- Page 1 AS 63 CS Dryer Asciugatrice...
-
Page 2: Safety Instructions
Warnings Please read the following information. Otherwise, there may be the risk of personal injury or material damage. Moreover, any warranty and reliability commitment will become void. General Safety • Never place your machine on a carpet covered floor. Otherwise, lack of airflow from below of your machine may cause electrical parts to overheat. -
Page 3: Installation
When available a drying rack could be used for such items. • Plastic articles such as shower caps or babies’ waterproof napkin covers should not be placed in a tumble dryer. • Rubber-backed articles, clothes fitted with foam rubber pads, pillows, galoshes and rubber-coated tennis shoes should not be placed in a tumble dryer. If there are children in your house... • Electrical appliances may be dangerous for the children. -
Page 4: Connection To A Water Drain (For Products Equipped With A Condenser)
extended directly to the outdoors. There must be a small number of elbows as not to hinder air ventilation. The ventilation hose can be routed outdoors via a window or it can be connected to the air outlet in the bathroom. To prevent water accumulation in the hose, make sure that it is not folded on the floor. -
Page 5: Before Drying
Before drying Always follow the advice on the garment labels. With this dryer, dry only the laundry having a label stating that they are suitable for drying in a dryer by selecting the appropriate program. Hochtemper Normaltemper Für Trockner aturtrocknung aturtrocknung geeignet Horizontal Ohne trocknen Kleiderbügel Schleudern trocknen aufhängen Kann warm Kann heiß Nicht bügeln gebügelt gebügelt werden werden • Laundry items with metal attachments such... -
Page 6: Control Panel
Selecting a Program and Operating Your Machine Control panel Asciugatura Pulire Filtri Pronto Svuotare Stiro Contenitore Asciutto Armadio Fine 1. On/Off button 2. Program selection knob 3. Start/Pause/Cancel button 4. Cancel Audio Warning 5. Program follow-up indicator Sintetici Pronto Tempo Stiro Programmato 10 min 20 min 40 min Stop Avvio 60 min... -
Page 7: Program Selection
Turning the machine on Prepare machine for program selection by pressing the “On/Off” button. Pressing the “On/Off” button does not necessarily mean the program has started. Press “Start/Pause/Cancel” button to allow the machine start the program. Program selection Decide the appropriate program from the table below which includes drying temperature in degrees. Select the desired program with the program selection button. Dry at high temperature only for cotton laundry. Thick and multi layered Extra dry laundry (E.g.: towels,... -
Page 8: Program Selection And Consumption Table
Program selection and consumption table Program table Programs Cottons / Coloreds Ready to Wear Ready to Iron Synthetics Ready to Wear Delicates Ready to Wear Energy consumption values Programs Cottons linen Ready to wear* Cottons Ready to iron Synthetics&Mixed fabrics Ready to wear * : Energy Label standard program (EN 61121:2005) All values given in the table have been fixed according to EN 61121:2005 Standard. These... -
Page 9: Auxiliary Function
Auxiliary function Buzzer Cancel Models Equiped Your machine will send out an buzzer warning when the program comes to an end. If you do not want to hear this buzzing, you need to press the “Cancel Audio Warning” button. The relevant LED will light up when this button is pressed and an audio warning will not be given when the program comes to an end. Warning indicators Warning indicators may differ according to the model of your machine. Filter cleaning A warning LED will light up to remind filter cleaning after the program finishes. -
Page 10: Technical Specifications
Ending the program through canceling The program which is selected first will keep on going even if the position of the program selection button is changed. A new program can be selected and started after “Program cancel” is activated in order to change the drying program. In order to cancel the selected program; press “Start/Pause/Cancel” button for about 3 seconds. The “Filter cleaning”, “Water tank” and “End/ Anti- creasing” warning LEDs will light up at the end of this period for reminding purposes. As the inside of the machine will be excessively hot when you cancel the program while the machine is running, activate the... -
Page 11: Maintenance And Cleaning
Maintenance and cleaning Fluff filter Lint and fibres released from the laundry to the air during the drying cycle are collected in the “Fluff Filter”. Such fibre and lint are generally formed during wearing and washing. Always clean the filter after each Drying process. You can clean the filter and filter area by vacuum cleaner. For filter cleaning; Open the cover. Remove the fluff filter by pulling it up and open the filter. Clean lint, fibre, and the fluff by hand or with a soft piece of cloth. Close the filter and place it back into its seat. -
Page 12: Solution Suggestions For Problems
Solution suggestions for problems Problem Cause Drying process takes Cover filter and filter drawer might have too much time. not been cleaned. * Cover filter and filter drawer might Laundry come out wet have not been cleaned. at the end of drying. * Excessive laundry might have been loaded in. * It might have not been plugged in. * The loading door may be ajar. * Program might have not been set or Machine does not the “Start/Pause/Cancel” button might switch on or the have not been pressed.
