Summary of Contents for Bosch Rexroth IPC 40.2
- Page 1 Industrial Electric Drives Linear Motion and Service Mobile Hydraulics and Controls Assembly Technologies Pneumatics Automation Hydraulics Rexroth IndraControl VCP 20 Rexroth IPC 40.2 R911307652 Edition 02 Project Planning Manual...
- Page 2 About this Documentation IPC 40.2 Rexroth IPC 40.2 Title Project Planning Manual Type of Documentation DOK-SUPPL*-IPC*40.2***-PR02-EN-P Document Typecode Document Number, 120-2100-B367-02/EN Internal File Reference This documentation describes the industrial PC IPC 40.2. Purpose of Documentation Record of Revisions Description Release...
-
Page 3: Table Of Contents
IPC 40.2 Contents Contents System Presentation Brief Description IPC 40.2 ......................1-1 Variants............................1-2 Distinguishing Features ......................1-2 Operating System ......................... 1-2 Commissioning ..........................1-2 Important Directions for Use Appropriate Use..........................2-1 Introduction ..........................2-1 Areas of Use and Application ....................2-2 Inappropriate Use ......................... - Page 4 Contents IPC 40.2 Dimensions Housing Dimensions........................5-1 Mounting ............................5-2 Display and Operating Components Monitor and Keyboard ........................6-1 Operating and Error Indication...................... 6-2 Connections View on the Connector Panel ....................... 7-1 Interfaces ............................7-1 Overview..........................7-2 Serial Interfaces XCOM1 to XCOM3 ..................7-3 Settings of the Serial Interfaces....................
- Page 5 IPC 40.2 Contents 10 Ordering Information 10-1 10.1 Type Code ..........................10-1 10.2 Accessories ..........................10-2 Network Connection ......................10-2 Battery Pack and Cables ....................... 10-2 Connecting Cables to the VDP 16.1, VDP 40.1 and VDP 60.1 (GIGASTAR Interface) ..10-2 Fastening Brackets........................
- Page 6 Contents IPC 40.2 DOK-SUPPL*-IPC*40.2***-PR02-EN-P...
-
Page 7: System Presentation
IPC 40.2 System Presentation System Presentation Brief Description IPC 40.2 The IPC 40.2 is an industrial PC, that represents in combination with a display VDP 16.1, VDP 40.1 or VDP 60.1 a PC-based operator terminal, and that can – depending on the application or configuration – also perform control functionalities. -
Page 8: Variants
System Presentation IPC 40.2 Variants Distinguishing Features There are different variants of the IPC 40.2. The possible variants are described by the type code (see section 10.1). Principally, they differ in the used PC box equipped with 3 or 4 slots. PC box Type A Type C... -
Page 9: Important Directions For Use
The user alone carries all responsibility of the risks. Before using Bosch Rexroth products, make sure that all the pre- requisites for appropriate use of the products are satisfied: •... -
Page 10: Areas Of Use And Application
IPC 40.2 Areas of Use and Application The IPC 40.2 of Bosch Rexroth is an industrial PC, that represents in combination with a display VDP 16.1, VDP 40.1 or VDP 60.1 a PC-based operator terminal, and that can – depending on the application or configuration –... -
Page 11: Safety Instructions For Electric Drives And Controls
If you do not have the user documentation for your equipment, contact your local Bosch Rexroth representative to send this documentation immediately to the person or persons responsible for the safe operation of this equipment. -
Page 12: Hazards By Improper Use
Safety Instructions for Electric Drives and Controls IPC 40.2 Hazards by Improper Use High voltage and high discharge current! Danger to life or severe bodily harm by electric shock! DANGER Dangerous movements! Danger to life, severe bodily harm or material damage by unintentional motor movements! DANGER High electrical voltage due to wrong... -
Page 13: General Information
IPC 40.2 Safety Instructions for Electric Drives and Controls General Information • Bosch Rexroth AG is not liable for damages resulting from failure to observe the warnings provided in this documentation. • Read the operating, maintenance and safety instructions in your language before starting up the machine. -
