Honeywell XYR 6000 User Manual

Temperature
Hide thumbs Also See for XYR 6000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
OneWireless
XYR 6000 Temperature Transmitter
User's Manual
34-XY-25-16
Revision 2
8/7/07

Advertisement

Table of Contents
loading

Related Manuals for Honeywell XYR 6000

Summary of Contents for Honeywell XYR 6000

  • Page 1 OneWireless XYR 6000 Temperature Transmitter User's Manual 34-XY-25-16 Revision 2 8/7/07...
  • Page 2 In no event is Honeywell liable to anyone for any indirect, special or consequential damages. The information and specifications in this document are subject to change without notice.

  • Page 3: About This Document

    Transmitters. Mounting, installation and wiring are covered in other documents. Honeywell does not recommend using devices for critical control where there is a single point of failure or where single points of failure result in unsafe conditions. The initial release of OneWireless (R100) is targeted at open loop control, supervisory control, and controls that do not have environmental or safety consequences.
  • Page 4 Contact: Honeywell Global TAC – China Phone: +86- 21-5257-4568 Mail: Honeywell (China) Co., Ltd 33/F, Tower A, City Center, 100 Zunyi Rd. Shanghai 200051, People’s Republic of China Email: Global-TAC-China@honeywell.com OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...
  • Page 5 20th Floor, 1-16-1 Kaigan, Minato-ku, Tokyo 105-0022, Japan Email: Global-TAC-JapanJA25@honeywell.com World Wide Web Honeywell Solution Support Online: http://www.honeywell.com/ps Elsewhere Call your nearest Honeywell office. Training Classes Honeywell Automation College: http://www.automationcollege.com Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...

  • Page 6: Symbol Definitions

    Chassis Ground: Identifies a connection to the chassis or frame of the equipment shall be bonded to Protective Earth at the source of supply in accordance with national and local electrical code requirements. OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...

  • Page 7: Table Of Contents

    Parameter details........................12 OPERATION......................13 Overview............................13 Display modes..............................13 Authentication Device............................13 Transmitter PV display....................... 13 Transmitter quick view of parameters..................16 Transmitter menu ........................17 Menu tree ................................17 Authentication device menus....................18 Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...
  • Page 8 Procedure ................................24 Replacing batteries ........................25 When to replace..............................25 Tools required..............................25 Procedure ................................25 Replacing antenna........................27 Tools required..............................27 Procedure ................................27 Parts ............................. 29 viii OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...
  • Page 9 Table 8 Buttons for Device Local Configuration ..................20 Table 9 Advanced Options.......................... 23 Table 10 Display/sensor module replacement.................... 24 Table 11 Battery replacement procedure....................26 Table 12 Antenna replacement procedure....................28 Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...
  • Page 10 Contents Figures Figures Figure 1 XYR 6000 Functional Diagram ...................... 2 Figure 2 Terminal connections for calibration ....................7 Figure 3 Block Diagram..........................11 Figure 4 Main menu ............................ 18 Figure 5 Security and Device Deployment....................19 Figure 6 Device Local Configuration screen ....................20 Figure 7 Read Device Information ......................

  • Page 11: Introduction

    • Details of topics that relate uniquely to the Honeywell XYR 6000 Temperature Transmitter, • This manual does not cover installation, mounting, or wiring. See XYR 6000 Transmitter Quick Start Guide (document 34-XY-25-21). OneWireless network overview OneWireless is an all digital, serial, two-way communication mesh network that interconnects industrial field sensors to a central system.

  • Page 12: Figure 1 Xyr 6000 Functional Diagram

    The Process Variable (PV) is available for monitoring and alarm purposes. Available PV update rates are 1, 5, 10, 30 seconds and are set on Wireless Builder. Slower update rates extend battery life. Figure 1 shows a block diagram of the XYR 6000 Temperature transmitter’s operating functions. Radio...

  • Page 13: Specifications

    Enclosure Type Type 4X, IP 66/67 For detailed transmitter specifications see the following Specification and Model Selection Guides. • XYR 6000 Wireless Transmitter Temperature (document 34-XY-03-29) Authentication Device Install the Authentication Device application on any PDA having • Windows Mobile version 4.2+ •...

  • Page 14: Preparation

    3.1. Installation 3. Preparation Installation Refer to the XYR 6000 Transmitter Quick Start Guide (document 34-XY-25-21) for installation, mounting and wiring of your XYR 6000 transmitter. Configuration The XYR 6000 Transmitter contains the electronics interface compatible for connecting to the OneWireless network.

  • Page 15: User Calibration

    Repeat steps 1 through 6 for each channel you want to calibrate. Reverse steps 3 and 4. When ready, in Wireless Builder return the transmitter’s channel to service and set Write Lock to Locked. Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...

  • Page 16: Table 2 User Calibration: Ohms

    Replace 1000 ohm wire with 0 ohm wire. Verify the PV for that channel is reading 0 ohms. Remove calibration wiring and re-connect sensor wires. When ready, in Wireless Builder return the transmitter’s channel to service and set Write Lock to Locked. OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...

  • Page 17: Figure 2 Terminal Connections For Calibration

    3. Preparation 3.4. Calibrating the transmitter Figure 2 Terminal connections for calibration Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...

  • Page 18: Table 3 Calibration Error Messages

    Typically this indicates that the applied calibration value was significantly different from the expected value or that the sensor is not within expected tolerances for the applied characterization. OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...

  • Page 19: Restore Calibration

    Display will say BUSY, then SUCCESS. If unsuccessful the display will show BAD_FACTORY_CALIBRATION. When ready, in Wireless Builder return the transmitter’s channel to service and set Write Lock to Locked. Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...

