Quick Start Guide
10GBase-LR SFP+ Transceiver
with DDM, 1310 nm, 10 km,
SMF, LC - Cisco SFP-10G-LR-S
Compatible
Model: N286-10G-LR-S
Este guía esta disponible en español en la página de
Tripp Lite: tripplite.com/support
Ce guide est disponible en français sur le site Web de
Tripp Lite : tripplite.com/support
Русскоязычная версия настоящего краткого
руководства представлена на веб-сайте компании
Tripp Lite по адресу: tripplite.com/support
WARRANTY REGISTRATION
Register your product today and be automatically entered to
win an ISOBAR surge protector in our monthly drawing!
tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA
tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
1
19-09-127-933B38-EN.indd 1
9/25/2019 1:43:16 PM
Advertisement
Table of Contents
Related Manuals for Tripp Lite N286-10G-LR-S
Summary of Contents for Tripp Lite N286-10G-LR-S
- Page 1 10GBase-LR SFP+ Transceiver with DDM, 1310 nm, 10 km, SMF, LC - Cisco SFP-10G-LR-S Compatible Model: N286-10G-LR-S Este guía esta disponible en español en la página de Tripp Lite: tripplite.com/support Ce guide est disponible en français sur le site Web de Tripp Lite : tripplite.com/support...
-
Page 2: Product Features
• Compliant with Common Management Spec SFF-8472 and SFF-8431 (with duplex LC receptacle) • Supports Digital Diagnostic Monitoring (DDM) • Full-metal housing emits low EMI • Hot-pluggable • Cisco switch compatible Package Includes • N286-10G-LR-S • Quick Start Guide 19-09-127-933B38-EN.indd 2 9/25/2019 1:43:16 PM... -
Page 3: Optional Accessories
Optional Accessories • N370-Series Duplex Singlemode 8.3/125 LC Fiber Cables • P999-000 Anti-Static Wrist Strap Installation Notes: • SFP transceiver modules are static-sensitive devices that require proper handling. An anti-static ESD wrist strap or similar device should always be used when handling a transceiver module. •... - Page 4 Installation 2. Gently insert the transceiver module into the module socket of your device. Press the dust plug until it locks into place. 3. Verify the transceiver module is locked into place by trying to remove it from the module socket without releasing the latch.
-
Page 5: Specifications
Specifications Industry Standards IEEE 802.3z Fiber Optic Gigabit Ethernet IEEE 802.3ae Fiber Optic 10 Gigabit Ethernet Connector Type LC Duplex Maximum Data Transfer 11.1 Gbps Rate Maximum Transmission 6 mi. (10 km) using Distance 8.3/125 ~ 10/125 SMF cabling Wavelength 1310 nm Fiber Operating Mode Half/Full Duplex... -
Page 6: Warranty And Product Registration
Warranty and Product Registration 3-Year Limited Warranty Seller warrants this product, if used in accordance with all applicable instructions, to be free from original defects in material and workmanship for a period of 3 years from the date of initial purchase. - Page 7 Warranty and Product Registration PRODUCT REGISTRATION Visit tripplite.com/warranty today to register your new Tripp Lite product. You’ll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!* * No purchase necessary. Void where prohibited. Some restrictions apply.
- Page 8 Warranty and Product Registration WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union) Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to: •...