Page 14: Protection Against Contact With Electrical Parts
Safety Instructions for Electric Drives and Controls IPC 40.2 • Operation is only permitted if the national EMC regulations for the application are met. The instructions for installation in accordance with EMC requirements can be found in the documentation "EMC in Drive and Control Systems". -
Page 15: Protection Against Electric Shock By Protective Low Voltage (Pelv)
IPC 40.2 Safety Instructions for Electric Drives and Controls To be observed with electrical drive and filter components: High electrical voltage on the housing! High leakage current! Danger to life, danger of injury by electric shock! ⇒ Connect the electrical equipment, the housings of all DANGER electrical units and motors permanently with the safety conductor at the ground points before power is... -
Page 16: Protection Against Dangerous Movements
Safety Instructions for Electric Drives and Controls IPC 40.2 Protection Against Dangerous Movements Dangerous movements can be caused by faulty control of the connected motors. Some common examples are: • improper or wrong wiring of cable connections • incorrect operation of the equipment components •... -
Page 17: Protection Against Magnetic And Electromagnetic Fields During Operation And Mounting
IPC 40.2 Safety Instructions for Electric Drives and Controls ⇒ Secure vertical axes against falling or dropping after switching off the motor power by, for example: - mechanically securing the vertical axes - adding an external braking/ arrester/ clamping mechanism - ensuring sufficient equilibration of the vertical axes The standard equipment motor brake or an external brake controlled directly by the drive controller are not... -
Page 18: Protection Against Contact With Hot Parts
Safety Instructions for Electric Drives and Controls IPC 40.2 Protection Against Contact with Hot Parts Housing surfaces could be extremely hot! Danger of injury! Danger of burns! ⇒ Do not touch housing surfaces near sources of heat! Danger of burns! CAUTION After switching the equipment off, wait at least ten (10) ⇒... -
Page 19: 3.11 Battery Safety
IPC 40.2 Safety Instructions for Electric Drives and Controls 3.11 Battery Safety Batteries contain reactive chemicals in a solid housing. Inappropriate handling may result in injuries or material damage. Risk of injury by incorrect handling! ⇒ Do not attempt to reactivate discharged batteries by heating or other methods (danger of explosion and cauterization). - Page 20 3-10 Safety Instructions for Electric Drives and Controls IPC 40.2 Notes DOK-SUPPL*-IPC*40.2***-PR02-EN-P...
-
Page 21: Technical Data
IPC 40.2 Technical Data Technical Data PC Box PC box Type A Type C Processor Pentium III with minimum 933 MHz and integrated graphic controller with maximum 8 MB video memory Main memory 512 MB Min. 10 GB Hard disk CD-ROM or DVD/CD-RW Optional drives •... -
Page 22: Power Supply Unit 115 V / 230 V
Technical Data IPC 40.2 Power Supply Unit 115 V / 230 V Nominal input voltage: 115 VAC / 230 VAC Input voltage range: 85 ... 264 VAC 1.0 A for nominal voltage 230 VAC Input current: 2.0 A for nominal voltage 115 VAC Max. -
Page 23: Ambient Conditions
IPC 40.2 Technical Data Ambient Conditions Operation Storage/transport Max. ambient temperature +5 °C... +45 °C -20 °C to +60 °C (surrounding air temperature) Max. temperature gradient Temporal temperature changes up to 3 °C Not defined per minute Relative humidity Climatic class 3K3 according to Climatic class 3K3 according to EN 60721, condensation not permissible. -
Page 24: Wear Parts
(surrounding air temperature) 25°C 4000 cycles 6 years 35°C 2000 cycles 3 years 45°C 1000 cycles 1.5 years Fig. 4-6: Battery pack If you don't exactly know the conditions, Bosch Rexroth recommends to exchange the battery pack every 1.5 years. DOK-SUPPL*-IPC*40.2***-PR02-EN-P... -
Page 25: Compatibility Test
(e.g. lubricants in machine tools) which may interact with our controls and drives, it cannot be completely ruled out that any reactions with the materials used by Bosch Rexroth might occur. For this reason, before using the respective material a compatibility test has to be carried out for new lubricants, cleaning agents etc. - Page 26 Technical Data IPC 40.2 DOK-SUPPL*-IPC*40.2***-PR02-EN-P...
