Cisco telepresence SX20 quick set Setup Manual page 6

5
Using Web Interface
In general, we recommend you to use the web interface to administer and maintain
the system. The web interface is the administration portal for the system. You can
connect from a computer and administer the system remotely. It provides full con -
figuration access and offers tools and mechanisms for maintenance.
1
3
The web interface is organized in sub-pages. All sub-pages shown below are
available if the video system is registerd to an on-premise service (CUCM, VCS);
the pages shown in grey color are not available if the video system is registered to
the Cisco cloud service (Cisco Spark).
Main menu
Home Call Control Setup
Con guration
Status
Peripherals
Personalization
Favorites
1
Launch a Web browser
and enter the IP address
into the address bar, then
press [Enter] key.
2
2
Enter your [user name] and
[passphrase].
The default user name is [ad-
min] with no passphrase set.
3
Click [Sign In].
Security Maintenance Integration
In-Room Control
Users Diagnostics
Startup Scripts
Access PIN System Logs
Developer API
Server Certi cates Call Logs
CUCM Certi cates User Interface Screenshots
Certi cate Authorities Software Upgrade
Strong Security Mode Option Keys
Sign In Banner Backup and Restore
Non-persistent Mode System Recovery
Restart
6
Configuring Direct IP Address Calls
Without a provisioning system, you must configure each video system individually.
To be able to make calls, you must set the IP address, if not provided by the net -
work, and SIP/H.323 parameters.
1
2
3
6 Configuring Direct IP Address Calls
1
Click [Setup].
2
Click [Configuration].
3
Click [Conference].
4
In the [DefaultCall] section,
5
4
select [H323] from the
[Protocol] drop down list.
5
Click [Save].
Cisco TelePresence SX20 Quick Set Easy Setup Guide
