Keiser M3 Calibration Procedure

CALIBRATION PROCEDURE
KEISER M3/M3i & M5/M5i CARDIO EQUIPMENT
BEFORE YOU BEGIN, PLEASE NOTE:
• Calibration is only required if (1) the computer has
been replaced or (2) the Magnet Assembly has been
disassembled.
• This calibration procedure applies to computer software
version U406 and above (production models built mid-
September 2009 and beyond, see Figure 1).
• To check the software version, remove the batteries for
20 seconds, then reinstall the batteries (see Figure 2).
Observe the computer display during start-up and look
for "U###". Note: Allow the computer to sleep before
normal usage.
• This calibration procedure requires a Calibration Tool,
included in the kit that you received (PN 555089).
• STEP 3 through STEP 6 must be completed within
30 seconds. After 30 seconds the computer will exit
calibration mode and must be allowed to sleep before
attempting calibration again.
PREPARATION:
M Series Indoor Cycles
(M3/M3i, M3+, M3/M3i Total Body Trainer, M3X/M3iX)
1. Place the Cycle on a flat, level surface with clear
access to the left side.
2. Set the Resistance Lever to the lowest position.
M Series Strider Ellipticals
(M5/M5i)
1. Place the Strider on a flat, level surface with clear
access to the right side.
2. Set the Resistance Lever to the lowest position.
3. Set the right Footpad in the down position.
4. Remove the three screws of the Access Port
(#1 Phillips Screwdriver) to access the Magnet
Assembly, see Figure 4.
Remove qty 3
screws using
a #1 Phillips
Screwdriver
PLEASE READ ALL INSTRUCTIONS CAREFULLY
Figure 4. M Series Strider Elliptical Preparation
MODEL: 005602XXX
│ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │
SERIAL NO.: 888888-88888
│ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │ │
YYMMDD-888888
Figure 1. Serial Number
Date Code
Figure 3. M Series Indoor Cycle Preparation
1
Remove
using a #1
Phillips
Screwdriver
1
2
Figure 2. Battery Access