-
Page 27: Dimensions
IPC 40.2 Dimensions Dimensions Housing Dimensions The IPC 40.2 can be mounted, e. g. in the control cabinet with the help of four fastening holes. The corresponding dimensions are illustrated in the following figure: Vi Vo T UPS HD IPC_40_2_Masse_3Slot.FH9 Fig. -
Page 28: Mounting
Dimensions IPC 40.2 Mounting As accessories brackets are provided (see page 10-3), with which the IPC 40.2 can also be mounted upstanding on a wall: Upstanding with additional bracket Angle* IPC_40_2_Rückansicht_3Slot.FH9 Fig. 5-3: Mounting of the IPC 40.2 upstanding on a wall DOK-SUPPL*-IPC*40.2***-PR02-EN-P... -
Page 29: Display And Operating Components
Monitor and Keyboard To display and operate the IPC 40.2 we recommend the displays VDP 16.1, VDP 40.1 and VDP 60.1 especially designed by Bosch Rexroth for industrial applications. The displays are connected with the IPC 40.2 via the GIGASTAR interface. As an alternative, the IPC 40.2 can also be... -
Page 30: Operating And Error Indication
Display and Operating Components IPC 40.2 Operating and Error Indication In the upper right part of the connector panel there are five LEDs to indicate the device states and errors. Start the measure specified in the following table, if one of the succeeding LEDs indicates an error or a note. Indicator Meaning Measure... -
Page 31: Connections
IPC 40.2 Connections Connections View on the Connector Panel Vi Vo T UPS HD IPC_40_2_Anschlussfeld_3Slot.FH9 Fig. 7-1: Position of the interfaces Interfaces Note: Not each variant provides all the described interfaces. Which interfaces are integrated in the respective device depends on the device configuration. -
Page 32: Overview
Connections IPC 40.2 Overview Des. on the Type of connection Type of connector Mating connector or cable housing (integrated) (from outside) XCOM1, Serial interfaces: D-Sub male connector, 9-pin D-Sub female connector, 9-pin XCOM2, RS232 (UART 16550), not assigned XCOM3 XLPT1 Parallel interface: D-Sub female connector, 25-pin D-Sub male connector, 25-pin... -
Page 33: Serial Interfaces Xcom1 To Xcom3
IPC 40.2 Connections Serial Interfaces XCOM1 to XCOM3 XCOM1 to XCOM3 – Depending on the device variant up to three serial standard interfaces are Serial Interfaces available at the connections XCOM1 to XCOM3. D-Sub male connector, 9-pin Type: RS232 Cable length: Max. -
Page 34: Parallel Interface Xlpt1
Connections IPC 40.2 Parallel Interface XLPT1 XLPT1 – Parallel Interface for D-Sub female connector, 25-pin Printer, Scanner, etc. Type: SPP (ex works), EPP, ECP Cable length: Max. 3 m Cable type: Shielded, cross section min. 0.14 mm² Interrupt (IRQ): I/O address: AUTO or 378H (recommended) XLPT1 Interface mode... -
Page 35: Usb Interfaces
IPC 40.2 Connections USB Interfaces XUSB – Serial Interfaces for The devices feature two USB interfaces on the connector panel (XUSB1 Printer, Scanner, CD-ROM Drive and XUSB2) and one in the device (on the carrier board). Note: The maximum power consumption of the connected device must not exceed 500 mA. -
Page 36: Ethernet Interface Xethernet
Connections IPC 40.2 Ethernet Interface XEthernet XEthernet – Network connection The IPC 40.2 can be connected with an Ethernet network via the XEthernet interface. RJ45 female connector, 8-pin Type: Ethernet 10Base T / 100Base X Cable length: Max. 100 m Cable type: Shielded, twisted pair Transmission rate:... - Page 37 IPC 40.2 Connections HD female connector, 15-pin Cable length: Max. 1.5 m Cable type: Shielded, cross section min. 0.14 mm² Max. resolution: 1600 x 1200 Pixel, max. 4294 mill. colors max. 1.5 m GREEN BLUE XVGA Display RED GND GREEN GND BLUE GND Digital GND Hsync...
