Portable Evaporative Air Cooler User Manual Read and save these instructions before use Model: CS04XE www.honeywellaircoolers.com E-mail: info@honeywellaircoolers.com...
PARTS DESCRIPTION POWER SPEED COOL MODE SWING Control Panel Front Grill Screws Louvers Honeycomb Cooling Media Front Grill Mounting Holes Water Fill Tray Drain Plug Water Level Indicator Power Cord & Plug WARNING -- READ AND SAVE THE AIR COOLER SAFETY & MAINTENANCE GUIDE AND USER MANUAL BEFORE USING THIS PRODUCT.
USE & OPERATION CONTROL PANEL POWER SPEED MODE COOL SWING FUNCTION BUTTONS POWER Press the POWER button to turn the unit on. The cooler will start automatically at medium speed. After a few seconds the speed will switch to low. To turn the unit off, press the button again. SPEED Press the SPEED button repeatedly to change the speed between H - M - L.
USE & OPERATION (CONTINUED) REMOTE CONTROL POWER ON / OFF SPEED Low / Medium / High MODE Evaporative cooling ON / OFF SWING Controls the motion of the louvers NOTE: • The remote control requires AAA (2 x 1.5V) batteries for replacement. •...
USE & OPERATION (CONTINUED) COOLER LOCATION Make sure to position the air cooler correctly before you set up and start using the product. Do not move the unit from one place to another while the Unit is turned on. Please refer to the COOLER LOCATION section of the separate Safety &...
Page 6
USE & OPERATION (CONTINUED) CLEANING & DRAINING THE WATER TANK Below are instructions on how to clean and maintain your air cooler. If the cooler will not be used for a long period of time, please refer to the STORAGE & MAINTENANCE GUIDELINES located in the separate Safety &...
Page 7
USE & OPERATION (CONTINUED) CLEANING THE HONEYCOMB COOLING MEDIA • The appliance is supplied with a Honeycomb Cooling Media. • The Honeycomb Cooling Media is located inside the Rear Grill. See Figure 1 for instructions on how to remove them from the unit for cleaning and maintenance. •...
