Summary of Contents for Smeg Tumble Dyer AS 61 E
- Page 1 AS 61 E Dryer Asciugatrice...
-
Page 2: General Safety
Warnings Please read the following information. Otherwise, there may be the risk of personal injury or material damage. Moreover, any warranty and reliability commitment will become void. General Safety • Never place your machine on a carpet covered floor. Otherwise, lack of airflow from below of your machine may cause electrical parts to overheat. -
Page 3: Installation
When available a drying rack could be used for such items. • Plastic articles such as shower caps or babies’ waterproof napkin covers should not be placed in a tumble dryer. • Rubber-backed articles, clothes fitted with foam rubber pads, pillows, galoshes and rubber-coated tennis shoes should not be placed in a tumble dryer. If there are children in your house... • Electrical appliances may be dangerous for the children. -
Page 4: Connection To A Water Drain (For Products Equipped With A Condenser)
extended directly to the outdoors. There must be a small number of elbows as not to hinder air ventilation. The ventilation hose can be routed outdoors via a window or it can be connected to the air outlet in the bathroom. To prevent water accumulation in the hose, make sure that it is not folded on the floor. -
Page 5: Before Drying
Before drying Always follow the advice on the garment labels. With this dryer, dry only the laundry having a label stating that they are suitable for drying in a dryer by selecting the appropriate program. High- Normal- Suitable for temperature temperature drier Drying Drying Dry on a Hang without horizontally hanger spinning Can be Can be ironed Do not iron ironed with with hot iron warm iron • Laundry items with metal attachments such as, belt buckles and metal buttons can... -
Page 6: Control Panel
Selecting a Program and Operating Your Machine Control panel Pulire Filtri 1. On/Off button 2. Program selection knob 3. Start/Pause/Cancel button 4. Low temperature 5. Program follow-up indicator 6. Filter cleaning warning LED Bassa Avvio Pausa Temperatura Refresh 7. Water tank full warning LED* 8. Time delay button * * According to your machine’s model 6 - EN On/Off... -
Page 7: Turning The Machine On
Turning the machine on Prepare machine for program selection by pressing the “On/Off” button. Pressing the “On/Off” button does not necessarily mean that the program has started. Press "Start/Pause/Cancel" button of the machine to start the program. Timer program selection Decide the appropriate time from the table below which includes drying temperature in degrees. Select the desired time with the timer program selection button. Extra dry Dry at high temperature only for cotton laundry. -
Page 8: Program Selection And Consumption Table
Program selection and consumption table Program table Programs Cottons / Coloreds Ready to Wear Ready to Iron Synthetics Ready to Wear Delicates Ready to Wear Energy consumption values Programs Cottons linen Ready to wear* Cottons Ready to iron Synthetics&Mixed fabrics Ready to wear * : Energy Label standard program (EN 61121:2005) All values given in the table have been fixed according to EN 61121:2005 Standard. These... -
Page 9: Warning Indicators
Auxiliary function Low temperature This function allows for drying at lower temperatures and therefore saves energy. Warning LED will light up when you select the function. You must use this function when you dry your synthetic or delicate laundry. Warning indicators Warning indicators may differ according to the model of your machine. Filter cleaning A warning LED will light up to remind filter cleaning after the program finishes. If the filter cleaning warning LED lights up continuously, please refer to, “Solution suggestions for problems”. -
Page 10: Technical Specifications
program. To cancel any selected program; • Press “Start/Pause/Cancel” button for about a duration of 3 seconds. The “Filter cleaning” and “Water tank” warning LEDs as well as the “0” warning LED on the program follow-up indicator will light up at the end of this period for reminding purposes. As the inside of the machine will be excessively hot when you cancel the program while the machine is running, activate the ventilation program to cool it down. Technical Specifications Models Height / Height for built-under installation (cm) -
Page 11: Maintenance And Cleaning
Maintenance and cleaning Fluff filter Lint and fibres released from the laundry to the air during the drying cycle are collected in the “Fluff Filter”. Such fibre and lint are generally formed during wearing and washing. Always clean the filter after each Drying process. You can clean the filter and filter area by vacuum cleaner. For Filter cleaning; 1 Open the cover 2 Remove the fluff filter by pulling it up and open the filter. -
Page 12: Solution Suggestions For Problems
Solution suggestions for problems Problem Cause Drying process takes Cover filter and filter drawer might have too much time. not been cleaned. * Cover filter and filter drawer might Laundry come out wet have not been cleaned. at the end of drying. * Excessive laundry might have been loaded in. * It might have not been plugged in. * The loading door may be ajar. * Program might have not been set or Machine does not the “Start/Pause/Cancel” button might switch on or the have not been pressed.