-
Page 38: Combined Keyboard/Mouse Interface
Connections IPC 40.2 Combined Keyboard/Mouse Interface XKeyb. – PS/2 Mini DIN PS/2 Mini-DIN female connector, 6-pin Keyboard / Mouse Interface Cable length: Max. 1.5 m Cable type: Shielded, cross section min. 0.14 mm² max. 1.5 m Keyb Keyboard Data Keyboard Mouse Data Power, +5VDC Keyboard Clock... -
Page 39: Pc Power Supply
IPC 40.2 Connections Note: The connected mouse must be PS/2-compatible. Normally, the BIOS reserves IRQ 12 for the PS/2 mouse. If there are address conflicts, e. g., if IRQ 12 has already been occupied by another PC extension card, you should change the IRQ of this extension card to another IRQ, that is still free. -
Page 40: Fig. 7-12: Safety Transformer According To En 60742
7-10 Connections IPC 40.2 Danger without protective separation! ⇒ The 24 VDC input voltage must comply with the requirements of the "Protective separation". Plug and unplug the connector only in no-voltage ⇒ DANGER condition! 400V + 5% 400V 400V - 5% + 24V sichertrafo.cdr Fig. - Page 41 7-11 IPC 40.2 Connections (green/yellow) Power supply with safety transformer acc. to EN 60742 24 VDC Cross-sections depending on current consumption, min. of 4 mm . For higher current con- sumption use 2 x 4 mm . (blue) Length max. 4 m (green/yellow) Earth bar load...
-
Page 42: Fig. 7-15: Pin Assignment Of The 230/115 Vac Connection X20
7-12 Connections IPC 40.2 This connection is used for device variants for 230/115 VAC. X20 – 230/115 VAC Power Supply All internally required voltages are generated by the 230/115 VAC power supply unit. The supply voltage must comply with overvoltage category II! Otherwise the integrated power supply unit might be destructed. -
Page 43: Battery Connection
7-13 IPC 40.2 Connections Incoming mains (green/yellow) Min.16 To control cabinet housing (green/yellow) To machine (green/yellow) All housing components (PE bolt) (green/yellow) PE terminal bar for 0 V wiring (see fig. 2) PE star point (green/yellow) Fuses; motor protection key preferred Overvoltage (green/yellow) category III... -
Page 44: Optional Interfaces
7-14 Connections IPC 40.2 Optional Interfaces Depending on the variant the IPC 40.2 provides a GIGABIT, a GIGABIT3 or a GIGASTAR interface. GIGABIT Interface As display a BF 312T or BF 315T can be connected to the GIGABIT interface. As accessories ready-made cables are provided (see page 10- 3). -
Page 45: Maintenance And Installation
(see chapter "Wear parts" starting on page 4-4). This lithium battery may not be changed by the user. The battery may only be exchanged by the Bosch Rexroth Service (see chapter "Service & Support" starting with page 13-1) or by personnel specially trained and authorized by the Service. -
Page 46: Hard Disk
Maintenance and Installation IPC 40.2 Hard Disk The hard disk frame can be accessed by a cover. The hard disk can be replaced including the installation frame. Loss of data! ⇒ Back up all required application data as well as operating system settings to an external storage medium! CAUTION! -
Page 47: Fig. 8-1: Position Of The Hard Disk's Installation Frame And The Retaining Screw
IPC 40.2 Maintenance and Installation 1. Save all required user data as well as the operating system settings of your system on an external storage medium or via the network connection! 2. Disconnect the power supply. 3. Wait until the power supply unit switches off automatically after UPS operation (the UPS LED on the IPC flashes red until the UPS switches off the power supply unit). -
Page 48: Rechargeable Battery Pack
3 years +45 °C 1000 cycles 1.5 years Fig. 8-2: Number of charging cycles Note: The used batteries are recyclable and can be returned to Bosch Rexroth after replacement. They must not be disposed in the standard household refuse. DOK-SUPPL*-IPC*40.2***-PR02-EN-P... -
Page 49: Fig. 8-3: External Battery Pack
IPC 40.2 Maintenance and Installation For the IPC 40.2 an external battery pack for cabinet mounting is External Battery available. IPC 40.2 Battery pack Externer_Akku_Anschluss.FH9 Fig. 8-3: External battery pack To connect the external batteries proceed as follows: 1. Fix the battery pack in the control cabinet. 2. -
Page 50: Extension Cards
PC box. For this, an unshielded cable with a cross section of at least 1.5 mm² is used. The cable length is maximum 3.0 m. Bosch Rexroth provides ready-made cables with a length of 1.0 m and 3.0 m. Extension Cards To place extensions cards slots for PCI bus and ISA bus are available. -
Page 51: Fig. 8-5: Position Of The Housing Cover And The Mounting Screw
IPC 40.2 Maintenance and Installation Retaining screws Rear covering plate Abdeckung.FH9 Fig. 8-5: Position of the housing cover and the mounting screw 5. The cover closing the air gap must be removed. 6. Remove the fastening screws from the slot cover. 7. - Page 52 Maintenance and Installation IPC 40.2 8. Then, snap in the cover again. 9. Now, mount the slot cover. 10. Plug in the battery cable again. Risk of destruction of the extension card or the main board! ⇒ The combined PCI/ISA bus slot must never be equipped with a PCI card and an ISA card at the CAUTION! same time!
