Wireless ADSL Modem Router Setup Manual
b. Two-Line Filter Example. Insert the two-line filter into the phone outlet and connect the
phone to the phone line connector (A):
A
Figure 1-6
Note: To use a one-line filter with a separate splitter, insert the splitter into the
1-8
phone outlet, connect the one-line filter to the splitter, and connect the
phone to the filter.
v1.1, 2006-2
Connecting the Router to the Internet
