  • Page 3: Component Checklist

    Component Checklist IMPORTANT: Ensure that you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit www.tripplite.com/support for service. Left Leg Right Leg Left Cover Right Cover Middle Base Front Rear Telescoping Pole (x2) Caster (x2)

  • Page 4: Assembling The Base

    1. Assembling the Base FRONT 1) Attach Front Casters F and Rear Casters G to both Left Leg A and Right Leg B using Wrench P-I. 2) Attach Middle Base E to the Legs. Secure top bar with Screws P-A and Washers P-G. Secure to sides of Legs with Screws P-B and Washers P-G using Allen Wrench P-J.
  • Page 5 2. Attaching Telescoping Sidebars Rotate the inner column to locate the locking pin, then press it and adjust to Position 1. locking pin Position 1 1) Adjust Telescoping Poles H to desired height using button. Cover exposed holes with Hole Covers I. 2) Insert Poles H into the holes on the Middle Base E.
  • Page 6 3. Attaching Universal Plate Insert Washers P-F and Nuts P-H into rear of Telescoping Poles H at desired height. Secure Universal Plate J with Screws P-C using Allen Wrench P-J. 17-11-297-9337CE-EN.indd 6 12/21/2017 10:10:20 AM...
  • Page 7 4. Installing the DVD Shelf 1) Slide Brackets L into DVD Shelf K. 2) Insert Bracket hooks at desired height into Telescoping Poles H. Push down to secure. 3) Cover exposed holes with Shelf Screw Covers N. 17-11-297-9337CE-EN.indd 7 12/21/2017 10:10:22 AM...
  • Page 8 5. Installing the Mounting Arms 5.1 For Flat-Back Screens Note: Choose the appropriate Screws, Washers and Spacers (if needed) according to the type of screen. Screw the Mounting Arms onto the display. CAUTION: Tighten all screws but do not over-tighten. 5.2 For Recessed-Back Screens or Accessing A/V Inputs Note: Choose the appropriate Screws, Washers and Spacers (if needed) according to the type of screen.
  • Page 9 6. Hooking the Display to the Universal Plate 1) Hook the Mounting Arms onto the Universal Plate attached to the Telescoping Poles. 2) Secure by tightening Screws with user-supplied Phillips-head screwdriver. CAUTION: Be sure the display is correctly mounted and that the screws are safely tightened before releasing the display.
  • Page 10 7. Cable Management & Display Adjustment +10° –10° Route cables through Hole Covers (optional). Tighten the knobs to secure. Loosen the knobs to adjust the display to the desired angle. 17-11-297-9337CE-EN.indd 10 12/21/2017 10:10:32 AM...

  • Page 11: Warranty And Product Registration

    PRODUCT REGISTRATION Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary.
  • Page 12 Maintenance • Check that the bracket is secure and safe to use at regular intervals (at least every three months). • For any additional questions, visit www.tripplite.com/support. 1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support 17-11-297 93-37CE_RevB 17-11-297-9337CE-EN.indd 12 12/21/2017 10:10:32 AM...