-
Page 53: Bios Settings
IPC 40.2 Maintenance and Installation BIOS Settings Note: IRQ0-IRQ6, IRQ8-IRQ13 and IRQ15 are already assigned and are not available for PCI and ISA extension cards! In the BIOS submenu "The Advanced Menu / PCI Configuration sub PCI Slot menu" you can assign each PCI slot to an IRQ address. By specifying the IRQ address you specify simultaneously the priority. - Page 54 8-10 Maintenance and Installation IPC 40.2 DOK-SUPPL*-IPC*40.2***-PR02-EN-P...
-
Page 55: Software
IPC 40.2 Software Software Application Software of the Monitoring Function Temperature Monitoring The ambient air temperature (surrounding air temperature) of the IPC 40.2 must not exceed +45 °C. To ensure operational reliability, a temperature monitoring function measures internal housing temperature. 1. -
Page 56: Program Ups
Only if the user has special access rights and after re-starting the operating system operation is possible and settings can be made. Note: Modifications of the parameters set in the UPS may only be carried out after consulting Bosch Rexroth. DOK-SUPPL*-IPC*40.2***-PR02-EN-P... -
Page 57: Fig. 9-1: Service Manager Of The Windows Control Panel
IPC 40.2 Software Operation and Configuration of UPS NT Note: To operate UPS administrator rights are necessary! Start/Stop During booting Windows NT the UPS program is automatically started. If the service shall be stopped, terminated or re-started (e.g. because of a re-installation or update), select the service manager in the Windows Control Panel. -
Page 58: Fig. 9-3: The Window "Services
Software IPC 40.2 services_screen.tif Fig. 9-3: The window "Services" Configuration Select the UPS program UPS NT Control in the system control (see Fig. 9-4). Note: The UPS program always runs as a Windows NT service. User changes have no influence on this behavior. The user can not terminate the program without administration rights or stop the monitoring. -
Page 59: Fig. 9-5: "Ups General" Tab
IPC 40.2 Software UPS General After calling up UPS Properties and Maintenance, first, the UPS General tab is active, with which the basic settings of the starting and run time behavior of the UPS are specified. upsc5-general.BMP Fig. 9-5: "UPS General" tab Note: To activate parameter modifications the UPS program is automatically stopped and re-started During this time... - Page 60 Software IPC 40.2 Note: After the expiration of the Shutdown Delay Time the operating system is shut down without safety prompt. Data of opened application programs without backup are then lost. Enable Startup Battery Test: If the check box is activated, a test of the battery pack is carried out after each restart of the system.
- Page 61 IPC 40.2 Software In the Command area an executable program (*.exe; *.bat) can be entered or activated, that can still be started and carried out after the initialization of the shutdown. This is always reasonable, if applications which do not respond to the system messages, have to be backuped or stopped.
