Venturi tubes.

Venturi Tube Spider Web
18
Keep the Venturi Tubes Clean
Blockages caused by spiders, insects
and nests can cause a flashback fire.
Although the grill may still light, the
backed up gas may also ignite and
cause a fire around the venturi tubes
at the control panel or side burner.
If a flashback fire occurs, turn the
gas off immediately by closing the
LP tank valve.
Inspecting and Cleaning the Venturi Tubes
1. Turn the gas off by closing the
LP tank valve.
2. When grill is cool, remove main
burner fasteners from grill bottom;
lift the main burner from the grill
housing.
3. Clean the venturi tubes with a pipe
cleaner or venturi cleaning tool.
Inspect and clean the venturi tubes (main
burners, side burner, rotisserie burner)
if any of the following symptoms occur:
1. You smell gas.
2. Your grill does not reach temperature.
3. Your grill heats unevenly.
4. The burners make popping noises.
4. Lower the burner into position in
the grill housing, making sure that
the venturi tubes are correctly aligned
and fitted on the orifices.
5. Secure the main burner with the
burner fasteners.
Make sure
correctly
fitted.
