Full-motion wall mount for flat or curved screens – security version (50 pages)
Summary of Contents for Tripp Lite DMC1342S
Page 1
200x100/200x200 Este manual esta disponible en español en la página de Tripp Lite: tripplite.com Ce manuel est disponible en français sur le site Web de Tripp Lite : tripplite.com Русскоязычная версия настоящего руководства представлена на веб-сайте компании Tripp Lite по адресу: tripplite.com Dieses Handbuch ist in deutscher Sprache auf der Tripp Lite-Website verfügbar: tripplite.com...
FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply. See website for details. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos and illustrations may differ slightly from actual products.
Component Checklist IMPORTANT: Ensure you have received all parts according to the component checklist prior to installing. If any parts are missing or faulty, visit tripplite.com/support for service. B (X2) A (X1) C (X1) D (X2) E (X2) F (X2) G (X2) H (X2) I (X1)
Page 4
1. Assemble Base 2. Assemble Vertical Support 19-09-108-933B42.indd 4 10/7/2019 9:48:35 AM...
Page 5
3. Attach Cord Management Collar to Vertical Support 4. Attach Vertical Support Assembly to Base 19-09-108-933B42.indd 5 10/7/2019 9:48:35 AM...
Page 6
5. Attach VESA Plate to Display Panel 5a. For Small and Medium Displays M-A/M-B M- E Attach the display to the VESA plate with the appropriate included screws. Do not over-tighten screws. 5b. For Larger Displays Using VESA Plate Adapters (Optional) 5b-1.
Page 7
5b-2. Attach VESA Plate with Adapters to Display M-A/M-B/M-C/M-D M-E/M-F M- D Attach the display to the VESA plate with the appropriate included screws. Do not over-tighten screws. 19-09-108-933B42.indd 7 10/7/2019 9:48:35 AM...
Page 8
6. Attach Display with VESA Plate to Vertical Support Use the included wrench to secure the VESA plate and display to the vertical support. Make sure the display is secure before releasing. 7. Adjustment +3˚ -3˚ +30˚ 0˚ Maintenance • Check to ensure the bracket is secure and safe to use at regular intervals (at least every three months). •...