-
Page 62: Fig. 9-6: "System Health" Tab
Software IPC 40.2 This tab indicates the current measured values of the internal operating System Health voltages, the battery voltage, the system temperature and the status of the fan function. upsc5-health.BMP Fig. 9-6: "System Health" tab The value of the battery voltage (Battery Voltage) is only updated after a battery test. -
Page 63: Fig. 9-7: "Profi Bus /Mode Com3" Tab
IPC 40.2 Software PROFIBUS and Further Settings The ProfiBus/Mode COM3 tab is divided into two segments: • Select PROFIBUS Address • Selection, if the COM3 interface is provided as serial interface at the XCOM3 plug or is internally connected with the keyboard controller. upsc5-proi-comsel_2.bmp Fig. -
Page 64: Fig. 9-9: "About" Tab
9-10 Software IPC 40.2 About The value Shutdown Count indicated in the About tab indicates, how often the UPS has already shut down the system. A battery change is recommended after more than 3000 trips by the UPS, but not later than the recommended maintenance interval (see section 4.6). -
Page 65: Touch Screen Software
9-11 IPC 40.2 Software Touch Screen Software In the displays VDP 16.1BB, VDP 16.1AC as well as VDP 40.1BE and VDP 40.1AG a touch screen is used, that allows the operation via the touch-sensitive surface of the displays. To ensure the communication of the touch screen controller with the PC, the serial interface XCOM2 is used. - Page 66 9-12 Software IPC 40.2 The program Calibrate might be of special interest. If required, you can calibrate the touch mouse with the help of this program. For this, touch, one after the other, the middle of the four crosses displayed on the screen.
-
Page 67: Ordering Information
10-1 IPC 40.2 Ordering Information Ordering Information 10.1 Type Code The IPC 40.2 is available in various variants according to the following type code. Abbrev. Column 1 2 3 4 6 7 8 9 1 2 3 4 6 7 8 9 1 2 3 4 6 7 8 9 1 2 3 4... -
Page 68: 10.2 Accessories
10-2 Ordering Information IPC 40.2 10.2 Accessories Network Connection Ordering designation Part number Description of tag configured in the tags database B-AC STECKER NETZ 230V 1070 912881 Mains connector 230 V, male inlet connector for non- heating apparatus, angular, for self-mounting BKS-U-N-NTZKAB-IPCRHO-002,5-P 1070 048937 Mains cable 230 V with female inlet connector for non-... -
Page 69: List Of Figures
11-1 IPC 40.2 List of Figures List of Figures Fig. 1-1: IPC 40.2 with 3 slot box 1-1 Fig. 1-2: PC box, type A and type C 1-2 Fig. 3-1: Hazard classification (according to ANSI Z535) 3-1 Fig. 4-1: Technical data: PC box 4-1 Fig. - Page 70 11-2 List of Figures IPC 40.2 Fig. 9-2: Indication of the operating status of the service in the Windows task bar 9-3 Fig. 9-3: The window "Services" 9-4 Fig. 9-4: Symbol "UPS NT Control" in the Windows Control Panel 9-4 Fig.
-
Page 71: Index
12-1 IPC 40.2 Index Index Accessories 10-2 Air pressure 4-3 Ambient Conditions 4-3 Ambient temperature 4-3 Appropriate use Introduction 2-1 Uses 2-2 Battery Pack 10-2 BIOS Settings 8-9 Buffer battery 8-1 CMOS Battery 8-1 Combined keyboard/mouse interface 7-8 Compatibility test 4-5 Connections 7-1, 7-2 Connectors 7-2 Delay time 9-5... - Page 72 12-2 Index IPC 40.2 Mounting 5-2 Mouse interface 7-8 Network connection 10-2 Operating and Error Indication 6-2 Operation and configuration of UPS NT 9-3 Ordering information 10-1 Parallel interface XLPT1 7-4 Pin assignment of the 230/115 VAC connection X20 7-12 PS/2 keyboard connection 7-8 PS/2 mouse connection 7-8 Relative humidity 4-3...
- Page 73 12-3 IPC 40.2 Index VGA connection 7-7 VGA interface 7-6 Video adapter CRT 7-7 Voltage connection 230 VAC via isolating transformer 7-13 Wiring of the power connection 24 VDC and the IPC 40.2 terminal 7-11 XCOM1 7-3 XCOM2 7-3 XCOM3 7-3 XLPT1 interface 7-4 XVGA interface 7-7 DOK-SUPPL*-IPC*40.2***-PR02-EN-P...
