QUICK INSTALLATION GUIDE
Package Contents
•
Powerline 4-Port Network Adapter
(model number: PLTS200)
•
Powerline Network Adapter (model
number: PLTE200)
•
Powerline Utility and User Guide
on CD-ROM
•
2 Ethernet Network Cables
•
2 Power Cords
•
Quick Installation Guide
•
2 Stands
Powerline
Network Kit
PLTK300
Model:
Advertisement
Related Manuals for Cisco linksys PLTK300
Summary of Contents for Cisco linksys PLTK300
-
Page 1: Quick Installation Guide
QUICK INSTALLATION GUIDE Powerline Network Kit PLTK300 Model: Package Contents • Powerline 4-Port Network Adapter (model number: PLTS200) • Powerline Network Adapter (model number: PLTE200) • Powerline Utility and User Guide on CD-ROM • 2 Ethernet Network Cables • 2 Power Cords •... - Page 2 Overview To create your powerline network, you must connect each network device to a Powerline Adapter. In the first section, you will connect the Powerline Network Adapter (model number: PLTE200) to your router. In the next section, you will connect the Powerline 4-Port Network Adapter (model number: PLTS200) to your computers or other network devices.
- Page 3 Connect the power cord to the Power port of the Adapter. Connect Power Cord Plug the other end into an electrical outlet. Plug Power into Outlet NOTE: Because the Adapter sends data over the power lines of your home, Linksys recommends that you plug the Adapter directly into an electrical outlet.
- Page 4 Install the Second Adapter Connect one end of an Ethernet network cable to an Ethernet port on the Powerline 4-Port Network Adapter (model number: PLTS200). Connect Ethernet Network Cable Connect the other end of the cable to a computer. Connect Other End of Network Cable NOTE: You can connect additional computers or other network devices to the remaining Ethernet ports of the 4-Port Adapter.
- Page 5 Plug the other end into an electrical outlet. Plug Power into Outlet NOTE: Because the 4-Port Adapter sends data over the power lines of your home, Linksys recommends that you plug it directly into an electrical outlet. The 4-Port Adapter has its own power filter to help protect against surges.
- Page 6 800-546-5797 (800-LINKSYS) Linksys, Cisco and the Cisco Logo are registered trademarks or trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2008 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of their respective holders.
