Transceiver with MMF,
16-09-100-9335FD-EN.indd 1
Quick Start Guide
HP Compatible
1000Base-SX SFP
850 nm, 550 m, LC
Model: N286-01GSX-MLC
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
www.tripplite.com/support
Copyright © 2016 Tripp Lite. All rights reserved.
1
9/12/2016 10:08:43 AM

Advertisement

Table of Contents
loading

Related Manuals for Tripp Lite N286-01GSX-MLC

Summary of Contents for Tripp Lite N286-01GSX-MLC

  • Page 1 Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a $100 value! www.tripplite.com/warranty 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support Copyright © 2016 Tripp Lite. All rights reserved. 16-09-100-9335FD-EN.indd 1 9/12/2016 10:08:43 AM...

  • Page 2: Product Features

    50/125 MMF cabling or 722 ft. (220 m) using 62.5/125 MMF cabling • HP switch compatible • Hot-pluggable Package Includes • N286-01GSX-MLC • Quick Start Guide Optional Accessories • N520-Series Duplex Multimode 50/125 LC Fiber Cables • N320-Series Duplex Multimode 62.5/125 LC Fiber Cables •...

  • Page 3: Installation

    Installation Notes: • SFP transceiver modules are static-sensitive devices that require proper handling. An anti-static ESD wrist strap or similar device should always be used when handling a transceiver module. • The transceiver module should never be installed with cables already connected. Always remove cables prior to installation to avoid damaging the cable, cable connectors, and/or optical interface.
  • Page 4 Installation 4. Once you have verified the transceiver module is securely locked in place, remove the dust plug from the LC optical bores and connect your cabling. Note: Save the dust plug so it can be used in the event the transceiver module needs to be uninstalled and reinstalled.

  • Page 5: Specifications

    Specifications Industry Standards IEEE 802.3z Fiber Optic Gigabit Ethernet Connector Type LC Duplex Maximum Data 1000 Mbps Transfer Rate Maximum 1,804 ft. (550 m) using 50/125 MMF Transmission cabling or 722 ft. (220 m) using Distance 62.5/125 cabling Wavelength 850 nm Fiber Operating Half/Full Duplex Mode...

  • Page 6: Warranty And Product Registration

    Warranty and Product Registration 3-Year Limited Warranty TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE’s obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products.
  • Page 7 • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user’s authority to operate this equipment. 16-09-100-9335FD-EN.indd 7...

  • Page 8: Regulatory Compliance

    (this varies depending on the country) • Send the new equipment back for recycling when this ultimately becomes waste Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. 1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support...
