Chapter 1 - Product Overview Package Contents The following items are included in your AirStation package. If any of the items are missing, please contact your vender. • AirStation ............................1 • Case ..............................1 • Ethernet Cable ..........................1 •...
Chapter 1 Product Overview Hardware Overview RESET RESET RESET INTERNET INTERNET INTERNET USB cable Connect to PC, or USB power adapter. Internet LED (Green) The Internet port is connected. Blinking: The Internet port is not connected. Off: Router functionality is disabled. Power/Diag LED (Green or Red) On (Green): Power is on, and WLAN is enabled.
Page 5
Chapter 1 Product Overview 2 blinks (Red) Flash ROM error. 3 blinks (Red) Wired Ethernet LAN error. 4 blinks (Red) Wireless LAN error. 5 blinks (Red) IP address setting error. 9 blinks (Red) System error. Continuously blinking : Updating firmware, saving settings, or initializing settings. *1 Never unplug the USB cable while the Power/Diag LED is blinking continuously.
Chapter 2 - Installation To configure your AirStation, follow the procedure below. USB Port Ethernet Connector AirStation Ethernet Cable Ethernet Connector USB power adapter AirStation Ethernet Cable Launch a web browser. If the home screen is displayed, setup is complete. - 5 -...
Appendix A - Specifications WAN Interface Standard Compliance IEEE802.3u (100BASE-TX), IEEE802.3 (10BASE-T) Transmission Rate 10 / 100 Mbps Transmission Encoding 100BASE-TX 4B5B/MLT-3, 10BASE-T Manchester Coding Access Method CSMA/CD Speed and Flow Control 10 / 100 Mbps, Auto Sensing, Auto MDIX Number of LAN Ports LAN Port Connector RJ-45...
Page 8
Appendix A Specifications Other Power Supply External AC 100-240 V Universal, 50/60 Hz Power Consumption About 2.5 W (Max) Dimensions Weight Operating Environment 0 - 40° C (32 - 104° F), 10 - 85% (non-condensing) - 7 -...
Appendix B - Environmental Information • The equipment that you have purchased has required the extraction and use of natural resources for its production. • The equipment may contain hazardous substances that could impact health and the environment. • In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems.
