Tripp Lite N286-10GSR-MDLC Quick Start Manual

Cisco Compatible 10GBASE-SR SFP+ Transceiver
Product Features
• 10GBASE-SR transceiver supports data transfer rates up to
11.1Gbps
• Compliant with SFP Multi-Source Agreement (MSA) standards
• Electrical interface compliant with SFF-8431
Package Includes
• N286-10GSR-MDLC
Optional Accessories
• N820-Series 10Gb Duplex Multimode 50/125 LC Fiber Cables
Installation
Notes:
• SFP transceiver modules are static sensitive devices that require proper handling. An Anti-Static ESD Wrist Strap or similar device should always be used when
handling a transceiver module.
• The transceiver module should never be installed with cables already connected. Always remove cables prior to installation to avoid damaging the cable, cable
connectors, and/or optical interface.
• Installing and uninstalling the transceiver module numerous times will shorten its useful lifespan. Do not uninstall and reinstall the module more than is
absolutely necessary.
1. Remove the transceiver module from its packaging, leaving the dust plugs inserted in the LC optical bores.
2. Gently insert the transceiver module into the module socket of your device, pressing on the dust plugs until it locks into place.
3. Verify that the transceiver module is locked into place by trying to remove it from the module socket without releasing the latch. If it stays in
place, it is seated properly. If not, you will need to re-insert it, firmly pressing on the dust plugs until it locks into place.
4. Once you have verified that the transceiver module is securely locked in place, you can remove the dust plugs from the LC optical bores and
connect your cabling.
Note: Save the dust plugs so that they can be used in the event that the transceiver module needs to be uninstalled and reinstalled.
Register your product for quicker service and ultimate peace of mind.
You could also win an ISOBAR6ULTRA surge protector—a $100 value!
Quick Start Guide
with DDM, MMF, 850 nm, 300 m, LC
Model: N286-10GSR-MDLC
Español 3 • Français 5 • Русский 7
PROTECT YOUR INVESTMENT!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
• Supports Digital Diagnostic Monitoring (DDM)
• 300 m transmission distance using 10Gb 50/125 MMF cabling
• Cisco switch compatible
• Hot-pluggable
• Quick Start Guide
• P999-000 Anti-Static Wrist Strap
1