  • Page 20: Clear Calibration

    Press Enter to continue. Display will say BUSY, then SUCCESS. Repeat for each channel desired. When ready, in Wireless Builder return the transmitter’s channel to service and set Write Lock to Locked. OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...

  • Page 21: Function Blocks

    Each of these blocks contains parameters that are standard WNSIA-transmitter defined parameters. The AITB and device blocks contain standard parameters common to all XYR 6000 transmitter models (that is, pressure, temperature, corrosion, HLAI) as well as temperature-specific parameters. The radio block contains parameters for communication with the wireless network.

  • Page 22: Parameter Details

    The transmitter itself displays a few basic parameters, such as tag, serial number, device revision, build, device address, WF ID. For more information on parameters, refer to the following documents. • OneWireless Wireless Builder User’s Guide • OneWireless Builder Parameter Reference OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...

  • Page 23: Operation

    If two or more device status messages are in effect they are displayed alternating with the Table 4 PV engineering units Engineering units Description Deg C Degrees Celsius Deg F Degrees Fahrenheit Millivolts Ohms Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...

  • Page 24: Table 5 Pv Status

    Calibration Data Invalid Use Cal Clear, Restore, or User or could not be read. Calibrate. NO RADIO DEV_ST_RADIO_ERR Radio Board is not Check radio board installed. accessible. Replace radio board. OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...
  • Page 25 Bit 3 Radio Frequency The radio processor detected error FHSS Hopping Spread on internal radio circuitry. Replace Spectrum Radio circuitry radio board. failure *Can also cause E FAIL message. Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...

  • Page 26: Transmitter Quick View Of Parameters

    This parameter changes whenever objects and parameters are added, deleted, or the data type or range changes. It does not change if the application firmware changes without affecting the device description. Build Sensor firmware number OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...

  • Page 27: Transmitter Menu

    CONNECTED means the transmitter radio and a multinode have detected each other. It does not necessarily mean security has been enabled or that the Wireless Builder has sensed the transmitter. NOT CONNECTED means radio communcations with a multinode Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...

  • Page 28: Authentication Device Menus

    Hold the Authentication Device no more than 6” (15 cm) from the transmitter and aim the infrared beam at the transmitter display while tapping on the screen command or button. Main menu The main menu is shown below. Figure 4 Main menu OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...

  • Page 29: Security And Device Deployment

    OneWireless network. To verify your transmitter has been authenticated, see Security under Read Device Info (page 21). For more details on keys, refer to Getting Started with Honeywell OneWireless Solutions. Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual...

  • Page 30: Device Local Configuration

    During number entry, decrement the digit or change +/- sign. • Go to the upper menu level. • When changing a number value, move cursor to the left/more significant digit, then wrap around to the least significant digit. OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...

  • Page 31: Read Device Information

    Modes: US Channel number 1 US Channel number 6 US Channel number 11 Guard bands outside US Channel number 1, 6 and 11 Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...
  • Page 32 Security Establishing - a security key has been sent to the transmitter and the transmitter is waiting for authentication by a multinode. Security Enabled - the transmitter has been authenticated by the OneWireless network. OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...

  • Page 33: Advanced Options

    Select Infrared Communication Overrides the detected infrared communication port detected on your PDA. If Port infrared communication is not functioning, you can override the detected settings using this option. Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...

  • Page 34: Maintenance/Repair

    Table 10 Display/sensor module replacement Step Action Honeywell recommends that the transmitter be removed from service and moved to a clean area before servicing. Loosen the M3 locking set screw on the display end-cap. See item 1 in Figure 9. Unscrew and remove the end cap.

  • Page 35: Replacing Batteries

    • The batteries used in this device may present a risk of fire or chemical burn if mistreated. Do not recharge, disassemble, heat above 100°C (212°F), or incinerate. Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...

  • Page 36: Table 11 Battery Replacement Procedure

    Mixing old and new batteries or different manufacturers is not permitted. Use only the following 3.6V lithium thionyl chloride (Li-SOCl2) batteries (non-rechargeable), size D. No other batteries are approved for use in XYR 6000 Wireless Transmitters. • Xeno Energy XL-205F •...

  • Page 37: Replacing Antenna

    POTENTIAL ELECTROSTATIC CHARGING HAZARD The integrally mounted antenna shroud is made of Teflon® and has a surface resistance greater than 1Gohm per square. When the XYR 6000 transmitter is installed in potentially hazardous locations care should be taken not to electrostatically charge the surface of the antenna shroud by rubbing the surface with a cloth, or cleaning the surface with a solvent.

  • Page 38: Table 12 Antenna Replacement Procedure

    See items 2 in Figure 11. Torque screws to 0,4 – 0,6 N-M (3.5 – 5.3 Lb-in). Replace the front end cap. Honeywell recommends lubricating the front end cap O-ring with a Silicone Grease such as Dow Corning #55 or equivalent before replacing the end cap.

  • Page 39: Parts

    6. Maintenance/Repair 6.4. Parts Antenna connector Figure 11 Antenna replacement Parts For other replacement parts refer to XYR 6000 Wireless Transmitter Temperature Specification (document 34-XY-03-29). Revision 2 OneWireless XYR 6000 Temperature Transmitter User's Manual 8/7/07...
  • Page 40 6. Maintenance/Repair 6.4. Parts OneWireless XYR 6000 Temperature Transmitter User's Manual Revision 2 8/7/07...
  • Page 42 Honeywell International Process Solutions 2500 West Union Hills Phoenix, AZ 85027...
